NDU-2NX Filter Cart
User Manual
© Copyright 2018 Filtertechnik
Fax:
+44 (0)115 986 8875
Web:
www.filtertechnik.co.uk
March 2018
V1.00
Registered in England No: 03969985 VAT No: 760 821 731
Certification No. UK002838
Advertisement
Table of Contents
Related Manuals for Filtertechnik NDU-2NX
Summary of Contents for Filtertechnik NDU-2NX
- Page 1 NDU-2NX Filter Cart User Manual March 2018 V1.00 © Copyright 2018 Filtertechnik Filtertechnik 1 Central Park, Lenton Lane, Nottingham, NG7 2NR Tel: +44 (0)115 9003 600 Fax: +44 (0)115 986 8875 Email: sales@filtertechnik.co.uk Web: www.filtertechnik.co.uk Registered in England No: 03969985 VAT No: 760 821 731...
-
Page 3: Table Of Contents
Suction Strainer ............................. 16 Troubleshooting ............................ 17 Spare Parts List ............................18 Warranty Statement ..........................19 EC Declaration of Conformity ........................ 20 Filtertechnik 1 Central Park, Lenton Lane, Nottingham, NG7 2NR Fax: +44 (0)115 986 8875 Tel: +44 (0)115 9003 600 Email: sales@filtertechnik.co.uk... -
Page 4: Specifications
3m long x 1" BSP female swivel hydraulic Ambient temperature -10°C to +60°C Maximum humidity 90% relative humidity, non-condensing Environment IP55 Filtertechnik 1 Central Park, Lenton Lane, Nottingham, NG7 2NR Fax: +44 (0)115 986 8875 Tel: +44 (0)115 9003 600 Email: sales@filtertechnik.co.uk... -
Page 5: Typical Applications
• Ensure a spill kit is available in case of any accidental spills. • Used filters must be disposed of in accordance with local environmental requirements. Filtertechnik 1 Central Park, Lenton Lane, Nottingham, NG7 2NR Fax: +44 (0)115 986 8875... -
Page 6: Basic Description
Basic Description The NDU-2NX portable filtration unit is a compact, self-contained filtration system, equipped with a high efficiency, high capacity filter cell capable of removing particulate contaminants and/or water quickly, conveniently and economically. It is designed for on-site preventative maintenance and is fitted with two standpipes and hoses for efficient fluid transfer. -
Page 7: Achieving Iso Cleanliness Codes
Achieving ISO Cleanliness Codes Filtertechnik has a wide range of elements available to effectively achieve the required cleanliness level for the intended system. Maintaining the fluid at the required cleanliness level is a cost effective way of extending the service life of system components. The tables below can be used to... - Page 8 16,200 2,880 23/21/18 1,024,000 182,400 32,400 5,760 1,020 Table 5 – ISO 4406 vs NAS 1638 Contamination Filtertechnik 1 Central Park, Lenton Lane, Nottingham, NG7 2NR Fax: +44 (0)115 986 8875 Tel: +44 (0)115 9003 600 Email: sales@filtertechnik.co.uk Web: www.filtertechnik.co.uk Registered in England No: 03969985 VAT No: 760 821 731 Certification No.
-
Page 9: Component Identification
11.) Vent valve 5.) Discharge lance 12.) Electrical box 6.) Differential pressure gauge 13.) Outlet 7.) System pressure gauge 14.) Inlet Filtertechnik 1 Central Park, Lenton Lane, Nottingham, NG7 2NR Fax: +44 (0)115 986 8875 Tel: +44 (0)115 9003 600 Email: sales@filtertechnik.co.uk... -
Page 10: Starting & Stopping - Dol (Direct-On-Line)
If for any reason the power supply cuts out, the internal contactor will unlatch to prevent accidental spillage once power is restored. Filtertechnik 1 Central Park, Lenton Lane, Nottingham, NG7 2NR... -
Page 11: Pressure Gauge
Indicates the filter is now fully blocked and requires changing The filter cell housing is monitored by a visual differential pressure indicator, displaying the filter’s condition via a green, yellow and red traffic light system. Filtertechnik 1 Central Park, Lenton Lane, Nottingham, NG7 2NR Fax:... -
Page 12: Filter Cell Housing
7.) Filter basket 3.) Filter securing bracket 8.) Filter cell 4.) Magnet (optional) 9.) Drain port 5.) Outlet port 10.) Outlet port Filtertechnik 1 Central Park, Lenton Lane, Nottingham, NG7 2NR Fax: +44 (0)115 986 8875 Tel: +44 (0)115 9003 600 Email: sales@filtertechnik.co.uk... -
Page 13: Cleaning The Magnet
Removal of ferromagnetic material can be carried out using a suitable tool as shown above (Filtertechnik part number FT-RRT01). The tool is to be located at the top of the magnet and downward force applied to push the material off the magnet. -
Page 14: Purging Air From The Filter Housing
Once all the air has been removed make sure the sampling / vent tube is disconnected to prevent siphoning or spillage of fluid. Filtertechnik 1 Central Park, Lenton Lane, Nottingham, NG7 2NR Fax:... -
Page 15: Sampling
1620 minimess test points to avoid accidental spillage. The upper port will provide pre-filtration sampling, while the lower port will provide post-filtration sampling. Filtertechnik 1 Central Park, Lenton Lane, Nottingham, NG7 2NR Fax: +44 (0)115 986 8875... -
Page 16: Pressure Monitoring
Connected using minimess test points, it’s possible to connect the gauge to the sampling ports on the filter housing to monitor pre and post filtration pressure. Filtertechnik 1 Central Park, Lenton Lane, Nottingham, NG7 2NR Fax: +44 (0)115 986 8875... -
Page 17: Pump
Isolation valves are fitted to the inlet and outlet ports. These should be closed off when the system is not in use, or when filter cells are being change out. It is also advisable to cap off ends of the pipework to prevent contaminants from entering the system. Filtertechnik 1 Central Park, Lenton Lane, Nottingham, NG7 2NR Fax:... -
Page 18: Hoses & Lances
The suction strainer will periodically need cleaning by unscrewing the cap, removing the mesh strainer and cleaning this out with a fluid suited for the units intended purpose e.g. hydraulic oil. Filtertechnik 1 Central Park, Lenton Lane, Nottingham, NG7 2NR... -
Page 19: Troubleshooting
Brittle hoses would require replacement Spills under unit Defective shaft seal Replace seals where necessary Hose leaks Tighten all joints Filtertechnik 1 Central Park, Lenton Lane, Nottingham, NG7 2NR Fax: +44 (0)115 986 8875 Tel: +44 (0)115 9003 600 Email: sales@filtertechnik.co.uk... -
Page 20: Spare Parts List
5 µm high efficiency disposable polypropylene FT-19HE005-2GYEP 1 µm FiltaSorb2 water removal cell FT-FA-02-001 1 µm absolute rated pleated element FT-CE-02-Z01 (requires filter clamp FT-AFC-01) Filtertechnik 1 Central Park, Lenton Lane, Nottingham, NG7 2NR Fax: +44 (0)115 986 8875 Tel: +44 (0)115 9003 600 Email: sales@filtertechnik.co.uk... -
Page 21: Warranty Statement
Limited Express Warranties, and no others: For a period of one (1) year from and after the date of delivery of a new Filtertechnik product, Filtertechnik warrants and guarantees only to the original purchaser/user that such a product shall be free from defects of materials and workmanship in the manufacturing process. -
Page 22: Ec Declaration Of Conformity
EC Declaration of Conformity NDU FILTER CART Filtertechnik 1 Central Park, Lenton Lane, Nottingham, NG7 2NR Fax: +44 (0)115 986 8875 Tel: +44 (0)115 9003 600 Email: sales@filtertechnik.co.uk Web: www.filtertechnik.co.uk Registered in England No: 03969985 VAT No: 760 821 731 Certification No.
