UNV OEI-371S-H-W Deployment Manual

Video intercom
Hide thumbs Also See for OEI-371S-H-W:
Table of Contents

Advertisement

Quick Links

Video Intercom Deployment Guide
V1.5
Zhejiang Uniview Technologies Co., Ltd.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OEI-371S-H-W and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for UNV OEI-371S-H-W

Summary of Contents for UNV OEI-371S-H-W

  • Page 1 Video Intercom Deployment Guide V1.5 Zhejiang Uniview Technologies Co., Ltd.

  • Page 2: Table Of Contents

    Zhejiang Uniview Technologies Co., Ltd. Video Intercom Deployment Guide Internal Use Only Contents 1 Introduction· · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · ·· · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · ·· · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · ·· · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · ·· · · · · · · · · · · · 1 1.1 Product Overview ································...
  • Page 3 5 Platform Management · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · ·· · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · ·· · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · ·· · · · · · · · · · · · · · · · · · · · · · · · · 53 5.1 UNV-Guard ································································ ································································ ··············· 53 5.1.1 Bind Devices in Batches ································ ································ ·························································· 53 5.1.2 Call UNV-Guard Client ································ ································ ···························································· 60...

  • Page 4: Introduction

    Introduction Product Overview OEI-371S-H-W/OEI-372S-H-W indoor station is a terminal in the digital building intercom system, with functions of video intercom, security alarm, network camera monitoring, etc., providing a safe and comfortable living environment for residents. It can be widely used in building systems such as smart communities, public security, and parks.

  • Page 5: Network Environment Setup

    Zhejiang Uniview Technologies Co., Ltd. Video Intercom Deployment Guide Internal Use Only 1.3.2 Network Environment Setup After the devices are ready, connect them as shown in the diagram below. Figure 1-1 Video Intercom Product Network Environment NOTE!  The indoor station, outdoor station (intelligent recognition terminal/door station), and network camera support a 12V DC power supply.
  • Page 6 Zhejiang Uniview Technologies Co., Ltd. Video Intercom Deployment Guide Internal Use Only (1) Log in to the device screen with the default username and password (admin/123456), and then the Welcome screen appears. Set a strong new password with 9 to 32 characters including all three elements: uppercase and lowercase letters, digits, and special characters.
  • Page 7 Zhejiang Uniview Technologies Co., Ltd. Video Intercom Deployment Guide Internal Use Only NOTE! The IP address of outdoor station must be on the same IP segment as that of the indoor station, and then the video intercom function can be available. 3.
  • Page 8 Zhejiang Uniview Technologies Co., Ltd. Video Intercom Deployment Guide Internal Use Only Figure 2-5 Time Settings (Time Zone/DST/Time Sync) 5. Set the indoor station type, location, and registration password. (1) The indoor station type includes main indoor station and extension (the extension can realize most of functions after binding to the main indoor station).
  • Page 9 Zhejiang Uniview Technologies Co., Ltd. Video Intercom Deployment Guide Internal Use Only Figure 2-7 Registration Password (4) Set the registration password to relate the indoor station to door station or other monitoring devices for security. Three methods are available: a Tap Apply directly, and the registration password is 12345678 by default. b Tap to customize the registration password, and tap Apply to save the setting.
  • Page 10 Zhejiang Uniview Technologies Co., Ltd. Video Intercom Deployment Guide Internal Use Only Figure 2-8 Door Station Auto Search (1) Refresh the door station auto search list (it will be refreshed automatically when you enter the screen). (2) Select the video intercom devices (door station/indoor station extension) you want to relate. (3) Click , and enter the administrator password, and then configure registration password, EZCloud, device location, and multiple doors for door stations (see...
  • Page 11 Zhejiang Uniview Technologies Co., Ltd. Video Intercom Deployment Guide Internal Use Only Figure 2-10 Added Successfully Figure 2-11 Failed to Add NOTE!  On the Door Station Auto Search screen, the outdoor station and indoor station in different network segments cannot be searched.

  • Page 12: Indoor Station Home Screen

    Zhejiang Uniview Technologies Co., Ltd. Video Intercom Deployment Guide Internal Use Only Indoor Station Home Screen The indoor station starts automatically after power-on, and the home screen appears. The home screen shows the current time and buttons including Lock Screen, Do Not Disturb, Live View, Call, Message, and Settings.
  • Page 13 Zhejiang Uniview Technologies Co., Ltd. Video Intercom Deployment Guide Internal Use Only Figure 2-12 Administration Configuration 3. Configure network parameters. (1) You can use DHCP to assign a dynamic IP address or set a static IP address. Figure 2-13 Indoor Station Config...
  • Page 14 Zhejiang Uniview Technologies Co., Ltd. Video Intercom Deployment Guide Internal Use Only Figure 2-14 Network Settings Figure 2-15 Wi-Fi Search (2) Connect to Wi-Fi. a Enter the Wi-Fi screen and enable Wi-Fi (the list will be refreshed automatically after 3 to 6 seconds).
  • Page 15 Zhejiang Uniview Technologies Co., Ltd. Video Intercom Deployment Guide Internal Use Only Figure 2-16 Wi-Fi Connection 4. Device location: Set the indoor station’s location information including residential compound name, district number, building number, unit number, and room number, which should be consistent with outdoor station’s location.
  • Page 16 Zhejiang Uniview Technologies Co., Ltd. Video Intercom Deployment Guide Internal Use Only Figure 2-18 Main Indoor Station Location 5. Tap Apply to save the settings. NOTE!  The default location of the villa door station is Building 1, Unit 1, Room 1 (cannot be modified). The default location of the indoor station is the same as the villa door station.
  • Page 17 Zhejiang Uniview Technologies Co., Ltd. Video Intercom Deployment Guide Internal Use Only NOTE! On the Device Location screen of the extension, only the extension number can be changed. Other location information will be changed automatically with the main indoor station. 6.
  • Page 18 Zhejiang Uniview Technologies Co., Ltd. Video Intercom Deployment Guide Internal Use Only Figure 2-20 Devices Figure 2-21 Device Discovery Figure 2-22 Added Successfully...
  • Page 19 Zhejiang Uniview Technologies Co., Ltd. Video Intercom Deployment Guide Internal Use Only Figure 2-23 Failed to Add Method 2: Enter the Related Devices screen, tap Add, and configure the device information as below. Figure 2-24 Related Devices...
  • Page 20 Zhejiang Uniview Technologies Co., Ltd. Video Intercom Deployment Guide Internal Use Only Figure 2-25 Related Devices Figure 2-26 Device Info (1) Enter the device name (optional). (2) Enter the IP address (required). (3) Select the device type (Door Station, Camera). (4) Enter the device password.
  • Page 21 Zhejiang Uniview Technologies Co., Ltd. Video Intercom Deployment Guide Internal Use Only Figure 2-27 Added Related Devices The Central Server is a default related device, and it can only be edited (enter IP address as needed) but cannot be deleted. The related devices (outdoor stations and network cameras) will be displayed in the red box above.
  • Page 22 Zhejiang Uniview Technologies Co., Ltd. Video Intercom Deployment Guide Internal Use Only Figure 2-28 Relate to Main Indoor Station on Extension To bind the main indoor station on the extension’s screen, enter the Main Station screen of the extension, set the name of the main station you want to show on the extension, enter the IP address of the main station, and then tap Apply.

  • Page 23: Outdoor Station Configuration

    Zhejiang Uniview Technologies Co., Ltd. Video Intercom Deployment Guide Internal Use Only Figure 2-30 Ringtone By default, four ringtones are available including Ringtone 1, Ringtone 2, Ringtone 3, and custom ringtone. It is Ringtone 1 by default. To import a custom ringtone, follow the steps below: Save the MP3 audio file you want to use to a SD card, and rename it as Custom.
  • Page 24 Zhejiang Uniview Technologies Co., Ltd. Video Intercom Deployment Guide Internal Use Only 不勾选 3. Enter the door station’s IP address (192.168.1.13 by default) in the address bar, and then press Enter. 4. Enter the username and password, and then click Login. 5.
  • Page 25 Zhejiang Uniview Technologies Co., Ltd. Video Intercom Deployment Guide Internal Use Only (1) At your first login, you need to follow the on-screen instructions to install the latest plug-in; otherwise, you cannot view the live video. Figure 2-31 Plug-in Installation Prompt (2) Enter the username and password (admin/123456 by default).
  • Page 26 Zhejiang Uniview Technologies Co., Ltd. Video Intercom Deployment Guide Internal Use Only Figure 2-33 Live View To use a wired network, set Obtain IP Address to Static and then set a static IP address as shown below. To use a wireless network, connect to Wi-Fi as shown below. Figure 2-34 Wired Network...
  • Page 27 Zhejiang Uniview Technologies Co., Ltd. Video Intercom Deployment Guide Internal Use Only Figure 2-35 Wi-Fi 1. Set Wi-Fi Mode to Wi-Fi. 2. Select the Wi-Fi to connect from the list. 3. Enter the Wi-Fi password and confirm the password. 4. Click Save, and then the Wi-Fi can be connected. NOTE! The IP of outdoor station and network camera must be on the same IP segment as that of the indoor station.
  • Page 28 Zhejiang Uniview Technologies Co., Ltd. Video Intercom Deployment Guide Internal Use Only Figure 2-36 Personalization 2. Click Browse..., select a custom auto answer audio (a PCM file with no more than 108KB) for the first use, and click Import. A success message means the audio are imported. Then, the custom audio will be displayed in the audio list.
  • Page 29 Zhejiang Uniview Technologies Co., Ltd. Video Intercom Deployment Guide Internal Use Only Figure 2-37 Network Settings Figure 2-38 Device Management After the indoor station is related to the door station, it will be displayed on the Web’s Device Management interface of the door station. If four indoor stations are related to the door station, the door station button 1/2/3/4 corresponds to the first/second/third/fourth added indoor station by default.
  • Page 30 Zhejiang Uniview Technologies Co., Ltd. Video Intercom Deployment Guide Internal Use Only Figure 2-39 Device Management Click Add, enter the indoor station information, click OK, and then the Device Management interface will show the indoor station. Follow the description above to set the door station button to call the indoor station.

  • Page 31: Intelligent Recognition Terminal

    Zhejiang Uniview Technologies Co., Ltd. Video Intercom Deployment Guide Internal Use Only Apartment Door Station The apartment door stations do not support the Wi-Fi connection. For the password modification, plug-in installation, and live view configuration, see Single-Button Villa Door Station. Figure 2-40 Network Settings Intelligent Recognition Terminal Network settings...
  • Page 32 Zhejiang Uniview Technologies Co., Ltd. Video Intercom Deployment Guide Internal Use Only Figure 2-42 Wired Network Location and call protocol settings: 1. On the device’s Activation Config screen, go to Basic Settings > Intercom Config. 2. Choose EI-3 Series Indoor Station for the indoor station protocol. 3.

  • Page 33: Network Camera Configuration

    Zhejiang Uniview Technologies Co., Ltd. Video Intercom Deployment Guide Internal Use Only Network Camera Configuration To view the live video of network camera on the indoor station, you need to set the camera’s sub stream to 720P or lower, and then connect the camera to the indoor station. Figure 2-44 Sub Stream Config 1.

  • Page 34: Add Device To App

    1. On the indoor station’s screen, go to Settings > Administration Configuration > Device Maintenance, tap Scan, and the indoor station’s register QR code appears. Figure 2-46 View EZCloud QR Code 2. Scan the register QR code with the UNV-Link app, and then bind the device as prompted. See Bind Device for details.

  • Page 35: Bind Device

    Video Intercom Deployment Guide Internal Use Only 2.7.2 Bind Device Log in to the UNV-Link app. Figure 2-48 Bind Device to App 1. Enter the login screen of app. 2. Log in to the app, and then the home screen appears.

  • Page 36: Video Intercom Operations

    Zhejiang Uniview Technologies Co., Ltd. Video Intercom Deployment Guide Internal Use Only Video Intercom Operations Video Intercom with Door Station 3.1.1 Villa Single-Button Door Station After completing the video intercom configuration of indoor station and door station, press the physical button as shown below to call all connected main indoor stations and door station extensions in the same room.

  • Page 37: Apartment Door Station

    Zhejiang Uniview Technologies Co., Ltd. Video Intercom Deployment Guide Internal Use Only 3.1.3 Apartment Door Station After indoor stations and apartment door station have completed video intercom configuration, follow the screen prompt on the apartment door station to input the room number of the indoor station by pressing the digit button, and then press the call button to call the corresponding indoor station and extensions.

  • Page 38: Video Intercom With Intelligent Recognition Terminal

    Zhejiang Uniview Technologies Co., Ltd. Video Intercom Deployment Guide Internal Use Only Video Intercom with Intelligent Recognition Terminal After completing the basic settings, the devices can start video intercom. Operations are available to outdoor station and indoor station, including make calls, answer calls, door opening (door station supports two doors, intelligent recognition terminal supports one door), and live video.
  • Page 39 Zhejiang Uniview Technologies Co., Ltd. Video Intercom Deployment Guide Internal Use Only Figure 3-2 Dialing Screen For example, if the room number is 18, input 18 on the screen, tap OK, and then the intelligent recognition terminal will call all indoor stations in the room. Figure 3-3 Calling Screen The intelligent recognition terminal screen shows a waiting status, and the indoor station screen shows an incoming call.
  • Page 40 Zhejiang Uniview Technologies Co., Ltd. Video Intercom Deployment Guide Internal Use Only Figure 3-4 Indoor Station Screen Showing Incoming Call The four buttons on the screen are used to decline the call, open the door 1, open the door 2, and answer the call.

  • Page 41: Call Extension

    Zhejiang Uniview Technologies Co., Ltd. Video Intercom Deployment Guide Internal Use Only Figure 3-6 Indoor Station Tap the Hang up button to end the call, or tap the Unlock button to open the door. Tap the Recording button on the right to record the live video. NOTE! Currently the default length of a call is 60s.

  • Page 42: Call App

    Zhejiang Uniview Technologies Co., Ltd. Video Intercom Deployment Guide Internal Use Only Figure 3-8 Extension Calling Screen For example, to call the extension in a same room with the extension number of 2, you need to input 2 and then tap Call. NOTE! For the extension, the default length of a call and calling time have no limitation.

  • Page 43: Common Functions

    Zhejiang Uniview Technologies Co., Ltd. Video Intercom Deployment Guide Internal Use Only After completing the settings, when the door station calls the indoor station, the indoor station and app screens all show an incoming video call as below. Figure 3-10 App Screen Showing Incoming Call Common Functions Live View After the indoor station is connected to the outdoor station or network camera, you can tap Live View on...
  • Page 44 Zhejiang Uniview Technologies Co., Ltd. Video Intercom Deployment Guide Internal Use Only  The device name and the remaining play time are displayed at the top of the screen. NOTE! A 60s live video will be played by default. The screen will automatically exit after 60s. To view the live video again, you need to tap the corresponding button.

  • Page 45: Visitor Message

    Zhejiang Uniview Technologies Co., Ltd. Video Intercom Deployment Guide Internal Use Only  : Tap to record live video. It is only available to the device with a SD card. Otherwise, the icon is grayed out.  : Tap to return to the home screen. Visitor Message NOTE! This function is only available to the version GVIC-B1101.3.1.231229 or later of the door station OEU-...
  • Page 46 Zhejiang Uniview Technologies Co., Ltd. Video Intercom Deployment Guide Internal Use Only Figure 4-6 Visitor Message If the call is not answered after the set duration, the door station shows a prompt Leaving a message..., and the visitor can leave a message on the door station. At the same time, the indoor station screen plays an audio, Please leave a message after the beep, Figure 4-7 View Visitor Message to enter the Message screen.

  • Page 47: Video Recording

    Zhejiang Uniview Technologies Co., Ltd. Video Intercom Deployment Guide Internal Use Only Figure 4-9 View Visitor Message By default, the messages are displayed in decreasing order of message time. Video Recording You can record the video when the indoor station receives a call or is calling with the door station. This function is only available to the device with a SD card.
  • Page 48 Zhejiang Uniview Technologies Co., Ltd. Video Intercom Deployment Guide Internal Use Only Figure 4-11 Hot-plug SD Card Message When the SD card is hot-plugged, the video intercom may be unavailable, and a message will appear on the indoor station screen to prompt you to restart the device. Figure 4-12 Video Recording...
  • Page 49 Zhejiang Uniview Technologies Co., Ltd. Video Intercom Deployment Guide Internal Use Only On the live view screen, you can tap to record the live video, and to stop recording. If the recording time reaches the upper limit, the recording will be ended. The grayed-out icon shows the device has no SD card and the recording function cannot be used.
  • Page 50 Zhejiang Uniview Technologies Co., Ltd. Video Intercom Deployment Guide Internal Use Only When the indoor station receives a call or is calling with the door station, you can tap to record the live video, and tap to stop recording. If the recording time reaches the upper limit, the recording will be ended.

  • Page 51: Indoor Station I/O Settings

    Zhejiang Uniview Technologies Co., Ltd. Video Intercom Deployment Guide Internal Use Only Figure 4-15 Video Recording and Play Figure 4-16 Video Recording and Play By default, the videos are displayed in decreasing order of recording time. Indoor Station I/O Settings Configure the I/O alarm output as needed, and the indoor station will send output signals to the connected output devices when it receives a call from door station or intelligent recognition terminal.
  • Page 52 Zhejiang Uniview Technologies Co., Ltd. Video Intercom Deployment Guide Internal Use Only Figure 4-17 I/O Settings You can enable/disable the output 1 and output 2, and then set the delayed alarm time and alarm duration. Figure 4-18 I/O Settings a. Enable Output 1, and then the delayed time and duration can be configured. b.

  • Page 53: Configure Multiple Doors For Door Stations

    Zhejiang Uniview Technologies Co., Ltd. Video Intercom Deployment Guide Internal Use Only Configure Multiple Doors for Door Stations Two methods are available to configure multiple doors for door stations. Method 1: Log in to the door station’s Web interface. See 2.4.1 Door Station for details.
  • Page 54 Zhejiang Uniview Technologies Co., Ltd. Video Intercom Deployment Guide Internal Use Only Figure 4-20 Related Devices 3. Tap beside Door Control, and enable Door 2. Figure 4-21 Door Station Door Control NOTE! The door 1 is enabled by default, and cannot be configured. You can enable/disable the door 2 as needed.
  • Page 55 Zhejiang Uniview Technologies Co., Ltd. Video Intercom Deployment Guide Internal Use Only Currently the multiple doors function is unavailable to the intelligent recognition terminal. When tapping beside Door Control for the intelligent recognition terminal, a prompt will appear on the screen, Failed to obtain door control settings.

  • Page 56: Platform Management

    Platform Management UNV-Guard Add apartment door stations and indoor stations to the UNV-Guard client, and tap the call button on the device screen to call the client. Currently, this function is unavailable to the villa door station. You can sync binding relations in batches on the UNV-Guard client to bind multiple devices to the client.
  • Page 57 Zhejiang Uniview Technologies Co., Ltd. Video Intercom Deployment Guide Internal Use Only Figure 5-1 Organization Management There is a default organization root. You can add multiple organizations to root. For example, add an organization, and add devices to the organization. Figure 5-2 Organization Management 2 Residential Management On the Residential Management page, click Add Compound to add a community.
  • Page 58 Zhejiang Uniview Technologies Co., Ltd. Video Intercom Deployment Guide Internal Use Only Figure 5-3 Residential Management Click OK to add the community. Figure 5-4 Residential Management 3 Device Management Click Device Management, and add villa door stations, apartment door stations, and indoor stations.
  • Page 59 Zhejiang Uniview Technologies Co., Ltd. Video Intercom Deployment Guide Internal Use Only Figure 5-5 Device Management Go to Device Management > Device > Video Intercom Device, and add villa door stations, apartment door stations, and indoor stations. You can add devices by auto search or manually. Auto search: Devices in the same network segment can be searched by default.
  • Page 60 Zhejiang Uniview Technologies Co., Ltd. Video Intercom Deployment Guide Internal Use Only Add manually: Click Add, enter the device information as required, and click OK to add a device.  Device Name: The device name.  IP Address: The device IP address. ...
  • Page 61 Zhejiang Uniview Technologies Co., Ltd. Video Intercom Deployment Guide Internal Use Only Figure 5-9 Device Location Config On the Device Location Config interface, click Add, and select a location for the device (building, unit, floor, and room). Note: The door station can be added to a unit only, and the indoor station can be added to a room.
  • Page 62 Zhejiang Uniview Technologies Co., Ltd. Video Intercom Deployment Guide Internal Use Only Figure 5-10 Device Location Config After the device location configuration is complete, click Sync to relate these devices. If the synchronization is successful, the sync status shows Succeeded.
  • Page 63 Figure 5-12 Device Location Config 5.1.2 Call UNV-Guard Client Currently, only the apartment door stations and indoor stations support calling the UNV-Guard client, and a microphone should be connected to the PC to answer the call.
  • Page 64 Zhejiang Uniview Technologies Co., Ltd. Video Intercom Deployment Guide Internal Use Only This function is unavailable to single-button and multi-button door stations. Go to Home > All-Function Mode > Video Intercom > Call Recipient Mgt. Click Add, select the user(s) and add to the call recipient list, and click Next.
  • Page 65 Zhejiang Uniview Technologies Co., Ltd. Video Intercom Deployment Guide Internal Use Only On the indoor station screen, tap the Call icon, and tap Call Center to call the UNV-Guard client. Figure 5-14 Call Center...
  • Page 66 Zhejiang Uniview Technologies Co., Ltd. Video Intercom Deployment Guide Internal Use Only On the apartment door station screen, tap to call the UNV-Guard client, then you can view the live video and open the door remotely on the client. Figure 5-15 Call Recipient...
  • Page 67 Zhejiang Uniview Technologies Co., Ltd. Video Intercom Deployment Guide Internal Use Only The Event Alarm interface shows the missing calls of devices. Figure 5-16 Call Recipient Mgt...
