SKU/THD.com # 0000 000 000
Model # HOTC9609BB1M
USE AND CARE GUIDE
HUSKY 96 IN. 9-DRAWER MOBILE WORKBENCH
Questions, problems, missing parts?
Before returning to the store, call
Husky Customer Service
8 a.m. - 7 p.m., EST, Monday-Friday
9 a.m.- 6 p.m., EST, Saturday
1 888 HD-HUSKY
HUSKYTOOLS.COM
THANK YOU
We appreciate the trust and confidence you have placed in Husky through the purchase of this
mobile workbench.
We strive to continually
create quality products designed to enhance your home. Visit us online to see our full line of products available for your home
improvement needs. Thank you for choosing Husky!
Advertisement
Related Manuals for Husky HOTC9609BB1M
Summary of Contents for Husky HOTC9609BB1M
- Page 1 1 888 HD-HUSKY HUSKYTOOLS.COM THANK YOU We appreciate the trust and confidence you have placed in Husky through the purchase of this mobile workbench. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home...
- Page 2 Table of Contents Table of Contents ..........2 Assembly ............... Safety Information ..........2-3 Operation ..............Warranty ............3 Maintenance ............Pre-Assembly ............. 4 Care and Clearning ........... Tools Required ..........4 Service Parts ..............Hardware Included ..........4 Specifications ..........
- Page 3 The manufacturer specifically disclaims any liability and shall not be liable for any consequential or incidental loss or damage, including but not limited to any labor/expense costs involved in the replacement or repair of said product. Contact the Customer Service Team at 1-888-HD-HUSKY or visit www.huskytools.com. HUSKYTOOLS.COM...
- Page 4 Pre-assembly TOOLS REQUIRED Phillips Safety screwdriver goggles HARDWARE INCLUDED NOTE: Hardware not shown to actual size. Part Part Code Description Quantity L034532A Bolt M4 x 10L L0345001 Bolt M6 x 15L L3011002 10MM/13MM Wrench SPECIFICATIONS Maximum capacity (drawer) 120 lbs Maximum capacity (bottom deep drawers) 240 lbs Maximum capacity (total unit)
- Page 5 Stainless Steel Top Lock Side handle Drawer liner Rolling cabinet Drawer slide (pair) Swivel caster with brake Power strip Soft Close Drawer slide (pair) Grommet Drawer Shelf Swivel caster Shelf clips Power strip bracket HUSKYTOOLS.COM 5 Please contact 1-888-HD-HUSKY for further assistance.
- Page 6 Assembly Attaching the power strip brackets Attaching the side handle □ Attach the side handle (B) to the cabinet using four bolts □ Attach the power strip brackets (H) to the cabinet for both (BB). sides using two bolts (AA) each. □...
- Page 7 Slightly insert one side and repeat for the other side. □ Slowly push the drawer until it is fully closed to engage the slide. □ Open the drawer and close it to verify proper operation. HUSKYTOOLS.COM 7 Please contact 1-888-HD-HUSKY for further assistance.
- Page 8 Maintenance Maintaining the casters Maintaining the drawers □ Periodically clean the drawer trim and inside the drawers □ Grease the casters annually using high quality with a mild detergent and water. bearing grease . □ Remove grease and oil with a standard, nonflammable cleaning fluid.
- Page 9 DTC35026 Drawer slide (pair) K03220392 Swivel caster with brake K2415014C Power strip K0129163 Soft Close Drawer slide (pair) L2065001 Grommet K03220391 Swivel caster D39013B Shelf DTC50011 Power strip bracket Z7400022I Shelf Clips HUSKYTOOLS.COM 9 Please contact 1-888-HD-HUSKY for further assistance.
- Page 10 Questions, problems, missing parts? Before returning to the store, call Husky Customer Service 8 a.m.-7 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m. EST Saturday 1-888-HD-HUSKY HUSKYTOOLS.COM Retain this manual for future use.
