- Page 1 Villa Door Station OEU-201S-HMK-W Installation Guide V1.0.0 Villa Door Station OEU-201S-HMK-W Installation Guide V1.0.0 Zhejiang Uniview Technologies Co., Ltd.
-
Page 2: Revision Records
Villa Door Station OEU-201S-HMK-W Installation Guide Internal Use Only Revision Records Date Version Description Author 2023/9/26 V1.0.0 Initial release GW3317 Zhejiang Uniview Technologies Co., Ltd. www.uniview.com 2/13... -
Page 3: Table Of Contents
Villa Door Station OEU-201S-HMK-W Installation Guide Internal Use Only Contents 1 Overview 2 Site Survey 3 Safety Instructions 4 Preparations 5 Installation 5.1 Determine Installation Location 5.2 Installation 6 Wiring 6.1 Tail Cables 6.2 Wiring Zhejiang Uniview Technologies Co., Ltd. www.uniview.com 3/13... - Page 4 Villa Door Station OEU-201S-HMK-W Installation Guide Internal Use Only NOTE: This document is intended to provide guidance on commissioning and installing visual intercom door station to ensure normal business operation. It is intended for Uniview’s checkpoint installation and maintenance engineers, and implementation and maintenance staff of integrators and contractors. It is strongly recommended to read through this guide before starting site design and subsequent actions.
-
Page 5: Overview
Villa Door Station OEU-201S-HMK-W Installation Guide Internal Use Only Overview OEU-201S-HMK-W is a terminal device in the digital building intercom system, with functions of visual intercom, video surveillance, etc., providing a safe and comfortable living environment for residents. It can be widely used in residential villas. - Page 6 Villa Door Station OEU-201S-HMK-W Installation Guide Internal Use Only Take waterproof measures for devices installed outdoors. Use a ground-protected power outlet. Ensure that the device is grounded properly if grounding is required. Be sure to strictly observe local electrical safety codes. ...
-
Page 7: Preparations
Villa Door Station OEU-201S-HMK-W Installation Guide Internal Use Only Preparations Screwdriver set (Phillips screwdriver, torx screwdriver head) Used to secure the device. Marker Used to mark mounting holes. Tape measure Used to measure dimensions. Electric hammer drill + 6mm drill bit Used to drill holes. -
Page 8: Installation
Villa Door Station OEU-201S-HMK-W Installation Guide Internal Use Only Select a backlight and rainproof position. Installation 1. Wall Mount Mount the junction box (skip this step if there is a junction box in the wall) : Drill a recess in the wall, which shall be 5mm larger than the junction box, then mount the box in the wall and secure it. - Page 9 Villa Door Station OEU-201S-HMK-W Installation Guide Internal Use Only Figure 5-1 Junction box supplied Figure 5-2 Other junction box Mount the bracket and sunshield. 1) Keep the two snaps on the bracket facing upward and the screw hole at the bottom of the bracket facing outward.
- Page 10 Villa Door Station OEU-201S-HMK-W Installation Guide Internal Use Only 2) Connect the network cable and other cables to the rear panel correctly, and then lead the cables out from the cable groove (See 6.2 Wiring for details.). 3) Fix the rear panel (with rubber cushion facing inward) onto the door station with screws. Install the base of door station to the bracket.
- Page 11 Villa Door Station OEU-201S-HMK-W Installation Guide Internal Use Only 2. Recess Mount CAUTION! Only metal door station supports recess mount. The recess mount bracket will be used for recess mount. Fix the recess bracket to ensure that the wall has enough space to mount the bracket. The bracket size is as follows.
-
Page 12: Wiring
Villa Door Station OEU-201S-HMK-W Installation Guide Internal Use Only Fix the door station and the sunshield to the bracket. Align the three holes of the station with those of the bracket, insert the screws and tighten. Mount the sunshield, and then insert the screw into the bottom of the station again and tighten. Wiring Tail Cables Cable... -
Page 13: Wiring
Villa Door Station OEU-201S-HMK-W Installation Guide Internal Use Only ALM_IN3 Light Green ALM_IN4 Yellow/Black Black Power supply VDD12V LOCK1_NC Pink LOCK1_COM White/Yellow LOCK1_NO White/Green LOCK2_NC Gray Door lock LOCK2_COM White/Orange LOCK2_NO White/Blue Black Wiring The door station can two sets of door opening buttons, door magnets, and door locks at the same time.
