Summary of Contents for Solaris SoLED W840
- Page 1 SoLED W840 USER MANUAL PRELIMINARY V4.1...
-
Page 2: Table Of Contents
HERMOMETER 4. APPENDIX ............................17 DMX C ............................. 17 ASICS OF ONTROL ............................17 ENERAL AINTENANCE ............................... 18 IMITED ARRANTY ............................18 ETURN ROCEDURE ............................19 ONTACT NFORMATION ............................. 20 ECHNICAL PECIFICATION SoLED W840 User Manual Version 4.1 051915 PRELIMILARY... -
Page 3: Introduction
1. I NTRODUCTION RODUCT VERVIEW The Solaris LED SoLED W840 white LED strobe offers the same look and feel as xenon strobes at a fraction of ® the power consumption. Using high-intensity Cree LEDs, the SoLED provides ultra-bright whites with 92,000 lumen peak output. -
Page 4: Safety Instructions
1. With a screwdriver turn the fuse cap counter-clockwise to remove fuse cap with fuse. 2. Replace fuse attached to fuse cap. 3. Reinsert fuse cap with new fuse and tighten clockwise. SoLED W840 User Manual Version 4.1 051915 PRELIMILARY... -
Page 5: Fixture Linking
Test cables with an ohm meter to verify correct polarity and to make sure the pins are not grounded or shorted to the shield or each other. SoLED W840 User Manual Version 4.1 051915 PRELIMILARY... -
Page 6: 3-Pin To 5-Pin Conversion Chart
3. Proceed to connect from the fixture output as stated above to the input of the following fixture and so on. 4. Continue linking until the last fixture is connected in your DMX chain. SoLED W840 User Manual Version 4.1 051915 PRELIMILARY... -
Page 7: Fixture Mounting / Rigging
OUNTING IGGING Orientation Solaris LED fixtures may be mounted in any position. Always make sure there is adequate room for ventilation. Do not obstruct the unit’s vents. Support Stand Always use a professional stand rated to support weight greater than the SoLED weight (4.77 lb. / 2.15 kg). - Page 8 During normal operation the control panel LCD display indicates the DMX start address of the SoLED. When the DMX signal is not connected, or if the Solaris LED is not receiving a DMX signal, the SoLED blinks RED. SoLED W840 User Manual Version 4.1 051915...
-
Page 9: Menu Map
Set strobe duration Rate 0-255 Set strobe rate 0-255 Set strobe effects Displays system measurements (input voltage, Measure frequency, temperate, etc.) Thermometer Shows current temperature of device URATION TIME RATE TIME RELATION SoLED W840 User Manual Version 4.1 051915 PRELIMILARY... -
Page 10: Function Description
6) When the new DMX Address is confirmed return to Main Menu. Press < X > button to return fixture at the work state. 7) At work state, control panel display shows current DMX Address, in this case 1. SoLED W840 User Manual Version 4.1 051915 PRELIMILARY... -
Page 11: Strobe Modes
7) At the work state, the control panel display shows current DMX Address, in this case 1. TROBE ODES Three or four channels control strobe parameters: Strobe Intensity Strobe Duration Strobe Rate Strobe FX (only in F4, 4-channel mode) SoLED W840 User Manual Version 4.1 051915 PRELIMILARY... -
Page 12: Effects Descriptions
Random flash: Light flashes randomly at variable rate and intensity. Multiple units flash independently. Lightning: Flashes simulate lightning. Duration is not adjustable. Spikes: Lamp remains dimly illuminated between flashes. Set flash intensity, duration, and rate as normal. SoLED W840 User Manual Version 4.1 051915 PRELIMILARY... -
Page 13: Manual Mode
3) Manual Mode submenu will open. Int (Intensity) Dur (Duration) Rate Eff (Effects, FX) 4) Manual Mode submenu will open. Int (Intensity) Dur (Duration) Rate Eff (Effects(FX) SoLED W840 User Manual Version 4.1 051915 PRELIMILARY... - Page 14 > button once more to exit editing the current value and to lock in the desired value Follow the above steps to edit other values. Press < X > button to exit Manual Mode. SoLED W840 User Manual Version 4.1 051915 PRELIMILARY...
-
Page 15: Measure
2) Use <UP> and <DOWN> buttons to find the Measure submenu and press < > button. Indicated are Input voltage (Uin); frequency (Frq); temperature (T) / power (P); and power limiting (Plim). If SoLED overheats, output power will automatically decrease. SoLED W840 User Manual Version 4.1 051915 PRELIMILARY... -
Page 16: Thermometer
3) To change temperature scale from Celsius to Fahrenheit, press <UP> or <DOWN> buttons. HERMOMETER 1) Press and hold <MENU> button to open the Main Menu. 2) Use <UP> and <DOWN> buttons to find the Thermometer submenu and press select button. SoLED W840 User Manual Version 4.1 051915 PRELIMILARY... -
Page 17: Appendix
Isopropyl Alcohol and a soft lint free cotton cloth or lens tissue. Apply solution to the cloth or tissue and drag dirt and grime to the outside of the lens. Gently polish optical surfaces until they are free of haze and lint. SoLED W840 User Manual Version 4.1 051915 PRELIMILARY... -
Page 18: Limited Warranty
IMITED ARRANTY Solaris LED fixtures (the Product) are warranted by TMB against defective materials or workmanship for a period of two (2) years from the date of original sale by TMB. TMB’s warranty shall be restricted to the repair or replacement of any part that proves to be defective and for which a claim is submitted to TMB before the expiration of the applicable warranty periods. -
Page 19: Ontact Nformation
Fax: +1 818.899.8813 UK Phone: +44 (0)20.8574.9700 Fax: +44 (0)20.8574.9701 e-mail: tmb-info@tmb.com web: www.tmb.com 24/7 TECHNICAL SUPPORT US/Canada: 1 877.TMB.DUDE (+1 877.862.3833) Toll-free UK: 0800.652.5418 International: +1 818.794.1286 e-mail: techsupport@tmb.com IMENSIONAL RAWING SoLED W840 User Manual Version 4.1 051915 PRELIMILARY... -
Page 20: Echnical Pecification
................ L INPUT OCKING MALE SOCKET ............... L OUTPUT OCKING FEMALE SOCKET ..........2 (-), 3 (+), 4 & 5 PIN CONFIG SHIELD PINS WARRANTY INFORMATION ................... 2- ARRANTY YEAR LIMITED WARRANTY SoLED W840 User Manual Version 4.1 051915 PRELIMILARY...
