Doc Ref: M501 Issue 2.7 Oct 2024
®
Baratherm
User, Installation & Servicing Manual
Issue 2.7 Oct 2024
w w w . p o w r m a t i c . c o . u k

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Baratherm and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Powrmatic Baratherm

Summary of Contents for Powrmatic Baratherm

  • Page 1 Doc Ref: M501 Issue 2.7 Oct 2024 ® Baratherm User, Installation & Servicing Manual Issue 2.7 Oct 2024 w w w . p o w r m a t i c . c o . u k...

  • Page 2: Certificate Of Guarantee

    1. The appliance type and serial number. 2. The original commissioning documentation. As much detail as possible on the fault. 3. Your supplier, or installer, will then contact Powrmatic to make a guarantee claim on your behalf. Conditions of Guarantee 1.

  • Page 3: Table Of Contents

    Dimensions General Requirements Installation Fitting the unit Electrical Cable Installation Wiring Diagrams Commissioning and Testing Servicing Parts Replacement Additional Documents Short List of Parts page no. 3 of 16 Baratherm Ambient Door Curtain Doc Ref M501 issue 2.7 Oct 2024.

  • Page 4: User Instructions

    The high air velocity stream will also reduce the The Baratherm unit has the ability to be wired back to a ingress of airborne contaminates and insects into the ELV door switch (supplied by others) to allow the unit to cooled space.

  • Page 5: Technical Data

    Qty of fans Nett Weight Model BAR3/17A BAR4/22A Dimensions Front View End View Dimensions (mm) Model BAR3/17A 1750 1718 Suspension Points BAR4/22A 2250 2218 page no. 5 of 16 Baratherm Ambient Door Curtain Doc Ref M501 issue 2.7 Oct 2024.

  • Page 6: General Requirements

    Rear of unit to nearest wall Front Recommended mounting height, floor level to underside 2.5m to 5.0m Note: The minimum clearances must be observed for installation and servicing. page no. 6 of 16 Baratherm Ambient Door Curtain Doc Ref M501 issue 2.7 Oct 2024.
  • Page 7 (See diagram below for suspension point dimensions ) ductwork. The ductwork must have an easily removable section where it attaches to the Baratherm unit(s) so that Which ever method of installation is used it must be this may be removed for service access to the Baratherm capable of adequately supporting the weight of the unit(s) unit(s).

  • Page 8: Electrical Cable Installation

    1N, 50Hz supplies. 2.2.3. Door Switch Connections The method of connection to the main electricity supply The Baratherm unit has the ability to be wired back to must:- a ELV door switch (supplied by others) to allow the unit - facilitate the complete electrical isolation of the Air to only operate when the door is in an open position.
  • Page 9 2.2 Electrical Cable Installation MAINS SUPPLY TO BARATHERM +V -V Techna Ktec21 230V CONTROL PANEL TERMINAL RAIL MAINS SUPPLY MAINS SUPPLY TO BARATHERM 230v 1ph 50Hz Mains Wiring VIA ISOLATOR Dwg. A01GBE0360 r3 BAR3/17A: 16A BAR4/21A: 20A LV DOOR ENABLE CIRCUIT...

  • Page 10: Wiring Diagrams

    2.3.3) (see sect.2.2.3) 2.3 Wiring Diagrams 2.3.1. Motor Wiring Connections Dwg. A01GBE0555 (ECP) Wiring Loom Motor 147600203 Terminal Block 147600204 178236-A-00 page no. 10 of 16 Baratherm Ambient Door Curtain Doc Ref M501 issue 2.7 Oct 2024.
  • Page 11 2.3 Wiring Diagrams 2.3.2. Baratherm Electrical Control Panel Dwg. A01GBE0555 (ECP) page no. 11 of 16 Baratherm Ambient Door Curtain Doc Ref M501 issue 2.7 Oct 2024.
  • Page 12 2.3 Wiring Diagrams 2.3.3. Connection diagram operating multiple units via a single door switch Dwg. A01GBE0360 r3 page no. 12 of 16 Baratherm Ambient Door Curtain Doc Ref M501 issue 2.7 Oct 2024.
  • Page 13 Ktec21 3 4 5 6 7 8 CONTROL PANEL #2 CONTROL PANEL #3 TERMINAL RAIL TERMINAL RAIL TITLE: BARATHERM AMBIENT AIR CURTAIN SITE ELECTRICAL CONNECTIONS GUIDE LOW MED HIGH EVL DETAIL ADDED 18.10.24 DRG NO: * high speed shown ADDED T12 &T13. NOTE re. DOOR SWITCH 13.01.22...

  • Page 14: Servicing

    3. Unscrew the fixings holding the fan in place and remove fan complete 4. Replace in reverse order Model Fan part Number BAR3/17A 1402CFAN011-T BAR4/22A 1402CFAN011-T page no. 14 of 16 Baratherm Ambient Door Curtain Doc Ref M501 issue 2.7 Oct 2024.

  • Page 15: List Of Parts

    3.1 List of Parts Item Description Usage Part No. Main Centrifugal Blowers 1402CFAN011-T Contactor 143000602 JOX Relay 143000816 Run-On-Timer BAR/ROT page no. 15 of 16 Baratherm Ambient Door Curtain Doc Ref M501 issue 2.7 Oct 2024.

  • Page 16: Getting In Touch

    Energy Association Powrmatic pursues a policy of continues improvement in both design and performance of its products and therefore reserves the right to change, amend or Powrmatic pursues a policy of continues improvement in both design and performance of its products and therefore reserves the right to change, amend or vary specifications without notice.
