- Page 1 WIFI BIRDCAM PRO INSTRUCTION MANUAL...
- Page 2 We’ve developed the WiFi BirdCam Pro out of our love for our garden friends - as well as our mission to make wildlife watching easy and fun.
-
Page 3: Table Of Contents
CONTENTS In the box....................... 3 Bird feeder overview..................4 BirdCam overview....................5 Indicator light....................... 6 Notes before use....................7 Setting up your BirdCam................... 8 Installing the feeder................... 9 Rotating the feeder................... 13 Refilling / securing the feeder................ 14 Mounting the camera..................15 Charging the camera.................. -
Page 4: In The Box
IN THE BOX Weatherproof rubber... -
Page 5: Bird Feeder Overview
BIRD FEEDER OVERVIEW Bird Feeder Cover Solar Panel Camera Perch Bracket... -
Page 6: Birdcam Overview
BIRD CAM OVERVIEW Indicator Light Power ON/OFF Light Sensor Infrared LED Sync/Reset Lens Charging Port Microphone Mounting Hole MicroSD card Slot Motion Sensor Speaker... -
Page 7: Indicator Light
INDICATOR LIGHT The LED light on the front of the BirdCam indicates the current status. These are: Turning on: Red Pairing mode: Blinking red Searching for WiFi: Green light blinking Connected to WiFi: Green light solid, before turning off Issue with pairing/connection: Red light slowing blinking. Reset the camera. -
Page 8: Notes Before Use
The status light can be turned on/off in the app settings. Motion Detection Motion triggered recording is automatically disabled when the NatureSpy app is open, but once you close / come out of the app this will be re-enabled after a few minutes. -
Page 9: Setting Up Your Birdcam
SETTING UP YOUR BIRDCAM Download the ‘NatureSpy’ App from the App Store or Google Play Store. Launch the app. Create a new account or log in to your existing account. Tap the '+' symbol in the top right corner and select 'Add Device'. -
Page 10: Installing The Feeder
INSTALLING THE FEEDER Stick the sticker on the tree, post or wall that you want to hang the feeder onto. This will show you where to drill the holes. If mounting on a wall, drill holes with a 6mm drill bit and insert the green plastic spacers (you may need to tap them in with a hammer) If mounting on a tree or post, drill guide holes using a 2mm drill bit. - Page 11 Next, attach the bracket to the tree, post or wall using the long screws provided.
- Page 12 Then, mount the feeder on top of the bracket. Next, position the bracket connector underneath lined up with the screw holes. If you have to twist the feeder to do this, don’t worry - you’ll be able to rotate the feeder after it’s attached.
- Page 13 Fix the bird feeder onto the bracket using the 3 screws provided. Next, attach the perch using the two small screws. NOTE: if mounting where squirrels are present, use the metal perch. The plastic perch should only be used if squirrels are not in the area or cannot access the feeder.
-
Page 14: Rotating The Feeder
ROTATING THE FEEDER After installation, you may need to rotate the feeder to your desired position. This is simply a case of pushing the feeder round to the left or the right. -
Page 15: Refilling / Securing The Feeder
REFILLING / SECURING THE FEEDER The feeder refill flap is behind the solar panel on the top of the feeder. It can be secured with 2 screws. This helps keep water out of the feeder and also prevents squirrels accessing the feed from this angle. -
Page 16: Mounting The Camera
MOUNTING THE CAMERA From time to time you may need to remove the camera for supplementary charging, or to clean the feeder. To mount the camera in the feeder, follow the instructions below. To remove the camera from the feeder, follow these instructions in reverse order. - Page 17 2. Place the camera in, with the switch area facing you, and line up the screw in the back of the camera with the mounting nut. 3. Screw the mounting nut into place, and be careful not to over-tighten.
- Page 18 4. Attach the solar panel cable firmly into the camera. 5. Tilt camera to the required angle.
-
Page 19: Charging The Camera
CHARGING THE CAMERA When you first receive your BirdCam, the camera will need to be fully charged. Remove the BirdCam from the feeder, and remove the top rubber piece. Connect the USB-C cable to the camera, and the other end to your charger. -
Page 20: Faq
For the latest versions of these FAQs, troubleshooting tips, and the latest version of this manual, go to the ‘FAQs and Manual’ option in the app, under your BirdCam’s settings. Q: How do I reset the BirdCam? A: To reset the camera, use the Pin to press and hold the Sync button for 10 seconds, and remove the pin. - Page 21 There's no need to uninstall the app for this. To do this: Open the camera on the NatureSpy app Open settings and scroll to the bottom of the page Select ‘Remove Device’...
- Page 22 A: You can check for any new firmware updates in your camera’s settings menu. To do this: Open the camera on the NatureSpy app Open settings and scroll to the bottom of the page Select “Device Update” Update your camera if new firmware is available After updating your camera's firmware, we recommend fully resetting and re-pairing it to ensure optimal functionality.
- Page 23 You can jump to your desired clip more quickly using the motion detection alert: Open the camera on the NatureSpy app Select the “Messages” tab at the bottom Select the “All” button on the right-hand side Scroll to your desired clip and then press “View”...
- Page 24 Press the share button in the bottom right Select the app you wish to use to share your clip Please note that sharing directly from the NatureSpy app may compress and reduce video quality. To maintain the best quality, first, save the clip...
