- Page 1 SV400 Use and Care Manual SvagoManual_Ocean_Cover-未 曲-160918 2016年9⽉22⽇13:56:53...
-
Page 2: Table Of Contents
Thank you for purchasing this Svago ZG-Recliner. To ensure that you don’t overlook any of your chair’s features, and that you use it safely, read this manual carefully. Then sit back, relax, and enjoy! TABLE OF CONTENTS IMPORTANT SAFETY INSTRUCTIONS ......1-2 CHAIR COMPONENTS . -
Page 3: Important Safety Instructions
When using an electrical appliance, basic precautions should always be followed, including the following: DANGER: To reduce the risk of electrical shock , always unplug Svago™ from the electrical outlet immediately after using and before cleaning. WARNING: To reduce the risk of burns, fire, electric shock or injury to persons: •... - Page 4 This plug will fit in a polarized outlet only one way. If the plug does not fit fully in the outlet, reverse the plug. If it still does not fit, contact a quali- fied electrician to install the proper outlet. Do not change the plug in any way. SvagoManual_Ocean_Cover-未 曲-160918 2016年9⽉22⽇13:56:54...
-
Page 5: Chair Components
CHAIR COMPONENTS Head rest Pillow Back rest Lumbar cushion Control Arm rest Seat rest Foot rest Check the accessories first SvagoManual_Ocean_Cover-未 曲-160918 2016年9⽉22⽇13:56:54... -
Page 6: Chair Specifications
CHAIRSPECIFICATIONS Specifications Description Model No. SV400 Rated Voltage In-put 110-120V Rated Frequency 60Hz 24V DC 3A Out-put Rated Power Consumption 15 minutes Auto Timer Chair Upright:43.3”*30.7”*47.5” Dimensions (L*W*H) Chair Reclined:63”*30.7”*30” Packing Carton: 45.3”*31.7”*25.6” Weight Net Weight 99 lbs 117 lbs... -
Page 7: Chair Dimensions
CHAIR DIMENSIONS H: 47.5" L: 43.3" L: 11" L: 35" L: 17" L: 30.7" SvagoManual_Ocean_Cover-未 曲-160918 2016年9⽉22⽇13:57:25... -
Page 8: Placing The Chair
• Do not keep the chair in a place with high humidity like a bathroom. • Do not keep the chair in a place where it will be exposed to direct sunshine for an extended period, or in a place near a heater where the temperature may reaches high levels. SvagoManual_Ocean_Cover-未 曲-160918 2016年9⽉22⽇13:57:25... -
Page 9: Installation
Unfold the headrest frame, fix the latch, and attach the rear fabric cover by Velcro. “L”shaped latch Step 3: After articulating the head rest frame forward, pull up the back pad from the seat, and put it onto the head rest frame. Head rest frame Back pad SvagoManual_Ocean_Cover-未 曲-160918 2016年9⽉22⽇13:57:25... - Page 10 Step 4: Zip up the fastener of the rear cover of back pad. Fastener Rear cover of back pad Step 5: Tidy and attach the seat pad. SvagoManual_Ocean_Cover-未 曲-160918 2016年9⽉22⽇13:57:25...
- Page 11 Step 6 : Attach the pillow to the head rest by the Velcro. Step 7 : Place the lumbar cushion on one seat. Lumbar cushion SvagoManual_Ocean_Cover-未 曲-160918 2016年9⽉22⽇13:57:25...
-
Page 12: Preparations Prior To Use
Check that there is neither breakage or damage to the power adaptor. Check that the cords are not caught or placed beneath the chair. 3. How to connect the power source. 1) Connect the power adaptor with the chair. 2) Insert the power plug into an outlet. SvagoManual_Ocean_Cover-未 曲-160918 2016年9⽉22⽇13:57:26... -
Page 13: Program Operation Guide
When you want to suspend the operation in the middle or have felt some abnormality with your body. Press the on/off button. Operation stops and all the lamps with extinguish. SvagoManual_Ocean_Cover-未 曲-160918 2016年9⽉22⽇13:57:26... - Page 14 • The motion can be stopped by pressing either the ZGR button, or Leg rest Raise/ Lower. • During the leg rest motion, the chair has no response when you press either Back rest Recline/Raise, Heating or Vibration. SvagoManual_Ocean_Cover-未 曲-160918 2016年9⽉22⽇13:57:26...
- Page 15 • Vibration massage will pause during any recline adjustments and will resume auto- matically after adjustments stop. Automatic Shut-off • The Svago has a 15 minute automatic shut-off function. All operations will stop af- ter 15 minutes and can be re-set by pressing any of the function buttons. CAUTIONS - AFTER USE •...
-
Page 16: Maintenance Procedures
• Polyurethane foam padding tends to soften and light creases may form on the leather cover over a period of three months. These are natural occurrences and do not require any type of maintenance. • A professional cleaner should be contacted for particular types of stains such as ink marks. SvagoManual_Ocean_Cover-未 曲-160918 2016年9⽉22⽇13:57:26... -
Page 17: Troubleshooting
If the trouble still persists after following the proper countermeasures,stop using the chair to avoid possible accidents. Disconnect the power plug from the outlet and consult Svago service department. Do not attempt to repair the chair, instead contact a certified technician. -
Page 18: Warranty Information
• Non warrant repair is provided on a ‘per incident’ basis. Svago customer service will verify that the unit has failed and provide instructions for repair. All applicable repairs, parts, shipping, handling, local tax and a ‘... -
Page 19: SvagoManual_Ocean_Cover-未 曲
• Please visit www.cozziausa.com for the latest terms and pricing for extended warranties. PRODUCT REPAIRS • Many Svago parts may be installed by the consumer in his/her own home with parts and instructions supplied by Svago ,such as remote controller replacements that do not require a technician. - Page 20 • Svago’s sole liability and the purchaser’s exclusive remedy shall be for repair, or at Svago’s option, for the replacement of the defective part. Notwithstanding the above, if replacement parts for defective materials are not available, Svago reserves the right to make substitutions in lieu of repair or replacement.
- Page 21 Product Serial No.(Located on product) Purchase Price: Model No: Date Purchased: First Name: Last Name: Address: City: State: Zip Code: Phone: Email: Please mail to: Svago Manufacturing,lnc. 14515 E DON JULIAN RD CITY OF INDUSTRY, CA 91746 Tel:1-877-977-0656 Fax:1-800-521-4712 SvagoManual_Ocean_Cover-未 曲-160918 2016年9⽉22⽇13:57:48...
- Page 22 SvagoManual_Ocean_Cover-未 曲-160918 2016年9⽉22⽇13:57:48...
- Page 23 SvagoManual_Ocean_Cover-未 曲-160918 2016年9⽉22⽇13:57:48...
- Page 24 REDEFINING ZG-RECLINER SvagoManual_Ocean_Cover-未 曲-160918 2016年9⽉22⽇13:57:48...
