Installation, Maintenance, and Upgrade
Install, Remove, and Replace the Network Module
You can remove and replace the network module in the Firepower 2130 and 2140 (the Firepower 2110 and
2120 do not support network modules). Although the hardware supports removing and replacing the network
module while the system is running, the software does not currently support hot swapping. You must power
down the chassis to remove and replace network modules. See
This procedure describes how to install a network module into an empty slot that has never contained a network
module, and how to remove an installed network module and replace it with another network module.
Safety Warnings
Warning
Install, Remove, and Replace the Network Module, on page 1
Remove and Replace the SSD, on page 3
Remove and Replace the Power Supply Module, on page 6
Connect the DC Power Supply Module, on page 9
Secure the Power Cord on the Power Supply Module, on page 13
Remove and Replace the Fan Tray, on page 17
Install the FIPS Opacity Shield in a Two-Post Rack, on page 19
Install the FIPS Opacity Shield in a Four-Post Rack, on page 23
Take note of the following component replacement safety warnings:
Statement 1028 More Than One Power Supply
This unit might have more than one power supply connection. To reduce risk of electric shock, remove
all connections to de-energize the unit.
Network Modules
for more information.
Installation, Maintenance, and Upgrade
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the Firepower 2140 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Cisco Firepower 2140

  • Page 1 Installation, Maintenance, and Upgrade • Install, Remove, and Replace the Network Module, on page 1 • Remove and Replace the SSD, on page 3 • Remove and Replace the Power Supply Module, on page 6 • Connect the DC Power Supply Module, on page 9 •...
  • Page 2 Installation, Maintenance, and Upgrade Install, Remove, and Replace the Network Module Warning Statement 1073 No User-Serviceable Parts There are no serviceable parts inside. To avoid risk of electric shock, do not open. Warning Statement 1089 Instructed and Skilled Person Definitions An instructed person is someone who has been instructed and trained by a skilled person and takes the necessary precautions when working with equipment.
  • Page 3 Installation, Maintenance, and Upgrade Remove and Replace the SSD Figure 1: Remove the Network Module If the slot is to remain empty, install a blank faceplate to ensure proper airflow and to keep dust out of the chassis; otherwise, install another network module. Step 4 To replace a network module, hold the network module in front of the network module slot on the right of the chassis and pull the network module handle out.
  • Page 4 Installation, Maintenance, and Upgrade Remove and Replace the SSD Note We may ship larger capacity SSDs depending on component supply availability. The larger capacity SSDs are formatted to 100-GB for the Firepower 2110 and 2120 and formatted to 200-GB for the Firepower 2130 and 2140.
  • Page 5 Installation, Maintenance, and Upgrade Remove and Replace the SSD Warning Statement 1090 Installation by Skilled Person Only a skilled person should be allowed to install, replace, or service this equipment. See statement 1089 for the definition of a skilled person. There are no serviceable parts inside.
  • Page 6 Installation, Maintenance, and Upgrade Remove and Replace the Power Supply Module Step 4 To replace the SSD in slot 1, make sure the power switch is still in the OFF position, and then hold the SSD in front of slot 1 and push it in gently until it is seated. Step 5 To install the MSP SSD, make sure the power switch is still in the OFF position, and then remove the blank faceplate in Slot 2 by loosening the captive screws on either side of the faceplate.
  • Page 7 Installation, Maintenance, and Upgrade Remove and Replace the Power Supply Module Warning Statement 1022 Disconnect Device To reduce the risk of electric shock and fire, a readily accessible disconnect device must be incorporated in the fixed wiring. Warning Statement 1028 More Than One Power Supply This unit might have more than one power supply connection.
  • Page 8 Installation, Maintenance, and Upgrade Remove and Replace the Power Supply Module Warning Statement 1090 Installation by Skilled Person Only a skilled person should be allowed to install, replace, or service this equipment. See statement 1089 for the definition of a skilled person. There are no serviceable parts inside.
  • Page 9 Installation, Maintenance, and Upgrade Connect the DC Power Supply Module Power supply module latch Power supply module 2 If the slot is to remain empty, install a blank faceplate to ensure proper airflow and to keep dust out of the chassis; otherwise, install another power supply module.
  • Page 10 Installation, Maintenance, and Upgrade Connect the DC Power Supply Module DC power connector Ejector latch Safety Warnings Take note of the following warnings: Warning Statement 1003 DC Power Disconnection To reduce risk of electric shock or personal injury, disconnect DC power before removing or replacing components or performing upgrades.
  • Page 11 Installation, Maintenance, and Upgrade Connect the DC Power Supply Module Warning Statement 1029 Blank Faceplates and Cover Panels Blank faceplates and cover panels serve three important functions: they reduce the risk of electric shock and fire, they contain electromagnetic interference (EMI) that might disrupt other equipment, and they direct the flow of cooling air through the chassis.
  • Page 12 Installation, Maintenance, and Upgrade Connect the DC Power Supply Module Before you begin • The color coding of the DC input power supply leads depends on the color coding of the DC power source at your site. Make sure that the lead color coding you choose for the DC input power supply matches the lead color coding used at the DC power source and verify that the power source is connected to the negative (–) terminal and to the positive (+) terminal on the power supply.
  • Page 13 Installation, Maintenance, and Upgrade Secure the Power Cord on the Power Supply Module Figure 6: Tighten the Terminal Block Captive Screws Negative (-) lead wire Positive (+) lead wire Step 6 Repeat these steps for the remaining DC input power source wire as applicable. Step 7 Use a tie wrap to secure the wires to the rack, so that the wires are not pulled from the terminal block.
  • Page 14 Installation, Maintenance, and Upgrade Secure the Power Cord on the Power Supply Module Warning Statement 1028 More Than One Power Supply This unit might have more than one power supply connection. To reduce risk of electric shock, remove all connections to de-energize the unit. Warning Statement 1073 No User-Serviceable Parts There are no serviceable parts inside.
  • Page 15 Installation, Maintenance, and Upgrade Secure the Power Cord on the Power Supply Module Procedure Step 1 Attach the clamp to the tie wrap by holding the clamp with the loop side on the bottom and sliding the tie wrap through the box-shaped channel above the clamp (see the following figure).
  • Page 16 Installation, Maintenance, and Upgrade Secure the Power Cord on the Power Supply Module Figure 8: Connect the Tie Wrap Tie wrap Hexagonal hole Step 3 Secure the clamp: a) Plug in the power supply power cord and wrap the clamp around the over mold portion of the power cord. b) Squeeze the clamp tabs together so that the annular teeth engage with the mate on the clamp.
  • Page 17 Installation, Maintenance, and Upgrade Remove and Replace the Fan Tray Clamp release tabs — Step 4 If you need to remove the power cord, push the release tab on the clamp to force the annular clamp teeth to disengage and the clamp opens up. You can then remove the clamp from the power cord. Remove and Replace the Fan Tray You can remove and replace the fan tray while the Firepower 2130 and 2140 are running (the Firepower 2110 and 2120 have two fixed fans).
  • Page 18 Installation, Maintenance, and Upgrade Remove and Replace the Fan Tray Warning Statement 1089 Instructed and Skilled Person Definitions An instructed person is someone who has been instructed and trained by a skilled person and takes the necessary precautions when working with equipment. A skilled person or qualified personnel is someone who has training or experience in the equipment technology and understands potential hazards when working with equipment.
  • Page 19 Note Because the FIPS opacity shield covers the serial number on the chassis, the Crypto Officer (CO) should copy the serial number and store it in a secure place. The serial number is needed when you call Cisco TAC. Caution This procedure should be performed only by the CO.
  • Page 20 Installation, Maintenance, and Upgrade Install the FIPS Opacity Shield in a Two-Post Rack Note The TELs are made of a special thin gauge vinyl with self-adhesive backing. Once the CO attaches them on the chassis, any attempt to open the chassis damages the TELs or the chassis cover.
  • Page 21 Installation, Maintenance, and Upgrade Install the FIPS Opacity Shield in a Two-Post Rack Figure 11: Route the Cables and Attach the Screws FIPS opacity shield 8-32 x 0.375-inch Phillips screws (two per side) Cable management bracket — Step 6 Before you attach the TELs, clean the chassis and FIPS cover of any grease, dirt, or oil with alcohol-based cleaning pads.
  • Page 22 Installation, Maintenance, and Upgrade Install the FIPS Opacity Shield in a Two-Post Rack Figure 12: TELs Placement on the Chassis TEL 1 on the left side and top of chassis TEL 2 on the right side and top of chassis TEL 3 on the top and back of chassis TEL 4 across the FIPS shield and the chassis (towards the left of the chassis)
  • Page 23 Because the FIPS opacity shield covers the serial number on the chassis, the CO should copy the serial number and store it in a secure place. The serial number is needed when you call Cisco TAC. You need the following to install the FIPS opacity shield: •...
  • Page 24 Installation, Maintenance, and Upgrade Install the FIPS Opacity Shield in a Four-Post Rack to turn the power off on the appliance, remove the cables, route the cables through the cable mounting brackets, reattach the cables, and continue with Step 5 below. Note When you toggle the power switch from ON to OFF, it takes several seconds for the system to power down.
  • Page 25 Installation, Maintenance, and Upgrade Install the FIPS Opacity Shield in a Four-Post Rack Figure 14: TELs Placement on the Chassis TEL 1 on the left side and top of chassis TEL 2 on the right side and top of chassis TEL 3 on the top and back of chassis TEL 4 across the FIPS shield and the chassis (towards the left of the chassis)
  • Page 26 Installation, Maintenance, and Upgrade Install the FIPS Opacity Shield in a Four-Post Rack What to do next See the Cisco Firepower 2100 Getting Started Guide for your operating system for further configuration information. Installation, Maintenance, and Upgrade...
