- Page 1 Orbita Hotel Lock E4041A Installation and User Manual...
- Page 2 CONTENTS 1: Introduction 1: Introduction Thank you for purchasing Orbita Hotel Door Lock E4041A. The product is made of grade 304 stainless steel with a PVC card reader cover, with strong 1-1: Product Dimensions resistance to impact, corrosion and abrasion. The door lock PCB is waterproof with stable and reliable quality.
- Page 3 Quiescent current: < 30 μA; dynamic current: < 200 mA Battery Life Provide up to 15,000 operations, and last over one year E4041A Lock can be used in hotels, hospitals, schools and apartments, Temperature: -20 ℃– 60℃; Relative Humidity: 20% – 90% Working Environment which comes with Orbita management system to save time and costs.
- Page 4 2: Installation Door Lock Accessories Please refer to the number below for the installation sequence 3.DOOR Lock body Side trim Striking Striking plate box plate Front panel Rear panel Lock set screw Cylinder Lock body Rear panel Side trim Striking plate fixing screws fixing screws fixing screws...
- Page 5 2. Drill holes using the cardboard cutout provided 6： Install the rectangular shaft and 5：Align the hole position on the front short square shaft. Pay attention to panel and install the from the Cylinder the square shaft One-to-one with screws on rear Lock the Cylinder correspondence with the hole position...
- Page 6 (Note: The card needs to be encoded by the compatible management maintenance card. software and card encoder before use. Please refer to the “Orbita Hotel Lock System Management Software User Manual” Problem: Three red blinks and three beeps indicate that the valid time period of the for details.
