Living Spaces CROWN MARK B6560-1 Assembly Instructions

THANK YOU FOR PURCHASING THIS QUALITY PRODUCT.BE SURE TO CHECK ALL PACKING MATERIAL CAREFULLY FOR
SMALL PARTS WHICH MAY HAVE COME LOOSE INSIDE THE CARTON DURING SHIPMENT.IDENTIFY AND COUNT ALL
PARTS AND COMPARE WITH HARDWARE LIST AS BELOW :
(BOX 1)BOX OF DRESSER
QTY
DESCRIPTION
ITEM DRAWING
A 1
DRESSER
4
B
BOTTOM LEG
1
C
SUPPORT LEG
(BOX 1) BOX OF DRESSER (HARDWARE LIST)
ITEM DRAWING
DESCRIPTION
D
ALLEN KEY M4
CONNECTION BOLT
(M6x100mm)
E
W/SPRING WASHER &
WASHER MEDIUM
ANTI TIPPING RESTRAINT
F
(Located in Dresser 1st RSF Drawer)
NOTE:MUST TIGHTEN SCREW PERIODICALLY.WITH USE SCREWS WILL
BECOME LOOSE CHECK THIGHT OF ALL SREWS EVERY 6-8 WEEKS.
CLEANING INSTRUCTION
After assembled,clean & polish the complete parts if necessary with soft clotch ang industrial recognized furniture polish.
ASSEMBLY INSTRUCTIONS
CROWN MARK (CRWN)
MODEL:B6560-1 DRESSER
STEP 1 :ATTACH AND TIGHTEN THE DRESSER BOTTOM LEG (B)
TO THE BOTTOM FRAME AND INSERT CONNECTION BOLT (E)
WITH WASHER AS SHOWN.
DIMENSION QTY
1
M4x55MM
4
1
D
E
4x
THE ANTI TIPPING HARDWARE IS LOCATED IN THE 1ST RIGHT SIDE
FRONT DRAWER OF DRESSER
THE HARDWARE IS LOCATED IN THE PACKING ITEMS
B
A
STEP 1:
STEP 2 : Move the Dresser
(A) into final position and
use tipping restraint (F)
attach to wall
C
F
WALL
COMPLETED
ASSEMBLY
