- Page 1 INSTALLATION wiss adison ® ® INSTRUCTIONS Virage Bathroom Faucet Share your pictures for a feature using #SwissMadison www.swissmadison.com | 1-434-623-4766 | info@swissmadison.com...
- Page 2 Thank you for your purchase! Thank you for purchasing a Swiss Madison Faucet. We appreciate your business and know you will enjoy your faucet for many years to come. If you have any questions or require assistance we would be happy to help, please contact us at 1-434-623-4766 or info@swissmadison.com.
-
Page 3: Parts List
Installation Bolts O-Ring The step-by-step guidelines in the installation instructions are a general reference for installing a Swiss Madison Faucet. Should there be any discrepancies, Swiss Madison cannot be held liable. It is recommended to install all Swiss Madison products by hiring a licensed professional. -
Page 4: Installation Instructions
BATHROOM FAUCET INSTALLATION INSTRUCTIONS 1. Connect Nozzle to Faucet • Slide nozzle hose through faucet. 2. Connect Hose to Faucet • Connect pipe to faucet, then place the O-ring below the faucet. • Place into countertop hole. O-ring Pipe — 3 —... - Page 5 BATHROOM FAUCET INSTALLATION INSTRUCTIONS 3. Secure Faucet to Countertop • Adjust direction of faucet and install U-shaped pads and bolts around inlet pipes. 4. Connect Water Supply • Screw washers and nuts onto pipe. • Connect water supply to hot and cold hose. Turn on and check for leaks. Cold Mixed —...
- Page 6 If you have any questions or concerns, please contact us directly at 1-434-MADISON (623-4766) WARNING: Contents of your order may contain sharp and possibly other harmful pieces and may cause hazard to children and adults. Swiss Madison® is not responsible in any way for personal dam- ages.
