- Page 1 KIN ONE OWNERS MANUAL...
- Page 2 Congratulations We s i nc er e l y t ha n k y o u fo r h a v i n g g r a nt e d T o t e m ’ s KI N ONE t he spe c i al p l ac e i n y o ur l iv i ng e n v i ro n m e n t .
- Page 3 . Totem kee ps to a s tr i c t q ua l i t y c on trol reg i m e n a n d a ll fa c to r y - sea led p rod uct s le ave o ur fac i l i ty i n p er fe c t c o n d i ti o n .
- Page 4 KIN ONE...
- Page 5 Restriction of Hazardous Substances (RoHS) and CARB certification. UNPACKING Totem Acoustic keeps to a strict quality control regimen and all factory- sealed products leave our facility in perfect condition. If there are any damages visible or concealed that has occurred in handling it must be reported immediately to your Authorized Totem Dealer.
- Page 6 The KIN ONE can conveniently be wall mounted with the appropriate bracket. At the back of the KIN ONE is a threaded insert (1/4” -20) that allows the speakers to be mounted directly on the wall. It is best to place them very close to the ceiling. Thus the speaker system does not require any space and they will unleash all the great- ness they are capable of.
- Page 7 SPEAKER POSITIONING AND PLACEMENT Totem generally recommends that bookshelf speakers be positioned 12 in (30.5 cm) from the back wall and side wall to allow a better energy flow and cleaner bass response. Moving them closer to boundaries will result in more bass enhancement but can negatively affect the perceived depth of the soundstage.
- Page 8 TRESS SPEAKER CABLE Speaker cable is an important element of the overall system performance so ask your dealer about Totem Tress cable. Tress is a twisted pair of 14-gauge, multi stand, linearized oxygen-free silver-plated conductors coated in black and white Teflon. Dielectric shielding makes it impervious to damage and oxidization.
- Page 9 Totem owner. Our intense listening sessions are conducted without a grills and we believe yours should as well.
- Page 10 VOLUME All connections should be made with the equipment turned off. Volume controls on the amplifier/ receiver/preamplifier are very misleading. Please note that the volume control does not address power-output, but simply adjusts the audible level of music. It is the type of music being played that has an incidence on the amount of power used at a given volume level.
- Page 11 KI N ONE Speci f icatio ns Design: Compact Monitor Tweeter: 1” Titanium Infused Soft Dome tweete Woofer: 4” MHEX CONE Woofer Power Handling: 20-100w RMS Frequency response: 65Hz – 22kHz +-3dB with proper positioning Impedance: 6 ohm Sensitivity: 89dB Dimensions (WxHxD) : 5”...
- Page 12 Keep your original bill or receipt obtained from your Totem Authorized Dealer. All Totem products are created with the utmost care and quality in mind. If ever a problem should arise, Totem’s speakers are covered by a two (2) year limited warranty on the amplifier and 5 years on the drivers, starting from the date of purchase.
