  • Page 1 Mounting AME 900 F...
  • Page 2 2024-12-05 First edition NOTICE Read this manual thoroughly before mounting the AME 900 F unit. Please keep it for later use. Manuals must be given to the owner of the unit for safekeeping. Fill out this form for future reference:...
  • Page 3 Table of content Introduction ..................................5 Target group ................................5 Warning symbols ..............................5 Liability ..................................6 Safety instructions ................................7 Responsibility ................................8 2.1.1 Personnel requirements ..........................8 Product identification ..............................9 Product name and type ............................9 Specifications ................................9 Manufacturer ................................
  • Page 4 Figure 2: Obstacles can create unwanted flow directions - illustrative example only ............12 Figure 3: Dimensional drawing [in mm], top of AME 900 F unit ................... 14 Figure 4: Place laths/battens/blocks of wood before lifting the unit ..................15 Figure 5: Move the unit into place ............................
  • Page 5 1 Introduction This manual will instruct you on how to mount the AME 900 F unit correctly and safely. Mounting and installing an AME 900 F is divided into two parts: Mounting the unit and securing it to the wall (this manual).
  • Page 6 CAUTION Wear safety footwear as personal protection equipment. NOTICE Failure to comply with the instructions can damage the device and its environment. Information, tips, and recommendations. 1.3 Liability The manufacturer cannot be held liable for damages due to usage violating this manual’s instructions. The manufacturer reserves the right to make changes without notice.
  • Page 7 2 Safety instructions Breaching the instructions marked with a warning symbol carries a risk of personal injury or material damage. WARNING The unit must not be installed in explosion-protected rooms. • The unit must not be installed in rooms with flammable or corrosive gas in the air. •...
  • Page 8 • wall/ceiling (e.g. vapor barrier) are restored and fully functional once the unit has been installed. 2.1.1 Personnel requirements Mounting the AME 900 F unit must be done by qualified personnel. Laypersons should not attempt to mount the unit. 8/24...
  • Page 9 Duct connection Ø315 mm Color: casing RAL 9010 Table 2: AME 900 F specifications Please refer to the AME 900 F datasheet for further information. The datasheet is available on our website. 3.3 Manufacturer Airmaster A/S Industrivej 59 9600 Aars...
  • Page 10 4 Transportation and storage The AME 900 F is packed on a pallet. Each pallet contains one unit. The pallet must be tied up during transport so it will not move or shift. Make sure that it is not dropped or otherwise damaged during handling.
  • Page 11 5 Important information before you mount the unit Read the instructions in this chapter carefully before you begin. WARNING The floor and walls in the room where the unit is mounted must be even and leveled. • Minimum ceiling height is 2300 mm (see section 3.2). •...
  • Page 12 Figure 2: Obstacles can create unwanted flow directions - illustrative example only 5.2 Tools and accessories Before you start mounting the AME 900 F unit you need the following tools and accessories: • Lifting equipment appropriate for the unit weight (min. 290 kg), e.g., a pallet loader.
  • Page 13 5.3 Unpacking The scope of delivery can be seen from the delivery note; however, a general list of parts is listed below: • AME 900 F unit Airlinq ® Orbit control panel (option) • • Condensate drain hose (option, included if the condensate pump is selected as an option) Duct pipes, grilles, vapor barrier (options) •...
  • Page 14 When drilling the duct holes make sure you have the correct gradient as well as size, see the Information Box on page 11. A section of the dimensional drawing depicting the top of the AME 900 F unit can be seen below. Please refer to the Dimensional drawing in Appendix A for further information.
  • Page 15 6.2 Mount the unit Before lifting the unit into an upright position place some laths/battens/blocks of wood as depicted in Figure 4. Without this, the height-adjustable feet may break or deform once the unit is lifted. Make sure the feet are as short as possible.
  • Page 16 CAUTION Be careful when moving the unit on the pallet loader. If the unit tilts over it can cause injury to persons and damage the unit. Adjust the feet to make the unit level, see Figure 6 below. Figure 6: Adjust the feet to level the unit Attach the brackets on top of the unit to the wall using screws applicable to the material of the wall.
  • Page 17 6.3 Mount duct pipes and grilles Please note that this section and the following subsection provide a general description of fitting the ducting and subsequent sealing. Materials and methods for fitting the ducting depend on the customer’s order, the options chosen, and the actual site, hence we can only provide general guidance on this matter.
  • Page 18 6.4 Condensate drainage (option) Depending on the options chosen, the AME 900 F may be fitted with a condensate pump and a condensate hose. Please note that this section provides general information about condensate drainage. We can only provide general guidance as drainage connections depend on the actual site.
  • Page 19 Figure 10: Water trap to avoid odors The drainage hose can also be led through the outer wall; when doing so, the hose must be protected against the formation of ice. If you wish to lead the drainage hose through the wall drill a hole with a suitable diameter and an outwardly sloping gradient of 1-2%.
  • Page 20 Appendix A Dimensional drawing 20/24...
  • Page 21 - This page is intentionally left blank -...
  • Page 22 - This page is intentionally left blank -...
  • Page 23 - This page is intentionally left blank -...
  • Page 24 Airmaster A/S +45 98 62 48 22 Industrivej 59 info@airmaster.dk 9600 Aars Denmark www.airmaster 16101_REV01_2024-12-05 Errors and omissions excepted. Subject to change without notice. Original user instruction.
