Ultravation synergy Installation And Owner's Manual

Maintenance:
Typical maintenance of the Synergy is recommended replacement of the UVLED-ION-
module every 36,000 hours approximately 4 years, for optimum results change Module
every 2 years.
Replacement Module Part Numbers:
12"UVLED-ION module ..................SYNCELL
Safety Precautions:
It is recommended that this unit be installed and maintained by a trained technician.
WARNING: UVA Hazard. Always protect eyes from ultraviolet light. NEVER look at UV lamps in
operation. Unplug or disconnect power before servicing.
WARNING: Severe eye damage or temporary blindness may occur.
WARNING: DO NOT operate outside of air handler. Mount product in preferred
location first.
WARNING: No openings should be allowed which would give direct line-of-sight to the UV light.
Note: In the event of accidental breakage or replacement of the ultraviolet lamp, please ensure that
the lamp is disposed of in accordance with local and state environmental laws regarding fluores-
cent lamps containing mercury.
Notice: All wiring inside of the air handler in direct line of site of the UV lamp must be shielded
with aluminum foil tape or equivalent non-combustible material. When installing this unit, select
a mounting location that prevents ultraviolet light exposure to synthetic or other plastic com-
ponents with unknown resistance to ultraviolet light. Ultraviolet light may cause color shift or
structural degradation of plastic internal components.
Warranty:
Synergy features Ultravation's lifetime warranty, with the exception of the UVLED-ION
module, which are warranted for a period of two years after date of consumer purchase.
This warranty does not include damage to the unit from accident, misuse or improper
installation.
If this product should become defective, Ultravation will elect to repair or replace the
product free of charge. Ultravation will return repaired or replaced warranted products
pre-paid to the customer, provided that the product was delivered pre-paid.
Ultravation shall have no responsibilities for charges incurred by the customer for
installation or removal of warranted items. Liability is limited only to the replacement or
repair of this product.
This warranty gives you specific legal rights, and you may also have other rights, which
vary from state to state. All returns must be accompanied by a return authorization
number, which may be obtained by contacting Ultravation, Inc.
Ultravation, Inc.
P.O. Box 165, 212 Ideal Way, Poultney, Vermont 05764
Phone: 1-866-GO-UV-AIR (468-8247) • Fax: 802-287-9203
www.ultravation.com • info@ultravation.com
Copyright © 2008-2020 Ultravation Inc.
DC-OM-SYN
Installation and Owners Manual
Model # Synergy
Whole House Air purifier with advanced oxidation
combined with 8x bi-polar ION generation.
Operating voltage: 24 vac 20 watts.
(24 VAC 40 VA.Transformer included)
Ultravation ®
y
LED
Whole House PCO Air Purifier for HVAC Sys
Multiple technologies combine for the
most powerful and efficient air purifier
available for HVAC.
• Deep Bed Organic Carbon
Photocatalytic Oxidation
• High Frequency UVLED
• Multi-pin Ionization
Powerful for whole house effectiveness
• Unified UVLED and ionizer module.
One piece simplicity, long 4-year lifespan.
• 3 Deep Bed Organic Carbon Purification Panels for photocatalytic
oxidation (PCO), energized by UVLED light to break down contamination.
• Patented TiO PCO formulation. The carbon panels are infused with
2
a patented formulation of Peroxo-Antanse
Titanium Dioxide (TiO ) that includes silver and
2
zinc ions. The ions prevent bio-growth in the air and on surfaces.
Clean Air Beyo
U.S. PATENT 6,429,169
