HUBER+SUHNER ODR 900S Installation Manual

INSTALLATION
MANUAL
Tray Unit Horizontal
Table of contents
• INSTALLATION OF A TRAY UNIT ..................................................... 1
INSTALLATION OF A TRAY UNIT
Scope of delivery:
Tray unit
Required tools:
Torx socket wrench T-30, long bar
Step 1 ODR 900S:
For bottom cable entry start with the tray units at the top
(see left picture); for top cable entry start with the fiber
trays at the bottom (see right picture).
ODR 600S:
HUBER+SUHNER disclaims any liability resulting from incorrect installation and use, including any damages resulting from the use of tools and
accessories other than the ones recommended herein. Any installation performed by unqualified personnel voids the product warranty provided by
HUBER+SUHNER. All due care and attention must be exercised when performing the installation of these products. For advice concerning the
general handling of these products please contact HUBER+SUHNER.
HUBER+SUHNER AG
Fiber Optics
Fiber Management Systems
DOC-0000236411 Rev B
Date: 09/09/2016
Page 1 of 3
