- Page 1 Pyrometer Quick Start Guide...
-
Page 2: Table Of Contents
Contents About This Manual ......................3 1.1 Trademarks ......................... 3 1.2 Disclaimer ........................3 1.3 Symbols ........................5 Safety Instruction ....................... 6 Overview ..........................8 3.1 Description ........................8 3.2 Dimensions ......................... 8 3.3 Basics .......................... 9 3.3.1 Infrared Radiation and Emissivity ..............9 3.3.2 1-Color and 2-Color Mode ................. - Page 3 5.2.4 Water/Air Cooled Housing ................21 More Operations ....................... 23 Regulatory Information ....................23...
-
Page 4: About This Manual
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THIS MANUAL AND THE PRODUCT DESCRIBED, WITH ITS HARDWARE, SOFTWARE AND FIRMWARE, ARE PROVIDED "AS IS" AND "WITH ALL FAULTS AND ERRORS". HIKMICRO MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING WITHOUT LIMITATION, MERCHANTABILITY, SATISFACTORY QUALITY, OR FITNESS FOR A PARTICULAR PURPOSE. - Page 5 YOU ACKNOWLEDGE THAT THE NATURE OF THE INTERNET PROVIDES FOR INHERENT SECURITY RISKS, AND HIKMICRO SHALL NOT TAKE ANY...
-
Page 6: Symbols
RESPONSIBILITIES FOR ABNORMAL OPERATION, PRIVACY LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER-ATTACK, HACKER ATTACK, VIRUS INFECTION, OR OTHER INTERNET SECURITY RISKS; HOWEVER, HIKMICRO WILL PROVIDE TIMELY TECHNICAL SUPPORT IF REQUIRED. YOU AGREE TO USE THIS PRODUCT IN COMPLIANCE WITH ALL APPLICABLE LAWS, AND YOU ARE SOLELY RESPONSIBLE FOR ENSURING THAT YOUR USE CONFORMS TO THE APPLICABLE LAW. -
Page 7: Safety Instruction
2. Safety Instruction These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss. The device can only be operated by trained personnel in accordance with these instructions and local safety regulations. Laws and Regulations ... -
Page 8: Maintenance
The wave length is 650+10 nm; the maximum output is 7 mW; laser beam divergence angle is 36×7° (maximum: 40×10°). Prevent eyes from direct laser and wear a pair of goggles for your safety. The operating wavelength of the eyewear should be longer than laser peak wavelength and its optical density should be higher than OD5+. -
Page 9: Overview
3. Overview 3.1 Description The 2-color pyrometer (hereinafter referred to as pyrometer or device) is an intelligent 2-color temperature measuring instrument, which can measure the target of medium and high temperature with high accuracy. The device is often used in various kinds of industrial sites with high demand for temperature control. -
Page 10: Basics
Figure 3-1 Dimensions (Unit: mm [inch]) 3.3 Basics 3.3.1 Infrared Radiation and Emissivity The surface of an object emits infrared radiation, the intensity of which varies with the temperature of the object. At the same time, according to the material and surface properties, the emitted radiation is roughly in the wavelength range of 1 to 20 μm. -
Page 11: Targets Smaller Than Field Of View
The 1-color mode determines the temperature by the radiation energy of a narrow wavelength range emitted from an object. The pyrometer measures the average temperature for a small detection area. Thus, the accuracy of measurement is affected by several factors, such as whether the target emissivity is stable, the measurement setting-up and the target is correctly arranged, and other environmental factors like background radiation. -
Page 12: Appearance
4. Appearance 4.1 Component The pyrometer appearance is shown in the figure below. M72×1.5 Thread Objective Button×4 Eyepiece Screen Aviation Plug Figure 4-1 Pyrometer Exterior Components 4.2 Cable The pyrometer comes with 1 standard cable from the factory, one end of which connects to the device’s aviation plug, while the other end can be customized for power connection, temperature and alarm signal transmission, etc. - Page 13 Aviation Plug Connects to the aviation plug of the pyrometer. Network Plug Connects to a switch or router for power and network supply. PoE powered, DC24 V. Terminal Table 4-1 Description of the Terminal Wiring Sequence Wire Number Specification Power Analog Analog 4~20...
-
Page 14: Installation
5. Installation 5.1 Positioning 5.1.1 Environment Before determining the installation location of the device, it is necessary to clarify the ambient temperature, air quality, and electromagnetic interference at the site. Note For detailed technical data, please refer to the technical specifications of the product. Ambient Temperature Under no circumstances should the ambient temperature exceed the maximum allowable operating temperature of the device. -
Page 15: Distance To Object
To avoid ground loops, make sure that the device or the external power supply terminal connected to the device is grounded at a single point. Note If you are unsure about the temperature measurement mode to use, it is recommended to select installation points that meet the requirements for both 1- color and 2-color modes. - Page 16 Note D represents the distance to object. S represents the diameter of the target spot size. D:S represents the fixed optical resolution, refer to the technical specifications. For example: spot size S = 10 mm, device D:S = 100:1, then the maximum measurement distance should be no more than 1000 mm.
-
Page 17: Viewing Angles
5.1.3 Viewing Angles In 1-color mode, it is best for the measurement direction to be perpendicular to the target, with an allowable angle between the measurement direction and the target ranging from 30 degrees to 90 degrees. In 2-color mode, it is best for the measurement direction to be perpendicular to the target, with an allowable angle between the measurement direction and the target ranging from 45 degrees to 90 degrees. -
Page 18: Mechanical Accessories
5.2 Mechanical Accessories The device has an M72 × 1.5 standard, 23.5 mm long thread on its front end, which can be installed with optional accessories such as the fixed bracket, adjustable bracket, air-purge, and water/air cooled housing. Fixed Mounting Bracket Pyrometer Air Purge... -
Page 19: Adjustable Bracket
The fixed bracket has one 6.5 mm diameter hole and one 6.5 mm wide waist hole at the bottom, which can be mounted with the optional bracket. Figure 5-5 Dimension of Fixed Bracket (Unit: mm [inch]) 5.2.2 Adjustable Bracket The adjustable bracket enables the device to be mounted in a movable location. For a correct device orientation, you can pitch and swivel the sighting axis in a range of about 60°... - Page 20 Adjustable Bracket 1/4UNC-20 Screw×2 Fixed Bracket Figure 5-6 Adjustable Bracket Lock the adjustable bracket and fixed bracket using two 1/4UNC-20 screws. Lock the fixed bracket to the M72 × 1.5 threaded connection on the front of the pyrometer using the mounting nut. The adjustable bracket has one 6.5 mm diameter hole and two 6.5 mm wide waist holes at the bottom, which can be mounted with the optional bracket.
-
Page 21: Air Purge
5.2.3 Air Purge The air purge is used to remove dust, moisture, water vapor and suspended particles from the pyrometer lens and can be installed with the fixed-bracket. Lock the purge onto the M72 × 1.5 threaded connection on the front of the pyrometer. - Page 22 Caution When measuring temperature in 1-color mode, the purge must always be supplied with clean and dry compressed air or nitrogen to avoid contaminating the lens area. Do not purge with cold air at temperatures below 10 °C, the purge input should follow the correct pressure flow.
- Page 23 Figure 5-9 Dimension of Water/Air Cooled Housing (Unit: mm [inch]) Connect the purge and water/air cooled device via the purge connection, water/air inlet, and water/air outlet. Self-selected connecting hoses, air compressors, and water pumps are available. For situations with higher safety requirements or where water cooling is not suitable, compressed air cooling or vortex coolers can be used for cooling.
-
Page 24: Regulatory Information
6. More Operations For a detailed explanation of the device installation, commissioning and configuration, scan the QR code below: Note The document is aimed at those who work with the device over the entire life cycle and perform specific configurations. 7. - Page 25 be required to take adequate measures. Directive 2012/19/EU (WEEE Directive): Products marked with this symbol cannot be disposed of as unsorted municipal waste in the European Union. For proper recycling, return this product to your local supplier upon the purchase of equivalent new equipment, or dispose of it at designated collection points.
- Page 26 UD40182B...
