- Page 1 DISCO SPHERE 107 USER MANUAL LCRT2KO...
-
Page 2: Unpacking Instructions
Any wrong operation will make this unit out of warranty. Carefully move after receiving it, checking whether there is any damage from shipping, and all the accessories in it. NAME DISCO SPHERE 107 Power Cord KEYS (for key switch) Interlock switch... -
Page 3: Safety Instructions
Safety Instructions Safety Instructions To protect the environment, please try to recycle the packing material as much as possible. The projector is for indoor use only, IP20. Use only in dry locations. Keep this device away from rain and moisture, excessive heat, humidity and dust. Do not allow contact with water or any other fluids, or metallic objects Don’t throw this product away just as general trash, please deal with the product follow the abandon electronic product regulation in your country. -
Page 4: Overhead Rigging
Overhead Rigging Attention! The installation must be carried out by qualified service personal only. Improper installation can result in serious injuries and /or damage to property. Overhead rigging required extensive experience! Working load limits should be respected, Certified installation materials should be used, the installed device should be inspected regularly for safety. - Page 5 Overhead Rigging DMX connection ◆ Connection between laser lights and DMX must use the shied cable of diameter more than 0.5mm. Please use the attached 3 pin XLR plug/socket to connect the DMX output/input interface. The connection between socket and cable as below( note the plug/socket’s 3 pin number and position). DMX-output DMX-input XLR mounting-sockets(rear view):...
-
Page 6: Button Description
Button description Button description MENU DOWN ENTER Button Function MENU Select mode and return to the previous menu Go to the next level of the menu ENTER I'm going to go up to a higher value Lower the value down DOWN 2、Menu description ENTER, parameter setting... - Page 7 Button description SLAV From the machine model ENTER finally confirms return ON: digital tube open power LED display saves electricity saving mode; When open for 30s without LEDS operation, the digital tube is OFF: digital tube OFF power saving mode(default ON) closed for a small point.
- Page 8 DMX channel description 000-005 Black Out 006-040 P1/S1 Auto and sound 041-076 P2/S2 Programs 077-112 P3/S3 113-148 P4/S4 149-184 P5/S5 185-220 P6/S6 221-255 P7/S7 Program speed 000-250 Speed slow to fast when channel 1 is 251-255 Sound between 212-255 Stop 001-127 Rotate left, slow to fast Motor...
- Page 9 DMX channel description 236-246 Read Green White Read Green Blue Green Blue White 247-255 Read Green Blue White Read Green Blue White Read Green Blue White 000-255 Total brightness, 0-100%PWM 000-005 No Strobe 006-250 Strobe slow to fast 251-255 Sound 000-005 Blackout 006-046...
- Page 10 DMX channel description 027-037 Blue Blue Blue 038-048 White White White 049-059 Read Green Blue 060-070 Read Green White 071-081 Read Blue White 082-092 Green Blue White 093-103 Read Green Read Blue Read White 104-114 Green Read Green Blue Green White 115-125 Blue Read Blue Green...
-
Page 11: Product Parameter
Product parameter Parameter DISCO SPHERE 107 Model: LED: 10W RGBW Laser: 100mw/650nm 30mw/532nm Box Size: L340*W270*H155 Weight: Power input: 100-240V 50/60Hz Power: Channels: 3/12CH Auto Show: Sound Show: Product size...
