2024-02-08 First edition NOTICE Read this manual thoroughly before using and maintaining the AMX 4 unit. Keep it for later use. Manuals must be given to the owner of the unit for safekeeping. Fill out this form for future reference:...
2 Introduction This manual will give you instructions on how to operate and maintain the AMX 4 unit correctly and safely. Besides this manual, two other manuals providing instructions on mounting and installation are available. All three manuals are part of the delivery. All manuals can also be downloaded from our website, see section 4.4.
CAUTION Wear safety footwear as personal protection equipment. CAUTION Wear eye protection as personal protection equipment. CAUTION Wear protective gloves as personal protection equipment. CAUTION Wear a face mask as personal protection equipment. NOTICE Failure to comply with the instructions can damage the device and/or its environment. Information, tips, and recommendations.
Be aware that refrigerants may not contain an odor. • WARNING Electrical work on the AMX 4 may only be carried out by an authorized electrician or by Airmaster A/S. WARNING Repair must be performed by authorized experts. Contact Airmaster A/S or your local representative.
Maintenance tasks according to the instructions in this manual can be performed by the owner, however, service, repair, or improvements must be performed by authorized experts. Contact Airmaster A/S or your local representative. 3.1.1 Personnel requirements Laypersons should not attempt to perform maintenance on the AMX 4 unit. 9/40...
4.2 Intended use AMX 4 is a decentralized room-based air handling unit. The unit is used in office environments and modular buildings accessible to the general public where it provides ventilation, cooling, and heating – all in the same unit.
55% or ePM Extract air filter, fine Supply air filter, coarse ISO Coarse 30% (PPI) Table 3: Filter class Please contact Airmaster A/S or your local representative for purchase and further information. 4.4 Manufacturer Airmaster A/S Industrivej 59 9600 Aars...
Go to ‘App Store’ or ‘Google Play’ and download the ‘Airlinq’ app from Airmaster, see Figure 2 below. Figure 2: Airlinq app Once you have downloaded the app you need to connect to your AMX 4 unit. To do so, you need the 4-digit code connected to your unit.
Enable Bluetooth on your device. Open the app. It quickly displays the Airmaster logo and then displays the screen where you can enter the code, see Figure 4. Figure 4: Enter the unit code Enter the 4-digit code from your unit.
If you wish to turn the unit off or put it in standby mode, you can do so by pressing the ‘power’ icon in the upper right corner of the screen. Each of the options will be described further in the following sections. 5.1.1 ‘Home’...
Until the new room temperature is reached, the display in the middle will show the current room temperature, this way you can keep track of the temperature. 5.1.1.2 Ventilation If you wish to alter the ventilation flow, press the ‘fan’ icon in the middle, this will display the current airflow, see Figure 8 below.
Please note, that the AMX 4 unit prevents situations where conflicting interests occur, e.g. setting the room temperature very low and at the same time setting the airflow to a minimum – it is impossible to lower the room temperature by many degrees if the flow of air is at a minimum.
TVOC are defined during unit setup. If you wish to change the limits for CO and TVOC please use Airlinq ® Online, not the app. 5.1.2 ‘Business card’ icon The ‘Business card’ icon provides contact details for Airmaster support as well as terms and conditions. Figure 13: Contact details 17/40...
AMX 4 unit. Figure 15: Tools icon - Service After replacing the filters you need to reset the filter service. Information on how to replace filters in the AMX 4 unit is provided in section 9.2 on page 26. 18/40...
5.2 Airlinq ® Online Airlinq Online is a professional web portal for Airmaster units connected to Ethernet. It is designed to control, monitor, ® and manage ventilation solutions for one or more installations. Airlinq ® Online is optional and can be used together with or instead of the Airlinq ®...
6 LED signals The AMX 4 is equipped with an LED to display the operational status of the unit. The LED is located to the rear on the right-hand side of the unit. Color Light Status Meaning Constant In operation...
7 Control functions The AMX 4 unit combines ventilation and recirculation with heating or cooling: Ventilation + cooling • • Ventilation + heating Recirculation + cooling • Recirculation + heating • Internal control functions run automatically and influence airflow and inlet temperature.
8 Adjusting the inlet air slats You can adjust the inlet air throw (length) and dispersion by adjusting the slats. The slats are located behind the louvers, see Figure 17 below. Figure 17: Inlet air slats (front side of the unit) By changing the slat angles you can change the throw and dispersion of the air, see general examples below: Standard dispersion and throw Reduced dispersion resulting in a longer throw...
Use long-nosed pliers to adjust the slats, however, be careful, it is only possible to bend the slats a few times, otherwise, they can break off. Please follow the guidelines below for adjusting the slats. • Standard factory setting at 45 angle dispersion looks like this: Figure 19: Slats 45 degrees angle reduced dispersion and long throw.
• Wide angle dispersion and shorter throw. The outer slats on both sides are at a lower angle than the ones in the middle: Figure 21: Wide-angle slats Asymmetrical throw. One of the sides has a lower slat angle than the other to create asymmetry: •...
Refer to section 9.3.3 for further details. All filters in the AMX 4 unit are monitored by the unit’s filter monitoring system. Replace the filters whenever the monitoring system indicates that a filter must be replaced, but a minimum every 14 months.
All filters must be replaced, do not try to wash or vacuum them. The AMX 4 unit has two filters on the supply side and two filters on the exhaust side. Each side has a fine filter and a coarse filter.
9.2.1 Replace the exhaust air filters Open the service cover on the right-hand side of the unit. Use the service cover key included in the delivery. See Figure 23 below. Open the filter hatch, see Figure 24. Figure 23: Open the service cover Figure 24: Open the filter hatch 27/40...
Open the hinges that keep the coarse filter in place, see Figure 25 below. Figure 25: Open the hinges holding the coarse filter Take the filter out and replace it with a new one, see Figure 26 and Figure 27. Figure 26: Take the coarse filter out 28/40...
Open the hinge that keeps the fine filter in place, see Figure 29 below. Figure 29: Open the hinge that keeps the fine filter in place Take the filter out and replace it with a new one, see Figure 30 and Figure 31. Figure 30: Take the fine filter out 30/40...
Figure 31: Replace the fine filter with a new one The fine filter has an arrow marking on the bottom, this arrow should point toward the middle part of the unit. Close the filter hinge, see Figure 32. 31/40...
10. Close the service cover, see Figure 34. Figure 34: Close the service cover This completes the exhaust filter replacement. Proceed to replace the filters on the supply air side, see the next section for details. 33/40...
9.2.2 Replace the supply air filters Follow the instructions provided in section 9.2.1, ‘’Replace the exhaust air filters’’, this time on the left-hand side of the unit. See Figure 35, Figure 36, and Table 6. Figure 35: Open the service cover and the filter hatch Figure 36: Replace the supply air filters Coarse filter Fine filter...
9.2.3 Reset service (after filter replacement) The default code for resetting the filter service = 9732. See section 5.1.4 on page 18 for information on how this is done in the Airlinq ® app. You can also reset the filter service via Airlinq Online.
9.3.3 Condensate system CAUTION The unit must be switched off and disconnected from the mains before the service covers are opened. Make sure nobody turns the power on (prevent use). To gain access to the condensate system you need to remove the service covers as well as the bottom steel plates, please refer to section 7 in the mounting manual.
To inspect the condensate pumps in the middle tray you must switch the power on briefly and check that the water is pumped out and that no leaks appeared. 9.4 Service/Repair For service or repair, please call Airmaster A/S or your local representative. Contact information for Airmaster is available in section 4.4 on page 11. 37/40...
10 Dismantling and disposal 10.1 Dismantling If you need to dismantle the AMX 4 unit follow the instructions in the Mounting manual and the Installation manual in reverse order. Mounting manual: section 7 • • Installation manual: section 7 and section 8.
Industrivej 59 9600 Aars Denmark Herewith declare that the following air handling unit (series and type (serial numbers)) Product AMX 4 (404000001 - 404099999) Is in conformity with provisions of the following directives, regulations, and standards: Directive(s) Regulation(s) Standard(s) 2006/42/EC - on machinery...
