Pioneer C-72 Operating Instructions Manual

Operating
Instructions
STEREO CONTROL AMPLIFIER
Thank you for buying this Pioneer product.
Please read through these operating instructions so you will know how
to operate your model properly. After you have finished reading the
instructions, put them away in a safe place for future reference.
in some countries or regions, the shape of the power plug and power
outlet may sometimes differ from that shown in the explanatory
drawings. However, the method of connecting and operating the unit
SD
is the same. &
WARNING: to prevent FIRE OR SHOCK HAZARD, DO
NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
IMPORTANT NOTICE
[For U.S. and Canadian models]
The serial number for this equipment is located on the rear panel. Please
write this serial number on your enclosed warranty card and keep it in
a secure area. This is for your security.
[For Canadian model]
CAUTION: to prevent ELECTRIC SHOCK DO NOT USE
THIS (POLARIZED) PLUG WITH AN EXTENSION CORD, RECEPTACLE
OR OTHER OUTLET UNLESS THE BLADES CAN BE FULLY INSERTED
TO PREVENT BLADE EXPOSURE.
ATTENTION: pour prevenir tes cHocs ELECTRIQUES
NE PAS UTILISER CETTE FICHE POLARISEE AVEC UN
PROLONGATEUR UNE PRISE DE COURANT OU UNE AUTRE SORTIE
DE COURANT, SAUF SI LES LAMES PEUVENT ETRE INSEREES A
FOND SANS EN LAISSER AUCUNE PARTIE A DECOUVERT.
BEFORE USING THE UNIT
FEATURES .............2eceee
PRECAUTIONS DURING USE
CONNECTIONS
HOW TO USE THE PROGRAMMABLE (LEARNING)
REMOTE CONTROLIUNUP s:csievs.asscnasesvevenerenssaere ct eceeveds i}
oR Aw
CONTENTS
LINE VOLTAGE SELECTOR SWITCHES
Only multi voltage models are provided with these switches, U.S.,
Canadian, European, U.i.,and Australian models are not provided with
this switch.
Mains voltages in Saudi Arabia are 127 V and 220 V only. Never use
this model with 110 V setting in Saudi Arabia..
Before your model is shipped from the factory, these switches are set
to the power requirements of the destination. Nevertheless, you should
check that they are set properly before plugging the power cord into
the AC outlet.
1. Disconnect the power cord.
2. Use a medium-size screwdriver.
3. Insert the screwdriver into the groove on the voltage selectors and
adjust so that the tip of the arrow points to the voltage value of your
area.
NOTE:
Both switches must be in the same switch setting; otherwise, unit can
be damaged.
VOLTAGE SELECTORS:
PANEL FACILITIES
OPERATIONS 1 (Basic Operation)
OPERATIONS 2 (Applications) .
TROUBLESHOOTING '
SPECIFICATIONS: sis aaiceessavsieassssrsesiavsavnuassaeseaseeauatvoeaaves
YQ) PIONEER'
The future of sound and vision.
