Position a microphone in front of the speaker cabinet and connect it to Nano Cortex's
CAPTURE INPUT. Nano Cortex's CAPTURE INPUT supports dynamic microphones. Condenser
microphones need an external preamp to be powered.
AMP HEAD (NO SPEAKER)
If you are capturing an ampli er without built-in speakers or just an amp head, connect the
amp's 'Speaker Output' to a Reactive Load Box. Then, connect the Load Box's balanced output
to the Nano Cortex's CAPTURE INPUT.
05
SETUP REVIEW
Once everything is connected correctly, you can proceed with the calibration settings.
