INSTRUCTION MANUAL
IMPORTANT INFORMATION
GB
sure you understand them before using this unit. Retain these instructions for future
reference.
MANUEL D'INSTRUCTIONS
RENSEIGNEMENTS IMPORTANTS:
FR
atentivement les instructions et assurez- -vous de les avoir comprises. Conservez
les instructions pour référence ultérieure.
BETRIEBSANWEISUNG
WICHTIGE INFORMATION:
DE
Geräts aufmerksam durch. Verwenden Sie es erst, wenn Sie sicher sind, daß Sie
alle Anweisungen verstanden haben und gut aufbewahren.
MANUAL DE INSTRUCCIONES
INFORMACIÓN IMPORTANTE:
ES
asegúrese de entenderlas antes de utilizar esta aparato. Conserve las instruc-
ciones para la referencia en el futuro.
LIBRETTO D'ISTRUZIONI
INFORMAZIONI IMPORTANTI
IT
istruzioni e prendere dimestichezza con il prodotto prima di usario. Mantenga
queste istruzioni per riferimento futuro.
HANDLEIDING
BELANGRIJKE IMPORTANTS:
NL
zeker van dat uze begrijpt alvorens de trimmer te gebruiken en bewaar ze voor
toekomstige raadpleging.
Colibrit T210
: Please read these instructions carefully and make
Avant d'utiliser cet appareil, veuillez lire
Lesen Sie diese Hinweise zur Handhabung des
Lea atentamente las instrucciones y
: Siete pregati di leggere attentamente questo
Lees deze instructies zorgvuldig en wees er
530163961
7/23/03
Advertisement
Related Manuals for Electrolux PARTNER Colibri T 210
Summary of Contents for Electrolux PARTNER Colibri T 210
- Page 1 Colibrit T210 INSTRUCTION MANUAL IMPORTANT INFORMATION : Please read these instructions carefully and make sure you understand them before using this unit. Retain these instructions for future reference. MANUEL D’INSTRUCTIONS RENSEIGNEMENTS IMPORTANTS: Avant d’utiliser cet appareil, veuillez lire atentivement les instructions et assurez- -vous de les avoir comprises. Conservez les instructions pour référence ultérieure.
- Page 2 IDENTIFICATION (WHAT IS WHAT?) Fuel tank Assist handle Manual Tube Wrench ON/OFF Switch Throttle Choke Assist handle adjustment Trimmer head Shield Muffler Starter Handle Primer Bulb IDENTIFICATION OF SYMBOLS WARNING! This trimmer can be dangerous! Careless or improper use can cause serious or even fatal injury.
- Page 3 SAFETY RULES S Always wear foot protection. Do not go WARNING: When using gardening barefoot or wear sandals. Stay clear of spinning line. appliances, basic safety precautions should al- S Secure hair above shoulder length. Secure ways be followed to reduce the risk of fire and or remove loose clothing or clothing with serious injury.
- Page 4 CUTTING SAFETY S Store unit and fuel in an area where fuel va- pors cannot reach sparks or open flames WARNING: from water heaters, electric motors or Inspect the area before switches, furnaces, etc. each use. Remove objects (rocks, broken S Store unit so line limiter cannot accidentally glass, nails, wire, etc.) which can be thrown cause injury.
- Page 5 OPERATION Starter Handle WARNING: Be sure to read the fuel information in the safety rules before you be- gin. If you do not understand the safety rules, do not attempt to fuel your unit. Contact an authorized service dealer. FUELING ENGINE Choke Lever WARNING:...
- Page 6 NOTE: CUTTING METHODS If engine has not started, pull starter rope 5 more pulls. If engine still does not run, it WARNING: is probably flooded. Use minimum speed and do not crowd the line when cutting around STARTING A FLOODED ENGINE hard objects (rock, gravel, fence posts, etc.), Flooded engines can be started by placing which can damage the trimmer head, become...
- Page 7 MOWING - - Your trimmer is ideal for mowing SWEEPING - - The fanning action of the rotat- in places conventional lawn mowers cannot ing line can be used for a quick and easy reach. In the mowing position, keep the line clean up.
- Page 8 SERVICE AND ADJUSTMENTS REPLACING THE LINE 10. Pull the line extending outside of the hub to release it from the notch. 1. Move the ON/OFF switch to the OFF position. CARBURETOR ADJUSTMENT 2. Disconnect the spark plug lead wire. 3. Remove spool by firmly pulling on tap but- WARNING: Keep others away when ton.
- Page 9 S Check entire unit for loose screws, nuts, OTHER and bolts. Replace any damaged, broken, S Do not store gasoline from one season to or worn parts. another. S At the beginning of the next season, use S Replace your gasoline can if it starts to rust. only fresh fuel having the proper gasoline to oil ratio.
- Page 10 2000/14/EC EU Declaration of Conformity relating to 2000/14/EC We, Poulan/Weed Eater Division, Electrolux Home Products, Inc., Texarkana, TX, 75501, USA, Tél. : +1 903 223 4100, declare under sole responsibility that the Partner model Colibri T210 grass trimmer was assessed in accordance with Annex V of the DIRECTIVE and from serial numbers 2001- -305N00001 and onwards, conforms to the provisions of the DIRECTIVE.
- Page 11 Racing, dB(A) VIBRATION LEVELS measured in accordance with ISO 7916 FRONT HANDLE Idling, m/s Racing, m/s 13,6 REAR HANDLE Idling, m/s Racing, m/s YEAR OF CONSTRUCTION: 2003 MANUFACTURER’S ADDRESS: Electrolux Home Products, Inc. 250 Bobby Jones Expressway Augusta, GA 30907...
