- Page 1 Doc Ref: M503 Issue 3.3 Jan 2020 ® CECx User, Installation & Servicing Manual Issue 3.3 Jan 2020 w w w . p o w r m a t i c . c o . u k...
- Page 2 1. The appliance type and serial number. 2. The original commissioning documentation. As much detail as possible on the fault. 3. Your supplier, or installer, will then contact Powrmatic to make a guarantee claim on your behalf. Conditions of Guarantee 1.
- Page 3 Contents Users, Installation and Servicing Instructions CONTENTS Title Section Contents Page Pre Installation Introduction Dimensions Technical data General Requirements Installation Fitting the unit Wiring Diagrams Commissioning and Testing Servicing Replacement of Faulty Items Additional Documents Short List of Parts page no. 3 of 24 CECx Users, Installation &...
- Page 4 In some installations a low level master control may be to contact our head office for expert advice. installed to provide user control of the units. Your safety is paramount to us. Dimensions CECx 1400 CECx 2250 CECx 3350 CECx 4500 CECx 6500...
- Page 5 1.2 Technical Data Model CECx 1400 CECx 2250 CECx 3350 CECx 4500 CECx 6500 0.77 1.58 3.07 Air flow 2772 4320 5688 7560 11052 Mounting Height (maximum) Mounting Height (suggested minimum) 230V/1Phase/50Hz Supply V/ph/Hz Electrics Start Current amps 0.78 Run Current...
- Page 6 2.1 Fitting the Unit 2.1.1 General Fitting 2.1.1.1.1 Connecting The calecon unit is equipped with four suspension points, one on each corner. These take the form of an eyebolt. Using either our fixing kit, chain or wire rope, connect each point to a rigid construction i.e.
- Page 7 2.1 Fitting the Unit 2.1.2. Electrical Connections All units are fully pre-wired and only require final connections for the incoming mains supply. The electrical supply must be run to a point adjacent to the unit and be suitably terminated to provide an isolation point that will prevent activation of the unit during servicing.
- Page 8 2.2 Wiring Diagrams 2.2.1 1ph Calecon CECx1400/2250/3350 - REMCO Fans LIVE MAINS SUPPLY NEUTRAL 230V 1ph 50 Hz EARTH CEWAL RQ10 THERMOSTAT CAPACITOR Gr/Yel Black Brown Blue 2.2.2 1ph Calecon CECx4500 & CECx6500 - EBM Fans LIVE MAINS SUPPLY NEUTRAL 230V 1ph 50 Hz EARTH CEWAL RQ10...
- Page 9 2.3 Commissioning and Testing 2.3.1. Electrical Installation and higher floor level air velocities. Do not over turn the louvres as this can cause damage. Checks to ensure electrical safety must be carried out by a qualified person. 2.3.2. Final Adjustments and Testing WARNING: When the electrical supply is turned on the unit may start immediately depending on the ambient temperature.
- Page 10 2.5 Replacement of Faulty Components WARNING: Before undertaking any 5. Remove terminal box cover from motor and disconnect component replacement turn off and isolate motor wiring. the electrical supply. 6. Check that replacement fan is of the correct type. 2.5.1 Fan 7.
- Page 11 Notes page no. 11 of 24 CECx Users, Installation & Servicing Instructions Doc Ref M503 issue 3.3 Jan 2020.
- Page 12 Energy Association Powrmatic pursues a policy of continues improvement in both design and performance of its products and therefore reserves the right to change, amend or vary specifications without notice. Whilst the details contained herein are believed to be correct they do not form the basis of any contract and interested parties should contact the Company to confirm whether any material alterations have been made since publication of this brochure.
