- Page 1 Instructions for use Refrigerator-freezer...
- Page 2 We thank you for the confi dence you have shown by purchasing our appliance. We wish you a lot of pleasure using the appliance. The appliance is intended solely for household use. The refrigerator-freezer is intended for use in households. The lower part is the refrigerator compartment intended for storing fresh food at temperatures above 0°C.
- Page 3 Important warnings • This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or metal capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
- Page 4 always be clean and unobstructed. • Warning! Do not use mechanical devices or tools to defrost the refrigerator, nor any other methods except for those recommended by the manufacturer. • Warning! When installing, cleaning, or removing the appliance, make sure the insulation on the refrigeration system parts is not damaged.
- Page 5 Appliance description A Refrigerator compartment B Freezer compartment Control unit Interior illumination lamp Shelf (height adjustable) Water discharge gutter / groove Fruit and vegetables bin Refrigerator door rack (deep and shallow version, with or without cover) Bottle rack Foot • Appliance interior equipment may change subject to appliance model.
- Page 6 A Refrigerator compartment B Freezer compartment Control unit Interior illumination lamp Shelf (height adjustable) Bottle rack Water discharge gutter/groove Fruit and vegetables bin Refrigerator door bin (versions: deep, shallow; with or without cover) Bottle shelf with retainer 10 Foot • Appliance interior equipment may change subject to appliance model.
- Page 7 Installation and connection Selecting the room • The appliance should be installed in a dry and well ventilated room. The appliance will operate correctly if the environment temperature is within the ranges listed in the table below. The appliance class is indicated on the label with the basic information on the appliance.
- Page 8 Remark: * Applies to OLD TIMER appliances. Connecting the • Use the power cord to connect the appliance to the power appliance mains. The wall outlet should be fi tted with a ground contact (safety socket). Nominal voltage and frequency are indicated on the label with basic information on the appliance.
- Page 9 Changing the door opening direction Tools required: socket wrench / spanner Nr. 8, slot and cross screwdriver 1. Use the slot screwdriver to remove the covers A and B. 2. Undo / remove the hinges (C, E1) and the door (D), starting from the top and working your way down.
- Page 10 Changing the direction 1. Undo the latch A and door hinge B of the low temperature of low temperature compartment and remove the door C. compartment door 2. Rotate the door by 180°, mount them on the other side of the opening low temperature compartment, and attach the latch A and door hinge B to the other side of the cell.
- Page 11 Operating the appliance Model without fan Model with fan A Temperature setting and on/off knob B Fan on/off switch (only with some models) Turning the appliance Turn on: rotate the thermostat knob clockwise towards position 7. on/off...
- Page 12 Turn off: rotate the knob back to position STOP (0). Setting the temperature • Higher settings (towards 7) selected with the knob correspond to lower (cooler) temperatures. The temperature in the refrigerator interior may drop below 0°C. Only use higher settings when a lower temperature is desired and recommended or when environment temperature is lower than 16°C.
- Page 13 Recommended food arrangement in the appliance Recommended food Refrigerator compartment areas: arrangement in the - upper area: canned / preserved food, bread, wine, pastry, etc. appliance - medium area: dairy products, ready-to-eat meals, deserts, juices, beer, cooked food, etc. - lower area: meat, meat produce, delicatessen, etc. - vegetable drawer / bin: fresh fruit, vegetables, salads, root vegetables, potatoes, onions, garlic, tomatoes, tropical fruit, sauerkraut, turnips, etc.
- Page 14 Storing food in the refrigerator Important warnings on Appropriate use of the appliance, appropriate food food storage packaging, maintaining the appropriate temperature and observing the hygienic guidelines will affect decisively the quality of food storage. Observe the best before dates indicated on the product packaging.
- Page 15 • Interior side of the refrigerator door is fi tted with racks and bins intended for storing cheese, butter, eggs, yoghurt, and other smaller packages, tubes, cans, etc. The lower part of the door is fi tted with a bottle rack. Food storage time Recommended storage time for the refrigerator Foodsmoked...
- Page 16 Important warnings on The freezer should only be used for freezing food that freezing fresh food is appropriate for freezing. The food should always be fresh and of adequate quality. Choose an appropriate packaging for the food and package it correctly. The packaging should be airtight and watertight to prevent loss of humidity or vitamins from the food.
- Page 17 Defrosting the appliance Automatic refrigerator The refrigerator does not require defrosting, as ice accumulated defrosting on the back wall of the refrigerator compartment interior is melted automatically. The accumulated ice is thawed when the compressor is not operating. The drops will drip through the opening in the refrigerator back wall into a container above the compressor, from where they will evaporate.
- Page 18 Cleaning the appliance Before cleaning, disconnect the appliance from the power mains - rotate the thermostat knob A to the STOP (0) position and unplug the power cord from the wall outlet. • Use a soft cloth to clean all surfaces. Cleaners containing abrasive particles, acids, or solvents, are not appropriate as they will damage the surface.
- Page 19 Troubleshooting Problem: Cause or remedy: After connecting to the power • Make sure the wall outlet is powered and that the appliance is mains, the appliance does not plugged in. operate: Cooling system has been • Too high environment temperature. working continuously for a long •...
- Page 20 WE RESERVE THE RIGHT TO CHANGES THAT TO NOT AFFECT THE APPLIANCE FUNCTIONALITY. Instructions for use of the appliance can also be found on our website at www.gorenje.com / < http://www.gorenje.com /> COOLER 4* HTS2967, OLD T en (10-14)
