I/Os & General Information

INSTRUMENT INPUT

CONNECTOR:
IMPEDANCE: 1MΩ
MAX INPUT LEVEL:
COMBO CAPTURE INPUT
CONNECTOR:
TS IMPEDANCE:
XLR IMPEDANCE:
MAX INPUT LEVEL:
BOOST GAIN:
TRS OUTPUTS 1L/2R
CONNECTOR:
IMPEDANCE: 560Ω
MAX OUTPUT LEVEL:
HEADPHONES OUTPUT
CONNECTOR:
MAX OUTPUT POWER:
EXP/MIDI INPUTS
EXPRESSION CONNECTOR:
MIDI CONNECTOR:
https://neuraldsp.com/manual/nano-cortex?srsltid=AfmBOops0eFs2xr0dG55hFwinvMw8i88HM5lKcahmGHGNS8iiX-En5BK
1/4 TRS-F
+10dBu
XLR-F + 1/4 TRS-F
1MΩ
45kΩ
+10dBu
+26dB
(2) 1/4 TRS-F
+10dBu (Unbalanced) / +16dBu (Balanced)
3.5MM TRS-F
55mW into 20Ω
1/4 TRS-F
MIDI TRS Type A
