Felder FAT 300 Operating Instructions Manual

Height adjustable working table

Hide thumbs Also See for FAT 300:

User manual (20 pages)

User manual (16 pages)

page of 18

/ 18
Bookmarks

Quick Links

Download this manual

FAT 300 / FAT 300 S / FAT 500 S

Aufstellung und Installation

Setup and installation

VIDEO

http://fg.am/fat300install

Keep this manual to hand and in good condition for future reference.

Please read this operating manual carefully before using the machine.

Translation of the original operating instructions

Height adjustable working table

Operating instructions

Download your local language

http://fg.am/ba-manuals

420240-903, 3, en_GB

Need help?

Do you have a question about the FAT 300 and is the answer not in the manual?

Questions and answers

Summary of Contents for Felder FAT 300

Page 1 FAT 300 / FAT 300 S / FAT 500 S Height adjustable working table Aufstellung und Installation Download your local language Setup and installation VIDEO http://fg.am/fat300install http://fg.am/ba-manuals Keep this manual to hand and in good condition for future reference. Please read this operating manual carefully before using the machine.
Page 2 FELDER KG KR-Felder-Straße 1, 6060 Hall in Tirol, AUSTRIA Telephone: +43 5223 5850 0 Email: info@felder-group.com Internet: www.felder-group.com 10.12.2024...
Page 3 Training......Contact Felder-Group service centre..
Page 4 Information about the manual Information about the manual Icon Object description Symbol legend General warnings Safety instructions Safety instructions in this manual are indicated with symbols. The safety instructions are introduced by key words which state in words the extent Warning of electrical voltage of the hazard.
Page 5 FAT 300 / FAT 300 S / FAT 500 S Safety instructions Liability and warranty ● The operator is solely liable for any damage that results from improper use of the machine. ● The contents and instructions in this manual have been compiled in ●...
Page 6 Safety instructions Work safety Exceeding or falling below the permissible ambient temperature If the permissible surrounding temperature is not complied with, malfunc- ● Following the safety advice and instructions given in this manual tions and unpredictable machine movements may occur. This can lead to can prevent bodily injury and material damage while working on serious personal injury and damage to property.
Page 7 FAT 300 / FAT 300 S / FAT 500 S Safety instructions ● Only use technically perfect spare parts. ● See spare parts list.
Page 8 Brand Felder Model type FAT 300 / FAT 300 S / FAT 500 S The following EU guidelines were applied 2006/42/EC This EU-Declaration of Conformity is valid only if the CE label has been affixed to the machine. Modifying or altering the machine without the express written agreement of the manufacturer shall render the warranty null and void.
Page 9 FAT 300 / FAT 300 S / FAT 500 S Declaration of Conformity UKCA - Declaration of Conformity Declaration of Conformity according to UK Directive S.I. 2008/1597 Note on the serial number: The serial number is printed on the cover sheet of the operating manual.
Page 10 Min. transport width Working height E1 (Position: below) approx. Approx. weight *) Load capacity H (max.) *) without worktop Net weight approx. *) FAT 300 S packaging Weight - worktop Data Value Unit *) Standard equipment is without worktop Length...
Page 11 FAT 300 / FAT 300 S / FAT 500 S Transporting, packing, storing *) without worktop Observe max. load capacity Crush risk to hands Crush risk to feet Operation and storage conditions Machine data plate Data Value Unit Information on the machine data plate...
Page 12 Setup and installation Loosen the hexagon socket screws on the front and rear. Remove transport bracket Remove the transport brackets from the front and rear. FAT 300 Self-assembly Assembly and commissioning: See individual assembly instructions WARNING Improper transport Severe crushing due to falling or tipping loads −...
Page 13 FAT 300 / FAT 300 S / FAT 500 S Operate Mount the worktop / tilt device following the installation instruc- tions. FAT 300 S / 500 S Personnel: ● Trained machine operator Tool: ● Pallet jack ● Ring spanner 13 mm ●...
Page 14 �� The working table lowers. (wedging threat). Panel tilting device for the machine table The FAT 300 S and 500 S models can be equipped with an panel tilting device for the handling of large dimensioned panels. NOTICE Exceeding the maximum loading capacity Danger of tipping −...
Page 15 FAT 300 / FAT 300 S / FAT 500 S Maintenance Maintenance Maintenance schedule Chap. If required Page Clean table Clean the castor rollers Clean table Clean the castor rollers NOTICE NOTICE Lifting cylinder improperly maintained Caustic or abrasive cleaning detergents The lifting cylinder is completely maintenance free.
Page 16 Disposal Troubleshooting Spare part orders 10.1 What to do in the event of malfunction WARNING Improper troubleshooting Severe injuries and damage to property − Troubleshooting may only be carried out by authorised, trained personnel who are familiar with how to operate the working table and are in strict observance of all safety instructions.
