- Page 1 ORBITA Smart Lock P7027 User Manual v24-01 www.orbitausa.com...
-
Page 2: Product Introduction
1. Product Introduction Table of Contents Thank you for purchasing our products. Orbita P7027 smart lock is made of high- 1：Product Introduction quality aluminum alloy and stainless steel, simple and fashionable. There are 3 door opening methods, including password, APP (Bluetooth 1.1 Appearance... -
Page 3: Technical Specifications
1.2 Features 1.3 Technical Specifications 1. Unlocking methods Password, App (Bluetooth), mechanical key Material high-quality aluminum alloy Operating voltage DC 6V (i.e. 4 dry cells) 2. Password function Child safety lock equipped on the rear panel Set a password of 6 to 10 digits, with fuzzy input supported, that is, inputting an arbitrary number of digits before and after the correct password can also unlock Quiescent current <... -
Page 4: Daily Use And Maintenance
ORBITA Smart Lock 2. Do not operate with wet hands to prevent water, beverages, and other liquids ∅ Depth P7027 User Manual from damaging the electronic components inside the lock. ∅ v24-01 Depth 3. Do not press the number keys on the lock too hard or with sharp objects. -
Page 5: Installation Steps
3. Align the center line of the door side cardboard cutout with that of the door side, 2.2 Installation Steps: and drill the holes. Step 1: Drill holes using the cardboard cutout Door side center (Please skip to Step 2 if having holes drilled already) 1. -
Page 6: Accessory List
Accessory List： Tools Four AA batteries Measure gauge Cross screwdriver Pliers Batter y box cover A-Front panel B-Rear panel C-Rear panel base Rear panel base AA batteries E-Lock body A-Front panel F-Rear panel base G-Front panel D-Lock body screws Rear panel screws studs base screws... - Page 7 Step 4: Align the holes to install the rear panel base (C), and lock it in place with 3 Step 2: Rotate the lock body to adjust its length based on the axle spread of the rear panel base screws (F). door hole, and align the center of the latch center with the center of the door hole.
- Page 8 Step 6: Adjust the rear panel knob to install the rear panel according to the door swing direction. 1. Rotate the knob to the horizontal Left swing: Right swing: 1. Rotate the knob to the vertical direction. direction. 2. Install the rear panel by aligning the 2.
- Page 9 Step 7: Load 4 AA alkaline dry batteries, put on the battery cover, and plug the rear If you want to change the door swing direction again, simply remove one battery, press any buttons on the front panel to ensure the residual power is drained, panel screw holes with rear panel screw plugs (J).
- Page 10 III Operation Guide Enter/Exit Administration Menu Long press " " for 3s, enter admin password according to the voice prompt and press " " to enter the Administration Menu. (Initial admin password: 123456) Long press " " for 3s in any menu can exit. Administration Menu Overview Press the corresponding number before the menu option to access the corresponding menu/function.
- Page 11 3-1 Admin Setting: Delete Admin: Add Admin: (5 administrators can be added) (The only administrator cannot be deleted directly, but can be done by restoring the initial settings.) Long press " " for 3s to enter the initial password "123456" and press "...
-
Page 12: Modify User
3-3 System Setting : Modify User : Automatic lock setting : Long press " " for 3s to enter admin password and press " " to access the Long press " " for 3s to enter admin password and press " "... -
Page 13: Network Setting
3-5. Initialization : 3-4 Network Setting: Network connection (requires APP operation, see P23 in detail) Open the battery cover as shown in the picture below, and press the reset hole, which triggers a voice prompt "Please keep long pressing to initialize the device". Long press "...
