UNV OEI-371S-H-W Deployment Manual

Video intercom
Hide thumbs Also See for OEI-371S-H-W:

Advertisement

Quick Links

Download this manual
Video Intercom Deployment Guide
V1.3
Zhejiang Uniview Technologies Co., Ltd.

Advertisement

loading
Need help?

Need help?

Do you have a question about the OEI-371S-H-W and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for UNV OEI-371S-H-W

Summary of Contents for UNV OEI-371S-H-W

  • Page 1 Video Intercom Deployment Guide V1.3 Zhejiang Uniview Technologies Co., Ltd.
  • Page 2 Zhejiang Uniview Technologies Co., Ltd. Video Intercom Deployment Guide Contents 1 Introduction 1.1 Product Overview 1.2 Installation 1.3 Networking 1.3.1 Device 1.3.2 Network Environment Setup 1.3.3 Indoor Station Home Screen 2 Video Intercom Configuration 2.1 Indoor Station Wizard Configuration 2.2 Indoor Station Manual Configuration 2.3 Outdoor Station Configuration 2.3.1 Door Station 2.4 Network Camera Configuration...
  • Page 3 Introduction Product Overview OEI-371S-H-W/OEI-372S-H-W indoor station is a terminal in the digital building intercom system, with functions of video intercom, security alarm, network camera monitoring, etc., providing a safe and comfortable living environment for residents. It can be widely used in building systems such as smart communities, and parks.
  • Page 4 Zhejiang Uniview Technologies Co., Ltd. Video Intercom Deployment Guide NOTE!  The indoor station, outdoor station, and network camera support a 12V DC power supply.  The indoor station and villa door station support PoE power supply.  In a Wi-Fi networking environment, it is recommended to connect up to 4 indoor stations. 1.3.3 Indoor Station Home Screen The indoor station starts automatically after power-on, and the home screen appears.
  • Page 5 Zhejiang Uniview Technologies Co., Ltd. Video Intercom Deployment Guide Video Intercom Configuration The indoor station can realize video intercom, remote door opening, live view, and other functions with the connected outdoor station and network camera. It can also communicate with other extensions. The following describes how to configure on both the indoor station and outdoor station.
  • Page 6 Zhejiang Uniview Technologies Co., Ltd. Video Intercom Deployment Guide Figure 2-2 Network Settings 1. Network settings: Obtain Automatically (DHCP) is enabled by default, which will assign the indoor station an IP address automatically. You can skip the step if you want to keep the default configuration. 2.
  • Page 7 Zhejiang Uniview Technologies Co., Ltd. Video Intercom Deployment Guide Figure 2-4 Wi-Fi Connection Figure 2-5 Time Settings (Time Zone/DST/Time Sync) Set time parameters, including time zone, time, and DST. If you do not need to set time, tap Skip to proceed.
  • Page 8 Zhejiang Uniview Technologies Co., Ltd. Video Intercom Deployment Guide The indoor station type includes main indoor station and extension (the extension can realize most of functions after binding to the main indoor station). The default location information of the main indoor station is District 1, Building 1, Unit 1, Room 1, Extension Number 0 (cannot be modified except the extension number);...
  • Page 9 Zhejiang Uniview Technologies Co., Ltd. Video Intercom Deployment Guide Figure 2-1 Administration Configuration 4. Configure network parameters. (1) You can use DHCP to assign a dynamic IP address or set a static IP address. Figure 2-2 Indoor Station Config Figure 2-3 Network Settings...
  • Page 10 Zhejiang Uniview Technologies Co., Ltd. Video Intercom Deployment Guide Figure 2-4 Wi-Fi Search (2) Connect to Wi-Fi. 1. Enter the Wi-Fi screen and enable Wi-Fi. 2. The list will be refreshed automatically after 3 to 6 seconds. You can also tap to refresh.
  • Page 11 Zhejiang Uniview Technologies Co., Ltd. Video Intercom Deployment Guide Figure 2-6 Indoor Station Device Location Figure 2-7 Main Indoor Station’s Device Location 6. Tap Apply to save the settings. NOTE!  The default location of the villa door station is Building 1, Unit 1, Room 1 (cannot be modified). The default location of the indoor station is the same as the villa door station.
  • Page 12 Zhejiang Uniview Technologies Co., Ltd. Video Intercom Deployment Guide Figure 2-8 Indoor Station Extension Device Location NOTE! On the Device Location screen of the extension, only the extension number can be changed. Other location information will be changed automatically with the main indoor station. 7.
  • Page 13 Zhejiang Uniview Technologies Co., Ltd. Video Intercom Deployment Guide Figure 2-9 Device Management Figure 2-10 Door Station Auto Search Method 2: Enter the Door Station and IPC Management screen, tap Add, and set the device information as below. Figure 2-11 Door Station and IPC Management...
  • Page 14 Zhejiang Uniview Technologies Co., Ltd. Video Intercom Deployment Guide Figure 2-12 Door Station List Figure 2-13 Device Info (1) Enter the device name (optional). (2) Enter the IP address (required). (3) Select the device type (VIC-OutDoorStation,IPC). (4) Enable Live View. To bind an IPC, see 2.4 Network Camera Configuration for details.
  • Page 15 Zhejiang Uniview Technologies Co., Ltd. Video Intercom Deployment Guide Figure 2-14 Bound Devices The bound devices (outdoor stations and network cameras) will be displayed in the red box above. Tap Edit to view the device’s IP address. Figure 2-15 Bind to Main Indoor Station on Extension To bind the main indoor station on the extension’s screen, enter the Main Station screen of the extension, set the name of the main station you want to show on the extension, enter the IP address of the main station, and then tap Apply.
  • Page 16 Zhejiang Uniview Technologies Co., Ltd. Video Intercom Deployment Guide 5. The default username/password is admin/123456 (If the administration password has been changed, you need to use the new password to log in). A prompt will be displayed to change the default password at your first login.
  • Page 17 Zhejiang Uniview Technologies Co., Ltd. Video Intercom Deployment Guide Figure 2-3 Live View To use a wired network, set Obtain IP Address to Static and then set a static IP address as shown below. To use a wireless network, connect to Wi-Fi as shown below. Figure 2-4 Wired Network...
  • Page 18 Zhejiang Uniview Technologies Co., Ltd. Video Intercom Deployment Guide Figure 2-5 Wi-Fi 1. Set Wi-Fi Mode to Wi-Fi. 2. Select the Wi-Fi to connect from the list. 3. Enter the Wi-Fi password and confirm the password. 4. Click Save, and then the Wi-Fi can be connected. NOTE! The IP of outdoor station and network camera must be on the same IP segment as that of the indoor station.
  • Page 19 2.5.1 EZCloud QR Code 1. On the indoor station’s screen, go to Settings > Administration Configuration > Device Maintenance, tap Scan, and the indoor station’s register QR code appears. Scan the code with the UNV-Link app to bind the device.
  • Page 20 EZCloud register code is displayed. Figure 2-2 EZCloud QR Code of Connected Door Station 3. Scan the device register QR code with the UNV-Link app, and then bind the device as prompted. See 2.5.2 Bind Device for details.
  • Page 21 2. Check the device status. If it is online, it means that the device is connected to EZCloud. The register code is used to connect the device to EZCloud, which can be obtained by scanning the QR code. 2.5.2 Bind Device Log in to the UNV-Link app.
  • Page 22 Zhejiang Uniview Technologies Co., Ltd. Video Intercom Deployment Guide Figure 2-1 Bind Device to App 1. Enter the login screen of app. 2. Enter the home screen of app. 3. Enter the Add Device screen (1. Scan QR code 2. Enter the register code). 4.
  • Page 23 Zhejiang Uniview Technologies Co., Ltd. Video Intercom Deployment Guide Video Intercom Operations Video Intercom with Door Station After completing the video intercom configuration of indoor station and door station, press the physical button as shown below to call all connected main indoor stations and door station extensions in the same room.
  • Page 24 Zhejiang Uniview Technologies Co., Ltd. Video Intercom Deployment Guide Figure 3-2 Extension Calling Screen For example, to call the extension in a same room with the extension number of 2, you need to input 2 and then tap Call. NOTE! For the extension, the default length of a call and calling time have no limitation.
  • Page 25 Zhejiang Uniview Technologies Co., Ltd. Video Intercom Deployment Guide 1. Enter the alarm records screen. 2. Enter the Settings screen. 3. 1) Enable Allow Alarm Notifications. 2) Enable Video Call Notifications. After completing the settings, when the door station calls the indoor station, the app screen also shows an incoming call as below.
  • Page 26 Zhejiang Uniview Technologies Co., Ltd. Video Intercom Deployment Guide Figure 4-1 Indoor Station Live View . The live view screen appears. By default, the right list displays the linked outdoor stations. To view the linked network cameras, enter the Camera tab. ...
  • Page 27 Zhejiang Uniview Technologies Co., Ltd. Video Intercom Deployment Guide Configure Multiple Doors for Door Stations Log in to the door station’s Web interface. See 2.3.1 Door Station for details. Figure 4-1 Multiple Doors Configuration 1. Enter the Setup menu. 2. Enter the Ports & Devices interface. 3.
