Summary of Contents for SVAGO Motion Mastery SV-701
- Page 1 Motion Mastery SV-701 Use and Care Manual...
- Page 3 TABLE OF CONTENTS IMPORTANT SAFETY INSTRUCTIONS GET READY CHAIR COMPONENTS CHAIR SPECIFICATIONS CHAIR DIMENSIONS 9-11 OPERATION GUIDE CARE AND MAINTENANCE TROUBLESHOOTING 14-15 WARRANTY INFORMATION...
- Page 4 IMPORTANT SAFETY INSTRUCTIONS When using an electrical appliance, basic precautions should always be followed, including the following: READ ALL INSTRUCTIONS BEFORE USING THIS APPLIANCE. DANGER: TO REDUCE THE RISK OF ELECTRICAL SHOCK Always unplug this product from the electrical outlet immediately after using and before cleaning or servicing.
- Page 5 Do not use this product if noise above normal sound is heard. • Do not stand on or in appliance. Use only while seated. • This appliance is not intended for use by persons (including children) with reduced physical, sensory •...
- Page 6 GET READY To set up your chair, refer to the provided Assembly Instructions. To ensure a worry free experience with your chair, follow the suggestions below. CHOOSE A LOCATION Lay a carpet down, or something similar, in the set up location. •...
- Page 7 POSITION THE POWER SUPPLY To avoid any chance of damage to the remote control cord, make sure that after you attach the remote control to the chair connection lead that you run the cord outside of the chair. DO NOT run the cord between the arm rest and back rest.
- Page 8 BATTERY BACKUP SAFETY FEATURE Your chair comes with a battery backup system, which will activate in the event of a power failure (batteries not included). You will need four (4), high-quality, 9V alkaline batteries to power the battery backup system. Replace these batteries after this system has been activated twice. To Install the Batteries: 1.
- Page 9 CHAIR COMPONENTS Headrest Backrest Hand-Held Controller Armrest Dial Footrest...
- Page 10 CHAIR SPECIFICATIONS Specifications Description SV-701 Model No. Rated Voltage 110-120V~ Rated Frequency 60HZ 29VDC 3A Out-Put 1.1A Rated Power Consumption 15 minutes Auto Timer Dimensions (L*W*H) Chair Upright: 32.2" x 33.1" x 44.9" Packing Carton: 44.7" x 35.6" x 34.2" Net weight Weight 150 lbs...
- Page 11 CHAIR DIMENSIONS 72.2” 32.2” 44.9” 33.1”...
- Page 12 OPERATION GUIDE Reset Control Press and hold this button for more than 2 seconds to turn off the chair. Dial Hand Controller RECLINE SIT UP FOOTREST TILT Press & Release HOME Press & Hold MASSAGE HEADREST HEAT MOTION...
- Page 13 1. ON/OFF Press to turn on the chair and the chair will start to work when you press any other function. Press again to stop all the functions and the chair will return to its original position. 2. ZGR Press this button to recline to the preset zero gravity position. Reclining motion can be paused by pressing either the ZGR button, headrest recline/restore button, backrest recline/restore button, seatrest recline/restore button, or the legrest recline/restore button.
- Page 14 6. Lumbar Adust Press and hold the “＞ “ button to inflate the air lumbar until the lumbar support is at your desired height. Press and hold the “＜ “ button to deflate the lumbar air bag, releasing the button will keep it at its current height.
- Page 15 Follow the product label instructions carefully; Svago is not responsible for third-party products. Maintenance and Repair 1.
- Page 16 1. Locate the serial number on the label on the back of your chair, inside the upholstery flap, and write it down. 2. Locate your proof of purchase, as we will need it to process any warranty claim. 3. Now you’re ready to contact us! Contact Customer Service at 844-697-8246 or via email at service@svago.com...
- Page 17 Service And Technical Support • Consumers may contact our customer service department at 844-697-8246 between 9:00 am and 5:30 pm PST, Monday through Friday, email us at service@svago.com, or visit our website at www.svago.com for warranty or service issues. •...
- Page 18 • Parts - All parts deemed necessary for repairs will be shipped to the consumer at no charge by the customer service department. Some product repairs may be performed by the consumer in their own home with parts and instructions supplied by the customer service department, such as remote controller replacements that don‘t require a technician.
- Page 20 TEL: 1-844-697-8246 service@svago.com www.svago.com...
