- Page 1 SV410 Use and Care Manual SV410- 明 -20160918 2016年9⽉22⽇14:00:07...
-
Page 2: Table Of Contents
Thank you for purchasing this Svago ZG-Recliner. To ensure that you don’t overlook any of your chair’s features,and that you use it safely, read this manual carefully.Then sit back,relax,and enjoy! TABLE OF CONTENTS IMPORTANT SAFETY INSTRUCTIONS ............1-2 CHAIR COMPONENTS ..................3 CHAIR SPECIFICATIONS .................. -
Page 3: Important Safety Instructions
When using an electrical appliance, basic precautions should always be followed, including the following: DANGER: To reduce the risk of electrical shock, always unplug Svago™ from the electrical outlet immediately after using and before cleaning. WARNING: To reduce the risk of burns, fre, electric shock or injury to persons: •... - Page 4 This plug will ft in a polarized outlet only one way. If the plug does not ft fully in the outlet, reverse the plug. If it still does not ft, contact a quali fed electrician to install the proper outlet. Do not change the plug in any way. SV410- 明 -20160918 2016年9⽉22⽇14:00:08...
-
Page 5: Chair Components
CHAIR COMPONENTS Head rest Pillow Back rest Lumbar cushion Arm rest Control Seat rest Foot rest Check the accessories frst SV410- 明 -20160918 2016年9⽉22⽇14:00:08... -
Page 6: Chair Specifications
Required Recline Clearance ℃ ℃ Usage Condition Environmental temperature 10 -40 Contrasting humidity level 30-85RH ℃ ℃ Storage temperature 20 -55 Storage Storage Condition humidity level 30-85RH Equipped with overheating and power Safety Feature surge detectors SV410- 明 -20160918 2016年9⽉22⽇14:00:30... -
Page 7: Chair Dimensions
CHAIR DIMENSIONS H: 47.5" L: 43.3" L: 11" L: 35" L: 17" L: 30.7" SV410- 明 -20160918 2016年9⽉22⽇14:00:30... -
Page 8: Placing The Chair
• Do not keep the chair in a place with high humidity like a bathroom. • Do not keep the chair in a place where it will be exposed to direct sunshine for an extended period, or in a place near a heater where the temperature may reaches high levels. SV410- 明 -20160918 2016年9⽉22⽇14:00:30... -
Page 9: Installation
Unfold the backrest frame, fix the “L” latch, and attach the rear fabric cover by Velcro. Step 3: Connect the power source, press the leg-rest-raise button and lift up the leg rest. Insert the leg frame into the rear pocket of leg-rest cushion.Tidy and attach the seat pad by Velcro. SV410- 明 -20160918 2016年9⽉22⽇14:00:30... - Page 10 Tidy, pull the seat pad to the seat frame as much as possible, align the Velcro and then attach the seat pad. Step 6: Unzip the rear cover of back pad, put it onto the head rest frame, and then zip up. SV410- 明 -20160918 2016年9⽉22⽇14:00:32...
- Page 11 Step 7 : Attach the pillow to the head rest by the Velcro. Step 8 : Place the lumbar cushion on one seat. Lumbar cushion SV410- 明 -20160918 2016年9⽉22⽇14:00:32...
-
Page 12: Preparations Prior To Use
Check that there is neither breakage or damage to the power adaptor. Check that the cords are not caught or placed beneath the chair. 3. How to connect the power source. 1) Connect the power adaptor with the chair. 2) Insert the power plug into an outlet. SV410- 明 -20160918 2016年9⽉22⽇14:00:32... -
Page 13: Program Operation Guide
When you want to suspend the operation in the middle or have felt some abnormality with your body. Press the on/of button. Operation stops and all the lamps with extinguish. SV410- 明 -20160918 2016年9⽉22⽇14:00:32... - Page 14 • The motion can be stopped by pressing either the ZGR button, or Leg rest Raise/ Lower. • During the leg rest motion, the chair has no response when you press either Back rest Recline/Raise, Heating or Air massage. SV410- 明 -20160918 2016年9⽉22⽇14:00:32...
- Page 15 • Air massage will pause during any recline adjustments and will resume auto matically after adjustment stop. Automatic Shut-of • The Svago has a 15 minute automatic shut-of function. All operations will stop af ter 15 minutes and can be re-set by pressing any of the function buttons. CAUTIONS - AFTER USE •...
-
Page 16: Maintenance Procedures
• Polyurethane foam padding tends to soften and light creases may form on the leather cover over a period of three months. These are natural occurrences and do not require any type of maintenance. • A professional cleaner should be contacted for particular types of stains such as ink marks. SV410- 明 -20160918 2016年9⽉22⽇14:00:32... -
Page 17: Troubleshooting
If the trouble still persists after following the proper countermeasures,stop using the chair to avoid possible accidents. Disconnect the power plug from the outlet and consult Svago service department. Do not attempt to repair the chair, instead contact a certifed technician. -
Page 18: Warranty Information
• Non warrant repair is provided on a ‘per incident’ basis. Svago customer service will verify that the unit has failed and provide instructions for repair. All applicable repairs, parts, shipping, handling, local tax and a ‘... - Page 19 • Please visit www.cozziausa.com for the latest terms and pricing for extended warran ties. PRODUCT REPAIRS • Many Svago parts may be installed by the consumer in his/her own home with parts and instructions supplied by Svago ,such as remote controller replacements that do not require a technician.
- Page 20 • Svago’s sole liability and the purchaser’s exclusive remedy shall be for repair, or at Svago’s option, for the replacement of the defective part. Notwithstanding the above, if replacement parts for defective materials are not available, Svago reserves the right to make substitutions in lieu of repair or replacement.
- Page 21 Product Serial No.(Located on product) Purchase Price: Model No: Date Purchased: First Name: Last Name: Address: City: State: Zip Code: Phone: Email: Please mail to: Svago Manufacturing,lnc. 14515 E DON JULIAN RD CITY OF INDUSTRY, CA 91746 Tel:1-877-977-0656 Fax:1-800-521-4712 SV410- 明 -20160918 2016年9⽉22⽇14:00:42...
- Page 22 SV410- 明 -20160918 2016年9⽉22⽇14:00:42...
- Page 23 SV410- 明 -20160918 2016年9⽉22⽇14:00:42...
- Page 24 REDEFINING ZG-RECLINER SV410- 明 -20160918 2016年9⽉22⽇14:00:42...
