VOTEM VP-700 User Manual

Hide thumbs Also See for VP-700:

Advertisement

Quick Links

Download this manual
VP-700 User's Manual
VER. 2.12(2024.12.10)

Advertisement

loading
Need help?

Need help?

Do you have a question about the VP-700 and is the answer not in the manual?

Questions and answers

Related Manuals for VOTEM VP-700

Summary of Contents for VOTEM VP-700

  • Page 1 VP-700 User’s Manual VER. 2.12(2024.12.10)
  • Page 2 How to Maintain Battery ......................18 How to Keep the Patient Monitor ..................18 Introduction ..........................20 Intended Use for the VP-700 ....................20 About This Manual ........................20 Sort of VP-700 ..........................20 Features for the VP-700 ......................20 Physical/Mechanical ......................
  • Page 3 NUMERIC ........................38 TREND ..........................38 EVENT ..........................39 Display Color Description ....................... 40 How to operate VP-700 ......................41 Description of warning and caution ................... 41 Main Use ............................42 Turn on the Main Unit ......................42 SET UP ............................44 SET UP –...
  • Page 4 VP-700 User Manual Content Alarm and Limit ......................... 62 Description of warning and caution ................... 62 General ............................62 Kind of Alarm ..........................62 Alarm Range ..........................63 Alarm Setting Range ......................63 Alarm Default Setting ...................... 64 Alarm Setting ..........................65 Alarm Warning Sign .........................
  • Page 5 VP-700 User Manual Content Display of SpO₂ ........................79 SpO₂ Message ........................79 APG ............................79 SpO₂ Setting ..........................80 Masimo SpO₂(Option) ......................81 SAFETY INFORMATION, WARNINGS, CAUTIONS AND NOTES ...... 81 Features and benefits ...................... 83 Indications for use ......................83 PRINCIPLE OF OPERATION ....................
  • Page 6 VP-700 User Manual Content Axillary Temperature Taking ..................99 Rectal Temperature Taking ................... 99 Removal ..........................99 Display of TEMP - F3000 Temperature(Option) ............100 Display of TEMP - F3000 Temperature(Option) ..........100 TEMP Message ........................ 100 TEMP Error Message ..................... 100 Temp Setting-F3000 Temperature(Option) ..............
  • Page 7 VP-700 User Manual Content 16. IBP Monitoring(Option) ....................... 116 Description of warning and caution ................116 General ............................117 Set Connection ........................117 Connection of Accessory ..................... 117 IBP Sensor Attachment ....................118 Way of measuring ......................120 Display of IBP ........................... 120 Display of IBP ........................
  • Page 8 VP-700 User Manual Content General ............................133 Resolution ..........................133 Display Trouble ....................... 133 ECG / RESPIRATION Measurement Trouble............134 SpO₂ Measurement Trouble ..................134 NIBP Measurement Trouble ..................134 IBP Measurement Trouble ..................134 EtCO₂ Measurement Trouble ..................134 TEMP Measurement Trouble ..................
  • Page 9 VP-700 User Manual General Information 1. General Information This user guide describes the product essentials and user information. ⚫ Safe use and a durable user manual will help you fully understand the product's ⚫ features. The user manual is kept in a place where the product's functions can be operated.
  • Page 10 VP-700 User manual What’s Inside of the Manual 2. What’s Inside of the Manual The Purpose of the Manual The manual provides you with the instructions on how to use the patient monitor with safety, function and purposes. Please locate the manual within the place you can reach easily for the reconfirmation of the function.
  • Page 11 You are asked to check the surroundings of the units before the operation whether there are any harmful things. NOTE ▪ VP-700 is “Class IIb” equipment. ▪ It is type “CF grade” for ECG, Resp, IBP and “BF grade” for EtCO2, SpO₂, NIBP and Temp.
  • Page 12 VP-700 User Manual Safety Information WARNING Please be careful when using the device in a place where a fire occurs or in a high temperature room, as there is a danger of battery explosion. WARNING Please do not disassemble the patient monitors. The manufacturer is free from the responsibility if something happens.
  • Page 13 It may cause any damage to the patient and malfunction of the operation. WARNING VOTEM Co., Ltd supplies on the optional items and accessories which are passed with the regulation of electronic safety. If you use the other products or the unproved additional items, it may cause damage to the patient or the patient monitors.
  • Page 14 WARNING Use a grounded design A/C power source. WARNING VP-700 can be used alongside with defibrillator while the accuracy of the product may be fallen in a short time. Check the accessories and symbols available before using the defibrillator. WARNING...
  • Page 15 CAUTION VP-700 have the Touch Panel on the front screen. Please be careful not to give any shocks. Do not touch the touch panel with the ball point pen or sharp things because this behavior causes the damage. The misuse by the end user cannot be covered by free technical service.
  • Page 16 VP-700 User Manual Safety Information CAUTION Instruction on manual should be kept for the long life of the patient monitor. But the priority should be on the patient than the manual. CAUTION When the data of patient is damaged temporarily, the present monitoring may not be completed.
  • Page 17 Please check all insulation status of all cables. Please repair or replace the ⚫ damaged or bad cable by the specialists. Please contact to Votem Co., Ltd or the Regional Distributors for further ⚫ information. General Maintenance WARNING: disconnect the main unit from the electronic sources before clearing and sterilization processes.
  • Page 18 CAUTION: Please abide by the regulations of the related country when you dump or reuse the battery. Please, when storing the VP-700's equipment for more than 3 months, it is recommended to remove the battery by a fully trained administrator before storage.
  • Page 19 VP-700 user manual Maintenance Avoid placing in an area where chemicals are stored or where there is in danger of gas leakage. Avoid dust and especially metal material into the equipment. CAUTION: When storing, hang used cables and lead wires vertically to prevent them from becoming twisted after use, and do not store them wrapped around other medical equipment.
  • Page 20 Each sensor cable has a unique ID color to make connection easy for users. About This Manual The manual explains how to use VP-700 and how to set the measuring value for measuring the vital signs of the patient. Please read the manual before use.
  • Page 21 Frequency 50/60 Hz ~ Display VP-700 display the vital signs on 7 Inch Color TFT LCD monitor. The users can easily operate the function or setting of the patient monitor with encoder and Touch Screen(when purchasing a Touch product.). The trend function outputs saved vital sign and various warning messages.
  • Page 22 WARNING VP-700 must not be located with other equipment at near place or on the upper part of other equipments. In case of putting the patient monitor on the above situation, please check whether the patient monitor works normally.
  • Page 23 VP-700 User Manual Set up the VP-700 Configuration Table 6-1. Standard Item ▪ Quick Manual Power Cord ECG Cable VP-700 5Lead (1ea) (1ea) (1ea) Adult Finger Clip Adult NIBP Cuff disposable electrodes NIBP Hose SpO₂ Sensor (1ea) (1ea) (5 PCS/1set) (1ea) Table 6-2.
  • Page 24 CAUTION: After using the patient monitor, recharge the battery. AC Power and Battery specification When AC power is connected to the VP-700, the power button on the front of the product lights up in blue, and when the product is not in use, it switches to automatic charging mode to charge the battery.
  • Page 25 21℃ ~ 30℃ 3 Months 31℃ ~ 45℃ The VP-700 has a battery installed inside the product. Therefore, if the battery usage time is less than 30% of the usual time, please contact the dealer where you purchased it to take action.
  • Page 26 VP-700 User Manual Set up the VP-700 Auxiliary Power Unit (Option) It is used as a power source for APs with DC 9V 0.5A or less. Figure 6-1. Power Out Port Terminal ▪ Accessory Cable Connection WARNING: For accurate patient biometric information measurement, please use the Accessory enclosed with the product or our recognized Accessory.
  • Page 27 VP-700 User Manual Description of Display and Symbols 7. Description of Display and Symbols Front Panel Controls and Display Figure 7-1. Front Panel Controls and Display ▪ Table 7-1. Front Panel Description ▪ Name Function Note 7inch LCD 7inch LCD...
  • Page 28 VP-700 User Manual Description of Display and Symbols Rear Panel Components Figure 7-2. Rear Panel ▪ Table 7-2. Rear Panel Description ▪ Name Function Note Moving handle Use to move the product Equalization ground Terminal for connecting ground wire Power Switch...
  • Page 29 VP-700 User Manual Description of Display and Symbols Left Panel Components Figure 7-3. Left Panel ▪ Table 7-3. Left Panel Description ▪ Name Function Note ECG Connector Connector for measuring ECG SpO₂ Connector Connector to measure SpO₂ Connection port for non-invasive blood pressure...
  • Page 30 VP-700 User Manual Description of Display and Symbols Left Panel Components – Temperature(Option) Figure 7-4. Left Panel– Temperature (Option) ▪ Table 7-4. Left Panel Description – Temperature (Option) ▪ Name Function Note Temp Probe Sensor Temp Probe Sensor Probe Chamber...
  • Page 31 VP-700 User Manual Description of Display and Symbols Right Panel – Printer(Option) Figure 7-5. Right Panel – Printer(Option) ▪ Table 7-5. Right Panel Description – Printer(Option) ▪ Name Function Note PRINT POWER LED Print Power LED PRINT ERROR LED Print Error LED...
  • Page 32 VP-700 User Manual Description of Display and Symbols Display of Main The main screen displays ECG, respiration, SpO₂, NIBP, IBP(option), EtCO₂(option), temperature(1~2 TEMP, optional). Figure 7-6. Non-Touch: Main Display ▪ Table 7-6. Non-touch: Main Display Description ▪ Name Function Bed No...
  • Page 33 VP-700 User Manual Description of Display and Symbols Figure 7-7. Touch: Main Display ▪ Table 7-7. Touch: Main Display Description ▪ Name Function Bed No Used to set the patient's location First Name Shows the patient's name. Alarm and function icons...
  • Page 34 VP-700 User Manual Description of Display and Symbols Symbols The following symbols describe the symbols inside/outside the VP-700. Please check the symbols before use. Table 7-8. Product Symbols ▪ Symbol Description Symbol Description Type CF Product, Alarm On/Off Defibrillation protected...
  • Page 35 VP-700 User Manual Description of Display and Symbols Icons The icons on the top of the VP-700 are explained below. Please check before using the product. Table 7-9. Screen Icons ▪ Meaning Icon Display Action Full wave 7 Leads ECG...
  • Page 36 Description of Display and Symbols Screen Change Pressing the Screen menu icon( ) allows you to sequentially view the following menu window. VP-700 provides a 6screens. Full Waves Figure 7-8. Full Waves Display ▪ The full waveform screen can display waveforms or numeric data from all connected modules.
  • Page 37 VP-700 User Manual Description of Display and Symbols 7 Lead ECG screen is a screen that displays only ECG wave data in basic numerical data. When using 5 Lead cable, 7Lead (I, II, III, aVR, aVL, aVF, V1) ECG waveform is displayed.
  • Page 38 VP-700 User Manual Description of Display and Symbols NUMERIC Figure 7-11. Numeric Display ▪ The numeric screen displays measurements in large format. TREND Figure 7-12. Trend Display ▪ The Trend screen allows you to check the patient's vital sign information measured in the...
  • Page 39 VP-700 User Manual Description of Display and Symbols EVENT Figure 7-13. Event Display ▪ Events are electronic records of episodes of the patient's condition, and the Event screen allows you to review the saved Event data. Save event data manually using the manual event record button ( ) or automatically save event data when an alarm occurs.
  • Page 40 VP-700 User Manual Description of Display and Symbols Display Color Description The VP-700's LCD monitor shows different colors on the screen depending on the function and alarm type. Table 7-10. Display Color Description ▪ Function Color Green (LEAD I, II, III, aVR, aVL, aVF, V1) SpO₂...
  • Page 41 VP-700 User Manual How to operate VP-700 8. How to operate VP-700 Description of warning and caution WARNING The patient monitor is for monitoring of Patient’s vital sign information. For the exact diagnoses, the general judgment with other clinical information is needed.
  • Page 42 3 months or completely discharge. Please recharge for the good performance. " NOTE When the VP-700 is not in use, connect the VP-700's power cord to AC power, and the VP-700 can be used as a fully charged battery whenever necessary. NOTE The operation time of battery is various according to the recharged times even if it is fully charged.
  • Page 43 VP-700 User Manual How to operate VP-700 Figure 8-1. Non-Touch: Main Display ▪ When the patient monitor detects the patient's vital signs, the waveform is displayed in real time. When turning off the product, press the power button for 1 to 2 seconds and the “POWER OFF”...
  • Page 44 VP-700 User Manual How to operate VP-700 SET UP The settings required for using the product can be set or changed by the following instructions. SET UP – Non-Touch Press the center of the ENCODER to set up the Non-Touch product. This will display a pull- down menu at the top of the screen.
  • Page 45 VP-700 User Manual How to operate VP-700 TIME/DATE Set the date and time displayed on the product screen, or can be changed. YEAR: You can select a year from the range 2000 ~ 2063. MONTH: You can select a month from the range January ~ December.
  • Page 46 4. The entered Patient ID must be an ID registered on the hospital server. - DISCHARGE: Deregisters a patient registered with VP-700. All patient data for that patient will be deleted. DISCHARGE can only be selected if ADMISSION is enabled.
  • Page 47 VP-700 User Manual How to operate VP-700 system. Heart rate is determined by these opposite nervous system harmonized with each other. Autonomic nervous system affecting to SA node has changed momentarily by variation of the interior/exterior of the body circumstances.
  • Page 48 In demo mode, the actual measured value is not displayed. LANGUAGE VP-700 supports a total of 12 languages. Please set the language of the country where you are using the product and then use it. List of supported languages: ENGLISH, FRENCH, GERMAN, ITALIAN, SPANISH, PORTUGUESE,...
  • Page 49 VP-700 User Manual How to operate VP-700 SET UP – Touch To set up a touch product, touch the menu button at the bottom right of the monitor. Pop- up menu will then appear on the screen. You can set the product to your desired state by touching SETUP in the menu.
  • Page 50 VP-700 User Manual How to operate VP-700 Figure 8-7. HRV Display ▪ DEMO: you can test and learn how to operate. GRAPH TEXT: you can view the waveform settings on each waveform screen. SETUP 2 TOUCH CALICRATE: If the use of the touch screen is unstable, perform touch calibration.
  • Page 51 4. The entered Patient ID must be an ID registered on the hospital server. - DISCHARGE: Deregisters a patient registered with VP-700. All patient data for that patient will be deleted. DISCHARGE can only be selected if ADMISSION is enabled.
  • Page 52 VP-700 User Manual How to operate VP-700 PARAMETER Setting Figure 8-8. Non-Touch: ECG Setting ▪ To set parameters for non-touch products, press the center of the ENCODER and a pull- down menu will appear at the top of the screen. You can set it to your desired state by selecting the desired parameter from the pull-down menu.
  • Page 53 How to operate VP-700 SMART KEY The VP-700 Touch product provides a Smart Key function and can be used on the screen. Smart Key is a function that allows you to operate the control button on the front of the product by touching it.
  • Page 54 VP-700 User Manual How to operate VP-700 Default Set Table 8-1 shows the product's default settings and alarm values when purchasing the product. NOTE The initial Patient category is set to Adult when the product is shipped Table 8-1. Default Set ▪...
  • Page 55 VP-700 User Manual How to operate VP-700 UNIT mmHg mmHg mmHg TREND SCREEN(OFF) SCREEN(OFF) SCREEN(OFF) MODE MANUAL MANUAL MANUAL INTERVAL 30 min 30 min 30 min TIME 5 min 5 min 5 min NIBP STAT SCREEN (SUNTECH) INITIAL PRESSURE VENOUS STASIS...
  • Page 56 How to operate VP-700 TREND The VP-700 periodically saves all measurement data every 1 minute or 15 seconds when measuring the patient's vital signs, depending on the settings. For user convenience, the VP-700 provides Graph Trend Data, allowing you to more easily check the patient's condition.
  • Page 57 VP-700 User Manual How to operate VP-700 TREND Setting For non-touch products, when you press ENCODER on the Trend screen, the Trend setting menu appears at the bottom of the screen. Figure 8-12. Non-Touch: Trend Setting ▪ For touch products, the Trend setting menu is displayed when you touch the menu at the bottom right of the Trend screen.
  • Page 58 VP-700 User Manual How to operate VP-700 TRACE 1~3 Select the parameter you want to check. INTERVAL Trend data display time can be displayed in units of 15 seconds / 1 minute / 5 minutes / 10 minutes depending on the storage cycle.
  • Page 59 VP-700 User Manual How to operate VP-700 EVENT If an alarm condition occurs while measuring a patient's vital signs, it is saved as event data, and the saved event data can be checked on the event display. Up to 20 event data are stored, and if 20 is exceeded, the oldest data is deleted.
  • Page 60 VP-700 User Manual How to operate VP-700 NOTE You can adjust the position of the wave using ENCODER. EVENT Setting For non-touch products, pressing ENCODER on the Event screen will display the Event Settings menu at the bottom of the screen.
  • Page 61 VP-700 User Manual How to operate VP-700 Trace 1~4 On the Event screen, select the parameter corresponding to the waveform you want to check. Print Select the waveforms 1 to 3 you want to print. INITIAL EXECITE: Delete all saved Event data.
  • Page 62 Low Alarm is low) In addition to HIGH, MIDDLE, and LOW Alarm, VP-700 notifies the user through an information alarm when a user needs to know or an error occurs. The information alarm sounds like a bell, and rings at an interval of 15 seconds to alert the...
  • Page 63 VP-700 User manual Alarm and Limit For example, an information alarm occurs in the following situations. If there is a failure in the NIBP measurement or overpressure error. ⚫ At Lead fault or Lead off during ECG measurement. ⚫ If the finger is not attached to the finger probe during measurement of SpO₂.
  • Page 64 VP-700 User manual Alarm and Limit Alarm Default Setting Table 9-4 below shows the default alarm settings for each patient category. The user can adjust the alarm set value within the range as needed. NOTE The initial Patient category is set to Adult when the product is shipped Table 9-4.
  • Page 65 VP-700 User manual Alarm and Limit Alarm Setting If the user want to change alarm setting, the range of alarm can be adjusted when selecting the alarm menu at each function. Press the center of the ENCODER to set up the Non-Touch product. This will display a pull- down menu at the top of the screen.
  • Page 66 VP-700 User manual Alarm and Limit Alarm Warning Sign If a corresponding alarm occurs during measurement, an alarm sound is generated and the measured value on the screen flashes in the color corresponding to the set alarm type. The alarm level is displayed in red, yellow according to the alarm type at the top of the screen, and the details of the alarm that occurred are also displayed in text.
  • Page 67 Keep the safety distance from the patient before installing. Install the patient monitor in a safe place. WARNING Use only ECG cable supplied with VP-700. The other brand of ECG Cable may be the cause of the damaging patient monitor. And the safety of the patient cannot be protected when the defibrillator is used.
  • Page 68 Right-Arm, Left-Arm, Left-Leg (3-Lead) ⚫ Right Arm, Left Arm, Right Leg, Left Leg. Chest (5-Lead) ⚫ VP-700 displays the signs from electrode after amplification. Setup Connection Preparations To display the best ECG information on the screen, the electronic sign should be transmitted in good condition.
  • Page 69 VP-700 User Manual ECG Monitoring Connect the ECG cable to the green ECG socket to the left side of the monitor. ⚫ Connect ECG electrode: To avoid any incorrectness of the wave or measuring value, ⚫ please use only the electrode from the same manufacturer.
  • Page 70 VP-700 User Manual ECG Monitoring Table 10-1. Electrode attachment position ▪ AAMI attachment position Lead Color Lead Color Below the collarbone near the right shoulder White (scapula) Below the collarbone near the left shoulder Black Yellow (scapula) Green Lower left abdomen...
  • Page 71 PCV is detected before finishing T wave in the normal ECG R-on-T Wave. WARNING: VP-700 may happen wrong alarm or not operate alarm for arrhythmia analysis sometimes. Because there are many various patients. WARNING: The arrhythmia analysis is to use monitoring for patient’s rhythm and hospital staffs seriously pay attention for emergency patient.
  • Page 72 Figure 10-6. ST Level ▪ The VP-700's ST I/II/III/aVR/aVL/aVF/V1 is designed to perform ST level analysis independently for each ECG Lead. For example, Alarm occurs when ST I analyzing value is out of setting alarm range. And the ST I Level value is blinkering. But the rest of ST Level value shall be not influenced.
  • Page 73 VP-700 User Manual ECG Monitoring ECG Setting The table below shows the range of changes to the ECG setting mode. Table 10-5. ECG Setting Mode ▪ Mode Range Description LEAD LEAD I / II / III / aVR / aVL / aVF / V...
  • Page 74 VP-700 User Manual ECG Monitoring ECG Out(Option) VP-700 provides ECG analog/pulse wave output from rear stereo connector. It can be used with defibrillator sync input or other medical devices. Figure 10-7. ECG Out Port Terminal ▪ Connect the cable to the rear radio connector of the VP-700.
  • Page 75 VP-700 User Manual SpO₂ Monitoring 11. SpO₂ Monitoring Description of warning and caution WARNING Use the authorized SpO₂ from the manufacturer. The quality cannot be guaranteed when the user use the other brand. WARNING If the senor is too tightened with fixing tape (wrong case), the patient may have the damage on the skin.
  • Page 76 Check every 2 hour when the patient has low blood flow. WARNING Use the Probe and Extension Cable provided by VOTEM Co., Ltd. If the components are not compatible, the performance may deteriorate, so you must check the compatibility (genuine) before use.
  • Page 77 VP-700 User Manual SpO₂ Monitoring CAUTION Check the Sensor because the movement of the patient may cause any trouble in measurement. NOTE Check the following if you do not have any data or in correct data. Put the Sensor at ears or other parts when the patient has low blood flow.
  • Page 78 VP-700 User Manual SpO₂ Monitoring Connection of accessory Connect the SpO₂ cable to the place in connect area to the left side of the monitor Figure 11-1. SpO₂ Cable Connection ▪ SpO₂ Sensor Attachment Figure 11-2. Probe Connection ▪ Put SpO₂ Sensor into the finger.
  • Page 79 VP-700 User Manual SpO₂ Monitoring Display of SpO₂ Display of SpO₂ The figure below shows the SpO ₂ area. Figure 11-3. SpO₂ Area ▪ Table 11-1. SpO₂ Area Description ▪ Description Name SpO₂ waveform Shows real-time SpO₂ waveforms. Alarm Range Shows the alarm range.
  • Page 80 VP-700 User Manual SpO₂ Monitoring NOTE Please be noted that it can not be. Trusted the reliability in case of extend the 100 bpm of pulse. In that case try again after resting. NOTE The APG still has not tested clinically.
  • Page 81 General knowledge of pulse oximetry and an understanding of the features and functions of the VP-700 Masimo SET Pulse Oximeter are a prerequisite for its proper use. Do not operate the VP-700 Masimo SET Pulse Oximeter without completely reading and understanding the instructions in this manual.
  • Page 82 VP-700 User Manual SpO₂ Monitoring condition. The Pulse Oximeter is to be operated by qualified personnel only. ⚫ This manual, accessory directions for use, all precautionary information, and ⚫ specifications should be read and understood before use. Electric shock hazard. Do not open the pulse oximeter cover except to replace the ⚫...
  • Page 83 (SpO₂) and pulse rate (measured by a SpO₂ sensor). The VP-700 Pulse Oximeter and accessories are indicated for use with adult, pediatric, infant and neonatal patients during both motion and no motion conditions, and for patients who are well or poorly perfused in hospitals, hospital-type facilities, mobile and home environments.
  • Page 84 VP-700 for calculation. Figure 11-4. Principle of Operation ▪ Once the VP-700 receives the signal from the sensor, it utilizes Masimo SET signal extraction technology for calculation of the patient’s functional oxygen saturation and pulse rate. WARNING: Explosion hazard: Do not use the VP-700 with Masimo SET pulse oximetry in the presence of flammable anesthetics or other flammable substance in combination with air, oxygen-enriched environments, or nitrous oxide.
  • Page 85 VP-700 User Manual SpO₂ Monitoring Connection of the Accessory Figure 11-5. Masimo SpO₂ Cable Connection ▪ Masimo SpO₂ Setting SENSITIVITY The three sensitivity settings allow the clinician to adapt the SpO₂ measurement sensitivity to the patient's level of SpO₂ signal strength and quality at the measurement site.
  • Page 86 VP-700 User Manual SpO₂ Monitoring FASTSAT FastSat enables rapid response to, and display of, rapid changes in SpO₂ by giving priority to the most recent data. This aids the clinician in clinical settings requiring fast response time such as those seen with induction, intubation, sleep studies and resuscitation.
  • Page 87 User Selectable Settings: 5% (Default) / 10% /Off Measurements If the accuracy of any measurement does not seem reasonable, first check the patient’s vital signs by alternate means and the check the VP-700 with Masimo SET pulse oximetry for proper functioning. Inaccurate measurements may be caused by Incorrect sensor application or use.
  • Page 88 ▪ The patient is in cardiac arrest or is in shock. ▪ Alarm Whenever using the VP-700 with a Masimo SET pulse oximeter, check the alarm settings to ensure they are appropriate for the patient being monitored. Message Information messages The following chart alphabetically lists all system messages displayed on the LCD screen.
  • Page 89 VP-700 User Manual SpO₂ Monitoring Table 11-4. Masimo SpO₂ Information messages ▪ MESSAGE POSSIBLE CAUSE(S) RECOMMENDATION BOARD FAILURE Internal Failure. Unit requires service. Oximeter cannot identify Broken sensor cable wire or inoperative LEDs or DEFECTIVE connected sensor or the sensor has faulty detector;...
  • Page 90 Grounding Connect the VP-700 with Masimo SET pulse oximetry only to a three-wire, grounded, hospital-grade receptacle. The three-conductor plug must be inserted into a properly wired three-wire receptacle; if a three-wire receptacle is not available, a qualified electrician must...
  • Page 91 If there is any doubt about the integrity of the protective earth conductor arrangement, operate the VP-700 with Masimo SET pulse oximetry on internal battery power until the AC power supply protective conductor is fully functional. To ensure patient electrical isolation, connect only to other equipment with electronically isolated circuits.
  • Page 92 VP-700 User Manual SpO₂ Monitoring LNCS® Reusable sensors LNCS reusable sensors must be used in conjunction with Masimo pulse oximetry Table 11-7. LNCS® Reusable sensors Specification Saturation Accuracy Pulse Rate Accuracy Low Perfusion Accuracy Weight Sensor Range Motion Saturation Pulse Rate...
  • Page 93 VP-700 User Manual SpO₂ Monitoring LNCS® SPECIALTY SENSORS LNCS specialty sensors must be used in conjunction with Masimo pulse oximetry. Table 11-9. LNCS® SPECIALTY SENSORS Specification Low Perfusion Saturation Accuracy Pulse Rate Accuracy Weight Accuracy Sensor Range Pulse Motion Motion...
  • Page 94 VP-700 User Manual SpO₂ Monitoring NOTE If the sensor fails to track the pulse consistently, the sensors may be incorrectly positioned. Reposition the sensor or choose a different monitoring site.. CAUTION: DO NOT REPROCESS ANY MASIMO SINGLE USE SENSORS Specifications Table 11-10.
  • Page 95 VP-700 User Manual TEMP Monitoring 12. TEMP Monitoring Description of warning and caution WARNING To have the exact temperature of the patient, use only the temperature sensor from the manufacture. WARNING For the safety of the patient, connect the sensor with the patient after electron isolation from the other equipments.
  • Page 96 VP-700 User Manual TEMP Monitoring Connection of Accessory Connect Temp Sensor connector to the main unit. Figure 12-1. Temp Cable Connection ▪ TEMP Sensor Attachment Connect the temp sensor to the patient. NOTE Do sterilize it before using it to another patient.
  • Page 97 VP-700 사용설명서 TEMP Monitoring-F3000(Option) 13. TEMP Monitoring - F3000(Option) Description of warning and caution WARNING To have the exact temperature of the patient, use only the temperature sensor from the manufacture. WARNING For the safety of the patient, connect the sensor with the patient after electron isolation from the other equipments.
  • Page 98 VP-700 사용설명서 TEMP Monitoring-F3000(Option) temperature of the patient is displayed on the screen. Setup Connection Preparations Make certain that the Blue isolation chamber/probe unit is attached to measure ⚫ oral and axillary temperature Make certain that the red isolation chamber/probe unit is attached to measure ⚫...
  • Page 99 VP-700 사용설명서 TEMP Monitoring-F3000(Option) Axillary Temperature Taking Have the patient raise the arm, then place the probe tip in the axilla. Figure 13-3. Axillary temperature probe ▪ Keep the patient arm down and as immobile as possible. Fix the probe parallel to the arm.
  • Page 100 VP-700 사용설명서 TEMP Monitoring-F3000(Option) Display of TEMP - F3000 Temperature(Option) Display of TEMP - F3000 Temperature(Option) The picture below shows the Temp area. Figure 13-4. Temp Area ▪ TEMP Message Temp messages are displayed in the temp area. Table 13-1. Temp Message ▪...
  • Page 101 VP-700 사용설명서 TEMP Monitoring-F3000(Option) Err – S 3 Could not auto-calibrate the Heater ADC channel. Err – S 4 Watch Dog Timer error (typically due to poor reset). Err – S 5 Overheated probe. Err – S 6 LCD Communications failure (Not Applicable for OEM) Err –...
  • Page 102 VP-700 사용설명서 TEMP Monitoring-F3000(Option) command of the format “OMXM or AMXM”. When F3000 is in Continuous Direct Monitoring mode, it will send the following Celsius-based temperature message about once every second. Rectal Temp Setting Figure 13-7. Temp Setting – Rectal ▪...
  • Page 103 14. RESP Monitoring Description of warning and caution WARNING Use VP-700 only for supervising the respiration. Do not use it for supervising sleep apnea. WARNING Respiration function is very sensitive with electronic wave. Incorrect measured value may occur due to the above reason. Do not judge the status of the patient only with the respiration figure and wave.
  • Page 104 VP-700 User Manual RESP Monitoring Display of RESP Display of RESP The picture below shows the Resp area. Figure 14-1. RESP Area ▪ Table 14-1. RESP Area Description ▪ NAME Description RESP wavefome Shows real-time RESP waveforms. RESP measurements Shows real-time RESP measurements.
  • Page 105 WARNING Do not use with other Hear, Lung measuring equipment. WARNING VP-700 may not work with the patient who have cramps. WARNING When measuring the new patient, please reset the alarm. WARNING Use NIBP Cuff only for measuring blood pressure. No measurement at the upper part of arm when the artificial sap or catheter is inserted into the blood vessel.
  • Page 106 VP-700 User Manual NIBP Monitoring WARNING Measuring time may be longer than normal case if the patient has arrhythmia. WARNING Auto Function will be off if the user changes the interval set during the automatic measurement. Auto compression normally works only after the user resets in case that the auto measuring mode is off.
  • Page 107 When not measuring, cancel the AUTO MODE. The life time of the valve, pump, cuff is shortened. NOTE The VP-700 remembers previously measured data and applies higher or lower pressure based on Systolic when measuring again. Therefore, if the patient being measured changes, turn the product on/off once before using it. (Example: When measuring a patient with low blood pressure immediately after measuring a patient with high blood pressure, more pressurization than necessary may be applied.)
  • Page 108 VP-700 User Manual NIBP Monitoring Connection of accessory to patient How to connect NIBP Cuff NIBP Hose should be locate inside to arm-direction because NIBP value can be ⚫ changed according to the location of Cuff. Refer to Fiqure 20-2. for Cuff installation.
  • Page 109 VP-700 User Manual NIBP Monitoring Table 15-1. NIBP Area Description ▪ 번호 Name Description Mode Shows the set measurement mode. Shows RT (measurement waiting time) Measurement time / MT (measurement completion time). average blood pressure Shows the average value of measured blood pressure.
  • Page 110 VP-700 User Manual NIBP Monitoring Measured values are displayed SCREEN ON /OFF sequentially Adult, Pediatric 100~300(mmHg) Setting limit values for MAX LIMITE Neonate 70~150(mmHg) pressurization Adult, Pediatric 50 ~ 200 / mmHg VENOUS Pressure value in VENOUS STASIS PRESSURE STASIS...
  • Page 111 VP-700 User Manual NIBP Monitoring PRESSURE MAX PRESSURE: 100 ~ 300 mmhg(Adult, Pediatric), 70~150 mmHg(Neonate) VENOUS STASIS: 50 ~ 200 mmHg(Adult, Pediatric), 50 ~ 150 mmHg(Neonate) INITIAL PRESSURE: 160 ~ 290 mmHg(Adult, Pediatric), 70 ~145 mmHg(Neonate) 참고 The INITIAL PRESURE setting is available from NIBP ver 2.29X (ex. 2.29A) and later.
  • Page 112 VP-700 User Manual NIBP Monitoring Suntech NIBP(Option) SAFETY INFORMATION, WARNINGS, CAUTIONS AND NOTES Oscillometric method is used for NIBP function. ⚫ Calculate the measuring value during the process of compression and ⚫ decompression done by LPC (Linear Pressure Controlled) NIBP module.
  • Page 113 VP-700 User Manual NIBP Monitoring The module may not operate correctly if used or stored outside the relevant ⚫ temperature or humidity ranges described in the Performance specifications. Suntech NIBP Setting Table 15-4. Suntech NIBP Setting Mode ▪ Mode Range...
  • Page 114 VP-700 User Manual NIBP Monitoring STAT STAT is to repeat the measuring blood pressure at maximum times during the setting time. Time set: 5 ~ 15 minute (1 minute interval) NIBP STAT SCREEN appears when the use selects Screen-On. The measured values are displayed ins serial order.
  • Page 115 VP-700 User Manual NIBP Monitoring Message Table 15-5. Suntech NIBP Message ▪ Message Description none GOOD BP READING Check that the cuff is in the correct position. Check the patient. Check that the cuff is properly tightened. WEAK PULSE Check that there is no excessive clothing between the arm and the cuff.
  • Page 116 VP-700 User Manual IBP Monitoring(Option) 16. IBP Monitoring(Option) Description of warning and caution WARNING Use only the authorized IBP kit from the manufacture. The incorrect or wrong result may happen with other bands. WARNING Keep it well after use because the damages of the patient or the monitor may occur.
  • Page 117 VP-700 User Manual IBP Monitoring(Option) NOTE During the operation of Electronic Surgical Unit, the user can operates only with the transducers which are certified with the guarantee of protection. NOTE The measured value may not be correct when the defibrillation is moved. The measured value shall be normalized when the normal status keeps consistently.
  • Page 118 VP-700 User Manual IBP Monitoring(Option) IBP Sensor Attachment The below picture is IBP Sensor Cable Configuration. Figure 16-3. IBP Sensor Cable ▪ II. The rear part of the transparent covering transducer connector and locate it with the same position of the lot part of monitor interface cable. Then insert softly.
  • Page 119 VP-700 User Manual IBP Monitoring(Option) IV. Flush System use Hold the both side of Flush operator and pull it to upper side slightly. ⚫ Be sure not to turn the Flush operator. Do press with even power. ⚫ Figure 16-6. Use Flush Device ▪...
  • Page 120 VP-700 User Manual IBP Monitoring(Option) NOTE How to Priming use Priming should be done slowly. ▪ The user shall have less efforts of removing the bubble afterwards. Do priming with Gravity. ▪ During the input, the liquid may leaks or the bubble may occur. Pull up the supplying back when the little bubble flows too slowly.
  • Page 121 VP-700 User Manual IBP Monitoring(Option) Table 16-1. IBP Area Description ▪ Name Description IBP waveform Shows real-time IBP waveforms. LABEL Shows the label on the blood pressure measurement area. shows the measurement of the PR (pulse rate). average blood pressure Shows the average value of measured blood pressure.
  • Page 122 VP-700 User Manual IBP Monitoring(Option) NOTE The Alarm setting range is changed according to the label. ZERO To obtain accurate results, the transducer's zero point must be adjusted before the patient can be measured. Fixed: Basic value according to the established label ⚫...
  • Page 123 VP-700 User Manual IBP Monitoring(Option) IBP Out(Option) VP-700 provides IBP analog wave output from rear stereo connector. It can be used with defibrillator sync input or other medical devices. CAUTION: Pacemaker, respiration signal is not supported. Figure 16-10. IBP Out Port Connection ▪...
  • Page 124 If the equipment is revised, the proper inspection and test should be done for the continuous safe operation. WARNING EtCO₂ Module is not designed for MRI surrounding WARNING VP-700 should be located at different space with MRI while MRI is operating. WARNING Incorrect measurement value may occur or be interfered when high frequency electro...
  • Page 125 WARNING The gas suction vacuum pressure (negative pressure) of the gas scavenging system shall not exceed 1 mmHg based on the VP-700 pump discharge. Excessive pressure can damage the pump within the EtCO₂ module. WARNING In order to prevent infection of the medical staff by the patient's respiratory sample, the outlet must be connected to the gas scavenging system in the hospital..
  • Page 126 VP-700 User Manual EtCO₂ Monitoring(Option) Setup Connection Connection of Mainstream Connect EtCO₂ module connector into the main body EtCO₂. Connect sensor with Y-hose which is connected with the patient. Figure 17-1. Mainstream Cable Connection ▪ When connecting the EtCO₂ module connector, insert it into the connector until a “click”...
  • Page 127 VP-700 User Manual EtCO₂ Monitoring(Option) Mainstream, Sidestream EtCO₂ Calibration Calibration of EtCO₂ must be performed in the following cases. When the measurement patient changes ⚫ When turning the product ON/OFF ⚫ When removing/attaching the EtCO₂ module and sensor ⚫ When the “ZERO REQUIRED” message is displayed during measurement ⚫...
  • Page 128 VP-700 User Manual EtCO₂ Monitoring(Option) NO BREATHS DETECTED Respiration is not detected, or SAMPLE LINE is disconnected with patient. CHECK ADAPTER SAMPLE LINE or ADAPTER has humid or foreign substances. ZERO IN PROGRESS ZERO CALIBRATION is in progress. ZERO CALIBRATION is needed. ZERO CALIBRATION is in progress at this ZERO REQUIRED moment.
  • Page 129 The printer may not work or print not clearly when the cover is not closed correctly. General The VP-700 features a dedicated printer that prints three waves at a time to print a variety of information. Depending on the type of printing, the output type produces text information or a wave...
  • Page 130 VP-700 User Manual Printing(Option) Printer Setting Press the center of the ENCODER to set up the Non-Touch product. This will display a pull- down menu at the top of the screen. You can set the product to your desired state by selecting SETUP-PRINT.
  • Page 131 VP-700 User Manual Printing(Option) The table below shows the change range for the print setting mode. Table 18-1. Printer Setting Mode ▪ Mode Range Description ALARM Print when alarm settings are satisfied SYNC MANUAL Print by pressing the print button...
  • Page 132 When the green lamp is on, it works properly. When the red lamp is on, it does not work. CAUTION: Please contact Votem Co., Ltd or the regional distributors for the details on the installation of the printer. CAUTION: Battery consumption increases when using the printer in Battery mode.
  • Page 133 If you have any trouble with the monitor, please check with the below table. Check again before contacting to the A/S center. After self-checking, please contact Votem Co., Ltd or the regional distributor if the troubles are not solved Resolution Display Trouble Table 19-1.
  • Page 134 VP-700 User Manual Troubleshooting ECG / RESPIRATION Measurement Trouble Table 19-2. ECG/RESP Measurement Issues ▪ Symptoms Description No display “LEAD FAULT” 1. Check ECG cable and the gel at electrode. Message 2. Check with other ECG cable 1. Check the cable connection No ECG WAVE 2.
  • Page 135 VP-700 User Manual Troubleshooting TEMP Measurement Trouble Table 19-7. TEMP Measurement Issues Symptoms Description 1. Check that the probe adapter is properly connected to the acquisition module. 2. Check that the probe is properly connected to the probe adapter. 3. Make sure you are using the correct probe for the monitored anatomical Temperature is not measured location.
  • Page 136 VP-700 User Manual Product Specification 20. Product Specifications Measurement parameters 3ch ECG, NIBP, SpO₂, 2IBP, 2 Temp, EtCO2 or Respiration. ⚫ PROCESSING PARAMETERS: HR, NIBP(Systolic/Diastolic/Mean pressure), SpO₂ Saturation, ⚫ Pulse rate, Respiration, IBP 2, Temp 2, EtCO2 Monitor Display ⚫...
  • Page 137 VP-700 User Manual Product Specification Information: OFF, 10~100% ◼ Language ⚫ English ◼ French ◼ German ◼ Italian ◼ Spanish ◼ Portuguese ◼ Portuguese-BR ◼ Turkish ◼ Russian ◼ Czech ◼ Rumanian ◼ Polish ◼ ECG Wave ⚫ Lead: ◼...
  • Page 138 VP-700 User Manual Product Specification ST Analysis Range ⚫ Measurement Range: -9.9 mV ~ +9.9 mV ◼ Resolution: ± 0.1 mV ◼ J Point: J + 0, 20, 30, 40, 50, 60, 70, 80 msec ◼ Pacemaker Detect ⚫ Defibrillator Sync ⚫...
  • Page 139 VP-700 User Manual Product Specification Averaging: Set of SpO2 Measure Detect Time 2~10 sec ⚫ Low Perfusion: 0.05 % up to ⚫ Setting Time ⚫ Wave out Time: Max. 2 sec ◼ SpO2 Percentage Display: Max. 10 sec ◼ Alarm Range ⚫...
  • Page 140 VP-700 User Manual Product Specification Alarm Range ⚫ High alarm limit: 0.1 ~ 50 ℃ ◼ Low alarm limit: 0 ~ 49.9 ℃ ◼ Respiration ⚫ Measurement Range: 5~150 bpm(for rates less than 5 bpm, the displayed rate is 0) Accuracy: ±...
  • Page 141 VP-700 User Manual Product Specification Venous Stasis Pressure ⚫ Adult: 50 ~ 200 mmHg ◼ Neonate: 50 ~ 150 mmHg ◼ Initial Inflation Pressure ⚫ Adult: 160 ~ 290 mmHg ◼ Neonate: 70 ~ 145 mmHg ◼ Alarm Range ⚫...
  • Page 142 VP-700 User Manual Product Specification Recommended Frequency of Pressure Transducer Calibration: The Pressure Transducer ⚫ calibration should be verified on a yearly interval Operating Conditions: 0°C to 50°C, 15% to 95% non-condensing humidity ⚫ Storage Conditions: -20°C to 65°C, 15% to 95% non-condensing humidity ⚫...
  • Page 143 VP-700 User Manual Product Specification Alarm Range ⚫ PRESSURE High Systolic [mmHg] Diastolic -45 ~ 350 -50 ~ 345 Mean Unit: mmHg, kPa ⚫ EtCO₂ - Option Mode: Respironics® Mainstream & Sidestream Measurement ⚫ Range: 0 to 150mmHg, 0 to 19.7%, 0 to 20kPa Measurement ⚫...
  • Page 144 VP-700 User Manual Product Specification Power Rating ◼ Rated input: 1.1 Watts typical. Steady State Up to 1.5 Watts maximum on power up (warm up) Sidestream ⚫ Initialization Time: Capnogram displayed in less than 20 seconds, at an ambient ◼...
  • Page 145 VP-700 User Manual Product Specification Printing paper width: 57 mm ⚫ Select print length: 150 ~ 300mm (change in 25mm increments) ⚫ TREND Parameters: Heart Rate, SpO₂, Pulse Rate, NIBP, IBP 2, Temperature 2, EtCO₂. ⚫ Data storage for 7 days(Based on 1 minute save cycle setting) ⚫...
  • Page 146 VP-700 User Manual Product Specification HUMIDITY ⚫ USE: 30 TO 85% ◼ STORAGE AND STORAGE: 20 TO 95% ◼ BAROMETRIC PRESSURE ⚫ USE: 700 TO 1060 KPA ◼ STORAGE AND STORAGE: 700 TO 1060 KPA ◼ Standard Accessories ECG Cable (5 leads) - 1ea ⚫...
  • Page 147 VP-700 User Manual Product Specification Wall Mount ⚫ DISPOSABLE SPO₂ SENSOR ⚫ Child / Neonate CUFF ⚫...
  • Page 148 Warranty 21. Warranty WARNING VOTEM and its local sales representatives do not take responsibilities about the defects or damages of our products that happens due to the wrong doings or negligence of the maintenance of customers. This product has been produced through the strict quality check and test.
  • Page 149 VP-700 User Manual Sales & Service Information 22. Sales & Service Information VOTEM CO., LTD << Manufacturer / Head Office >> Geodudanji 1-gil, Dongnae-myeon, Chuncheon-si, Gangwon-do, Korea (zip. 24398) Tel: +82-33-910-0701, Fax: +82-33-911-0701...
