THE INDUSTRY STANDARD FLARE, REDEFINED
USER MANUAL
TMB authorizes its customers to download and print this electronically published manual for professional use only.
TMB prohibits reproduction, modification or distribution of this document for any other purposes, without express written consent.
Specifications are subject to change without notice. The information in this document supersedes all previously supplied information before the effective date
listed below. TMB has confidence in the accuracy of the document information herein but assumes no responsibility or liability for any loss occurring as a direct
or indirect result of errors or exclusions whether by accident or any other cause.
Effective 3 October 2024. © Copyright 2024, TMB. All rights reserved
Advertisement
Table of Contents
Related Manuals for Solaris FLARE XL 120
Summary of Contents for Solaris FLARE XL 120
-
Page 1: Title Page
XL 120 • XL 72 • XL 36 • XL 6 FLARE XL 120 FLARE XL 72 FLARE XL 36 FLARE XL 6 FLARE XL THE INDUSTRY STANDARD FLARE, REDEFINED USER MANUAL TMB authorizes its customers to download and print this electronically published manual for professional use only. -
Page 2: Table Of Contents
Table of contents ......................................3 Overview .........................................5 Flare XL Family Description ................................5 Main Features ......................................5 Ordering Codes ....................................6 Dimensional Drawings ..................................7 Flare XL 120 .......................................7 Flare XL 72 ......................................8 Flare XL 36 ......................................9 Flare XL 6......................................10 Setup ..........................................11 Safety Precautions ....................................11 Unpacking ........................................11... -
Page 3: Table Of Contents
Control Mode ......................................24 Recommended ....................................25 Basic Mode ......................................26 Advanced Control Modes ................................28 Flare XL 120 - Pixel Map ...............................29 Flare XL 120 - DMX Chart ..............................30 Flare XL 72 - Pixel Map .................................35 Flare XL 72 – DMX Chart ..............................37 Flare XL 36 - Pixel Map .................................41... - Page 4 FLARE XL USER MANUAL Fixture Status ......................................49 Output Preview ....................................49 Fixture Info ......................................49 Fixture Config .......................................50 LCD Dimming ....................................50 Ethernet Config .....................................50 Advanced .......................................50 Supported RDM PIDs ....................................51 Cleaning and Maintenance ...................................52 Firmware Updates ....................................52 Technical Specifications ....................................53 Limited Warranty Information ................................54 Return Procedure ......................................55 Contact information ....................................56 4 / 56...
-
Page 5: Overview
USER MANUAL The Solaris Flare XL Family of lighting fixtures are the next generation of high output, hybrid wash luminaires. As the successor to the Flare Q+ lineup, Flare XL is even bigger and brighter – with a range of models suitable for a variety of venues ranging from small stages to stadium events. -
Page 6: Ordering Codes
SFXL36LAAD Solaris Flare XL36 Light Line Array Air Vent OPTICS PLATES SFXLOPT9L Solaris Flare XL Optics Plate Kit - 6 X 9° Lenses w/hardware SFXLOPT25L Solaris Flare XL Optics Plate Kit - 6 X 25° Lenses w/hardware SFXLOPT35L Solaris Flare XL Optics Plate Kit - 6 X 35° Lenses w/hardware SFXLOPT50R Solaris Flare XL Optics Plate Kit - 6 X 50°... -
Page 7: Dimensional Drawings
FLARE XL USER MANUAL SOLARIS FLARE XL120 Dimensions: mm [inches] 7 / 56... -
Page 8: Flare Xl 72
FLARE XL USER MANUAL SOLARIS FLARE XL72 Dimensions: mm [inches] 8 / 56... -
Page 9: Flare Xl 36
FLARE XL USER MANUAL SOLARIS FLARE XL36 Dimensions: mm [inches] 9 / 56... -
Page 10: Flare Xl 6
FLARE XL USER MANUAL SOLARIS FLARE XL6 Dimensions: mm [inches] 10 / 56... -
Page 11: Setup
FLARE XL USER MANUAL SETUP Safety Precautions Please read these instructions carefully. This user guide contains important information about the installation, usage, and maintenance of this product • Ensure the device is connected to proper voltage, and that line voltage is not higher than that stated in the device specifications •... -
Page 12: What's Included
0-100% switch. When powered up, the Solaris Flare XL will initially show a boot screen, then the factory default DMX address appears on the display screen and Solaris is ready for operation. After initial power-up, the last saved DMX address will appear. -
Page 13: Fuse Replacement
Replacement fuses are available from TMB, please contact sales@tmb.com Flare XL 120 uses a 20A 250V fuse, Flare XL 72 uses a 20A 250V fuse, Flare XL 36 uses a 10A 250V fuse *Note: XL 6 units do not have a user-serviceable fuse To replace a Fuse: 1. -
Page 14: Dmx Data Linking
FLARE XL USER MANUAL DMX DATA LINKING Traditional DMX linking for Flare XL fixtures requires a portable DMX data cable (such as ProPlex PC224P) with 5-pin XLR connectors on either end The DMX Signal originates from the source and is sent via daisy-chain connection from fixture output to fixture input, until the last fixture is connected in your DMX signal data chain When using sACN or Art-Net communication, the daisy-chain is very similar –... -
Page 15: Installation
FLARE XL USER MANUAL To adjust the tilt angle of the fixture, loosen both knobs first before attempting to position. Hold the fixture at the appropriate tilt angle with one hand while re-tightening a knob with your other hand. With one knob tight the unit should lock in position, allowing you to re-position your hands to re-tighten the remaining knob •... -
Page 16: Operation
FLARE XL USER MANUAL OPERATION Control panel overview All Flare XL Family fixtures share the same interface with slightly different pixel mode options depending on the model The 4 navigation buttons to the left and right of the screen change function depending on the menu. Each of the 4 corners of the LCD screen display a soft-key icon that directly corresponds to the hard button next to it The Home Screen has only two button functions, the other two buttons have no function As you enter the main menu, the button functions change to simple arrow navigation. -
Page 17: Home Screen
FLARE XL USER MANUAL Home Screen On startup, the Home Screen will show the DMX Address of the fixture front-and-center with various other settings and monitors displayed around it. Home is designed to provide all relevant and concise fixture information to the user at-a-glance, so you can easily monitor performance The information presented on the Home Screen is only intended as a monitor. -
Page 18: Menu Maps
FLARE XL USER MANUAL MENU MAPS FLARE XL120 18 / 56... -
Page 19: Flare Xl72
FLARE XL USER MANUAL MENU MAPS FLARE XL72 19 / 56... -
Page 20: Flare Xl 36
FLARE XL USER MANUAL MENU MAPS FLARE XL32 20 / 56... -
Page 21: Flare Xl6
FLARE XL USER MANUAL MENU MAPS FLARE XL6 21 / 56... -
Page 22: Menu Settings
FLARE XL USER MANUAL MENU SETTINGS DMX Address Within the Main Menu, highlight <DMX Address> and press Then use to set the desired address (1-512) Press to save the DMX address DMX Source Source options allow you to change how the fixture responds to incoming data and determine what to do if data is lost In the main menu, Highlight <DMX Source>... -
Page 23: Data Loss Action
FLARE XL USER MANUAL Data Loss Action Change how the fixture responds to a data loss event. Data loss action can behave in three different ways: Hold Values – the last frame of DMX data received before loss will be held Blackout –... -
Page 24: Dmx Monitor
FLARE XL USER MANUAL DMX Monitor The <DMX Monitor> is a real-time display of incoming DMX data input The data is arranged in 4 columns, where each box represents a single DMX channel with a DMX Value GREEN DMX Values in are current live values from incoming data DMX Values in... -
Page 25: Recommended
FLARE XL USER MANUAL Recommended The first option in the list of available modes is the <Recommended> mode By default, the recommended mode is a 1-pixel RGBW mode with strobing effects for the first eight channels (more details below) Basic <Basic>... - Page 26 FLARE XL USER MANUAL Strobe Only mode sets the fixture to behave as a generic 4-channel Strobe. In this mode, four channels control the functions of the strobe: Strobe Intensity, Strobe Duration, Strobe Rate and Strobe Effects Strobe intensity, duration and rate are intensity based, where an increase in DMX value is directly proportional to the strobe function STROBE ONLY MODE...
- Page 27 FLARE XL USER MANUAL RGB AND RGBW STROBE MODE CHANNEL DMX VALUE PERCENT FUNCTION 0 - 255 0 - 100 Red Strobe Intensity 0 - 255 0 - 100 Green Strobe Intensity 0 - 255 0 - 100 Blue Strobe Intensity RGB Strobe 0 - 255 0 - 100...
-
Page 28: Advanced Control Modes
FLARE XL USER MANUAL Advanced Control Modes Advanced Mode allows independent control of individual segments of LEDs (AKA pixels). The amount or variety of pixel shapes will be determined by the specific model of Flare XL Within the Control Mode menu, Use to Highlight <Advanced>... -
Page 29: Flare Xl 120 - Pixel Map
FLARE XL USER MANUAL FLARE XL120 PIXEL MODES 29 / 56... -
Page 30: Flare Xl120 Dmx Chart
FLARE XL USER MANUAL FLARE XL120 DMX CHART 30 / 56... - Page 31 FLARE XL USER MANUAL 31 / 56...
- Page 32 FLARE XL USER MANUAL 32 / 56...
- Page 33 FLARE XL USER MANUAL 33 / 56...
- Page 34 FLARE XL USER MANUAL 34 / 56...
-
Page 35: Flare Xl 72 - Pixel Map
FLARE XL USER MANUAL FLARE XL72 PIXEL MODES 35 / 56... - Page 36 FLARE XL USER MANUAL 36 / 56...
-
Page 37: Flare Xl72 Dmx Chart
FLARE XL USER MANUAL FLARE XL72 DMX CHART 37 / 56... - Page 38 FLARE XL USER MANUAL 38 / 56...
- Page 39 FLARE XL USER MANUAL 39 / 56...
- Page 40 FLARE XL USER MANUAL 40 / 56...
-
Page 41: Flare Xl 36 - Pixel Map
FLARE XL USER MANUAL FLARE XL36 PIXEL MODES 41 / 56... -
Page 42: Flare Xl36 Dmx Chart
FLARE XL USER MANUAL FLARE XL36 DMX CHART 42 / 56... - Page 43 FLARE XL USER MANUAL 43 / 56...
-
Page 44: Flare Xl 6 - Pixel Map
FLARE XL USER MANUAL FLARE XL6 PIXEL MODES 44 / 56... -
Page 45: Flare Xl6 Dmx Chart
FLARE XL USER MANUAL FLARE XL6 DMX CHART 45 / 56... -
Page 46: Gamma
FLARE XL USER MANUAL Gamma <Gamma> curve sets a direct relation between AC current to the LEDs and the DMX value. The default value is 3.0. The data is arranged in 4 columns, where each box represents a single DMX channel with a DMX Value to set the gamma curve and press to save Low Value Gamma Curve - when the gamma value is lower,... -
Page 47: Manual Control
FLARE XL USER MANUAL Fan/Power Mode Based on the conditions and needs of the situation, it is possible to choose between from three Fan/Power modes Reducing Fan Speed will have a directly proportional effect on LED output – Silent operation means less total output is available to highlight the desired fan mode and press to select and save Manual Control... -
Page 48: Fan/Power Mode
FLARE XL USER MANUAL Preset The Preset function allows the user to mix color from all 4 RGBW channels manually and independently without a DMX console. These Manual values are saved if power is shut down and only a reset will clear these values. To enable Preset, use to highlight the Preset Mode and press to enter . -
Page 49: Set
FLARE XL USER MANUAL Set allows you to enter custom values to each individual RGBW channel Press the button to highlight a color, then press change the percentage intensity value The Preview window has a top and bottom area. The top area shows the intensity of each color channel while the bottom area reflects the mixed color from all channels When levels are set, press... -
Page 50: Fixture Config
FLARE XL USER MANUAL Fixture Config LCD Dimming In the Fixture Config menu, it is possible to dim the LCD Display Press to enter the LCD Dimming menu and use to highlight to choose between Enabling or disabling the LCD - then press to save Ethernet Config Ethernet Config allows you to change IP Address and Subnet Mask for the network interface... -
Page 51: Supported Rdm Pids
FLARE XL USER MANUAL SUPPORTED RDM PIDS Category - Status Collection 0x0020 QUEUED_MESSAGE Category - RDM Information 0x0050 SUPPORTED_PARAMETERS 0x0051 PARAMETER_DESCRIPTION Category – Product Information 0x0060 DEVICE_INFO 0x0080 DEVICE_MODEL_DESCRIPTION 0x0081 MANUFACTURER_LABEL 0x0082 DEVICE_LABEL 0x0090 FACTORY_DEFAULTS 0x00C0 SOFTWARE_VERSION_LABEL Category - DMX512 Setup 0x00E0 DMX_PERSONALITY 0x00E1... -
Page 52: Cleaning And Maintenance
“Tech Bulletins” and are emailed directly to our customers To check the current firmware version, visit the Flare XL website for more information: https://tmb.com/solaris-flare-xl/ You may also contact TMB directly via email at TechSupport@tmb.com 52 / 56... -
Page 53: Techincal Specifications
FLARE XL USER MANUAL TECHINCAL SPECIFICATIONS Model FLARE XL120 FLARE XL72 FLARE XL36 FLARE XL6 Part Number SFXL120 SFXL72 SFXL36 SFXL6 120 Osram OSTAR stage 30W 72 Osram OSTAR stage 30W 36 Osram OSTAR stage 6 Osram OSTAR stage Light Sources RGBW RGBW 30W RGBW... -
Page 54: Limited Warranty Information
FLARE XL USER MANUAL LIMITED WARRANTY INFORMATION ProPlex Data Distribution Devices are warranted by TMB against defective materials or workmanship for a period of two (2) years from the date of original sale by TMB. TMB’s warranty shall be restricted to the repair or replacement of any part that proves to be defective and for which a claim is submitted to TMB before the expiration of the applicable warranty periods. -
Page 55: Return Procedure
FLARE XL USER MANUAL RETURN PROCEDURE Please contact TMB and request a repair ticket and Return Merchandise Authorization Number prior to shipping items for repair. Be prepared to provide the model number, serial number, and a brief description of the cause for the return as well as the return shipping address and contact information. -
Page 56: Contact Information
CONTACT INFORMATION LOS ANGELES HEADQUARTERS 527 Park Avenue | San Fernando, CA 91340, USA Tel: +1 818.899.8818 | Fax: +1 818.899.8813 sales@tmb.com TMB 24/7 TECH SUPPORT US/Canada: +1.818.794.1286 Toll Free: 1.877.862.3833 (1.877.TMB.DUDE) UK: +44 (0)20.8574.9739 Toll Free: 0800.652.5418 techsupport@tmb.com LOS ANGELES +1 818.899.8818 LONDON +44 (0)20.8574.9700 NEW YORK +1 201.896.8600 BEIJING +86 10.8492.1587...
