- Page 1 SY-HDS12-18G User Manual 18G HDMI® Splitter 1x2 HDMI splitter with downscaling per output SY Electronics Ltd., 7 Worrall Street, Manchester, M5 4TH, United Kingdom Tel: +44 (0)161 868 3450 – Web: sy.uk...
- Page 2 AC mains cables. The terms ‘HDMI’ and ‘HDMI High-Definition Multimedia Interface’, and the HDMI logo are trademarks or registered trademarks of HDMI LLC in the United States and other countries. sy.uk V1.0...
- Page 3 The SY-HDS12-18G HDMI splitter supports HDMI resolutions up to full 4K60 4:4:4 (18Gbps). HDR 10, HDR 12 formats are supported. Features All HDMI resolutions up to 4K60 4:4:4 – 18Gbps Auto Downscaling per each output (4K → 1080p) ...
- Page 4 HDMI outputs to the display devices HDMI input from the HDMI source device 5V PSU input Using the SY-HDS12-18G Connect the HDMI source device to the HDMI IN Connect the HDMI display devices to the HDMI OUT connectors ...
- Page 5 4K24 444 HDR Dolby/DTS 5.1ch 4K24 444 HD Audio 7.1ch 1080p60 HDR Stereo audio 2.0ch 1080p60 HDR Dolby/DTS 5.1ch 1080p60 HDR HD Audio 7.1ch 1080p60 Stereo audio 2.0ch 1080p60 Dolby/DTS 5.1ch 1080p60 HD Audio 7.1ch EDID bypass from OUT 1 V1.0 sy.uk...
- Page 6 Each output can independently Auto-downscale from 4K to 1080p, depending on the capability of the display device. This ensures optimal use of mixed capability displays. Note: The SY-HDS12-18G is designed to accept AOC cables as well as HDMI cables. sy.uk...
- Page 7 DO NOT operate this product outside the specified temperature and humidity range given in the above specifications. Ensure there is adequate ventilation as this product generates heat while operating. V1.0 sy.uk...
- Page 8 For full details please refer to our Terms and Conditions. The SY Product warranty is automatically void under any of the following conditions: The product is already outside of its warranty period ...
