- Page 1 | we si mpli fy c onst r uction Ød LindabSliding dampers SKMTR, SKPTR Assembly instructions...
- Page 2 Sliding dampers SKMTR, SKPTR SKMTR SKPTR Assembly Install the damper as per instructions for straps or flanges. Check that the space before/beyond the damper allows the damper blade to be fully opened. When installing SKPTR with automatic opening and closing function, the risk of personal injury must be considered. The damper must therefore be installed outside any possible contact zone, for example min.
- Page 3 Sliding dampers SKMTR, SKPTR Electrical connection Electrical connection must not be performed before the damper is connected to the pipe system or the pipe connections are covered in some other way. Electricity must be connected by a qualified electrician. Connection must be carried out in accordance with the adjoining diagram.
- Page 4 Sliding dampers SKMTR, SKPTR Control signal from current sensor In a current sensor a circuit is closed when the sensor is activated by a suitable electric current. Via control unit the sole- noid valve is supplied with 230 V when the sensor is activated. The control unit contains a potentiometer where damper closing can be delayed by up to 30 seconds.
- Page 5 Sliding dampers SKMTR, SKPTR Structure of the automatic damper 1. Pneumatic cylinder 2. Rotating angel connection 1/8” – 6 mm hose 3. Hose 6 mm 4. Connection 1/8” – 6 mm hose 5. Magnetic valve 6. Silencer/adjustment 7. Cable terminal 8.
- Page 6 At Lindab, good thinking is a philosophy that gui- des us in everything we do. We have made it our mission to create a healthy indoor climate – and to simplify the construction of sustainable buil- dings. We do that by designing innovative pro- ducts and solutions that are easy to use, as well as offering efficient availability and logistics.
