Summary of Contents for YORKVILLE EXM Pro 12
- Page 1 OWNER'S MANUAL MANUEL DE L'UTILISATEUR EXM Pro 12 Bluetooth B A T T E R Y P O W E R E D L O U D S P E A K E R S Y S T E M...
-
Page 2: Important Safety Instructions - English / Français
Important Safety Instructions - English / Français I MP OR TA N T S A FE T Y I N ST R U C TI O N S This lightning flash with arrowhead symbol, within an The exclamation point within an equilatereal triangle is intended to alert the user to the presence equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous of important operating and maintenance (servicing) instructions in the literature accompanying voltage”... -
Page 3: Table Of Contents
Table of Contents Important Safety Instructions - English / Français ���� i Introduction ������������������������������������������������������ 5 EMC Declaration TYPE A - English / Français ����������� ii Configurations du Système ����������������������������������� 5 Table of Contents ������������������������������������������������ ii Entrées des Canaux ��������������������������������������������� 6 Diagram ������������������������������������������������������������... -
Page 4: Diagram
P.A. User Guides avail- able on our website (http://www.yorkville.com) System Configurations The scalable nature of the Yorkville EXM Pro12 allows for several configurations that can be utilized to suit your needs� Here are some examples: Diagram... -
Page 5: Channel Inputs
Bluetooth ® The Yorkville EXM Pro12 is capable of Bluetooth® audio streaming from devic- es such as smart phones, tablets and laptops� Pairing your device with an EXM Pro12 is simple and gives you the freedom to play your music wirelessly�... -
Page 6: Level Control
Master Section Master Control The Master Control is used to set the overall level of the Yorkville EXM Pro12� Note: When two systems are linked together, the Master Control only affects the level of the unit on which it is located. -
Page 7: Battery Status Indicators
Battery Status Indicators The EXM Pro12 has a series of four green LEDs to indicate the approximate charge level� The upper green LED is illuminated SLEEP MODE if there is greater than 75% charge in the battery� The DEFEAT red LED only will indicate that the battery is critically low (approximately 10% remaining) and needs immediate charging�... -
Page 8: Introduction
P.A. disponibles sur notre site Web (http://www.yorkville.com). Configurations du Système La nature évolutive de l’EXM Pro12 de Yorkville permet plusieurs configurations qui peuvent être utilisées pour répondre à vos besoins� En voici quelques exemples: Diagram... -
Page 9: Entrées Des Canaux
3. Bluetooth ® L’EXM Pro12 de Yorkville est capable de diffuser des flux audio Bluetooth® à partir d’appareils tels que des téléphones intelligents, des tablettes et des ordinateurs portables� Le jumelage de votre appareil avec un EXM Pro12 est simple et vous donne la liberté... -
Page 10: Comande De Niveau
Section Principale Commande “Master” La commande “Master” est utilisé pour régler le niveau général de la EXM Pro12 de Yorkville� Remarque : Lorsque deux systèmes sont reliés entre eux, la commande principale n’affecte que le niveau de l’unité sur laquelle elle se trouve. -
Page 11: Prise De Sortie Principale Et D'entrée Principale
Prise de Sortie Principale et d’Entrée Principale Les prises de sortie principale et d’entrée principale sont en parallèle et nous avons prévu une prise XLR mâle et une XLR femelle pour faciliter la liaison des enceintes EXM 70/Mobile/ Mobile12/Mobile8/Pro12� Pour utiliser la fonction “Link”, insérez un câble de raccordement XLR standard entre les enceintes�... -
Page 13: Specifications - English
Specifications - English Specifications Program Power (watts) 800 watts program (500 Low, 200 Mid, 100 High) Max SPL (dB) 125dB Cont, 131dB Peak Frequency Response (Hz +/- 3dB) 45 - 20K (Hz +/-3dB) Power Consumption While Charging 100 watts (battery fully discharged and unit idling) Speaker Configuration - LF 12 inch Neo Speaker Configuration - MF/HF 6.5-inch/1-inch exit horn Neo Coaxial Inputs 8... -
Page 14: Block Diagram
Block Diagram... -
Page 15: Warranty - English / Français
Unlimited Warranty Yorkville's two and ten-year unlimited warranty on this product is transferable and does not require registration with Yorkville Sound or your dealer. If this product should fail for any reason within two years of the original purchase date (ten years for the wooden enclosure), simply return it to your Yorkville dealer with original proof of purchase and it will be repaired free of charge. -
Page 16: Rear Page
WORLD HEADQUARTERS CANADA U.S.A. Yorkville Sound Limited Yorkville Sound Inc. 550 Granite Court 4625 Witmer Industrial Estate Pickering, Ontario Niagara Falls, New York L1W 3Y8 CANADA 14305, USA Voice: 905-837-8481 Voice: 716-297-2920 Fax: 905-837-8746 Fax: 716-297-3689 Manual-Owners-EXMPRO12-00-1v7 • December 16, 2024...
