- Page 1 Orbita Hotel Lock S3074 Installation and User Manual...
- Page 2 CONTENTS 1: Introduction 1: Introduction Thank you for purchasing Orbita Hotel Door Lock S3074. The product is made of grade 304 stainless steel with a PVC card reader cover, with strong 1-1: Product Dimensions resistance to impact, corrosion and abrasion.
- Page 3 L52*W52*D12 mm 1-4: Application Material Grade 304 stainless steel S3074 Lock can be used in hotels, hospitals, schools and apartments, Operating Voltage DC 6V (4 AA dry batteries) which comes with Orbita management system to save time and costs. Operating Power Quiescent current: <...
- Page 4 2: Installation Door Lock Accessories Please refer to the number below for the installation sequence Cylinder Front panel Rear panel Lock body Side trim Striking Striking plate box plate Side trim Lock body Rear panel Cylinder Short Square axis screws fixing screws fixing screws fixing screws...
- Page 5 2. Drill holes using the cardboard cutout provided 5：Install the battery box and the side 6：Install the strike plate and trim panel of the lock body respectively, side plate install 4 batteries on the battery box, insert them into the hole of the battery box, and finally put on the side trim panel of the battery box and the side trim panel of the lock body and lock them with screws.
- Page 6 Solution: A double-locked door can only be opened by the correct guest card and a software and card encoder before use. master card. Please refer to the “Orbita Hotel Lock System Management Software User Manual” for details. Problem: Seven red blinks and seven beeps indicate that the lock has been restricted for opening by a restriction card.
