R7184A,B,G,P,U
Electronic Oil Primary,
EnviraCOM™ Enabled
APPLICATION
The R7184A,B,G,P,U Electronic Oil Primary is a line
voltage, safety rated, oil primary control for residential oil
fired burners used in boilers, forced air furnaces and
water heaters. The R7184A,B,G,P,U used with a cad cell
flame sensor, operates an oil burner and optional oil
valve. The primary controls fuel oil, senses flame,
controls ignition spark (either interrupted or intermittent)
and notifies a remote alarm circuit when in lockout.
The R7184 can be used with both hydronic and forced air
systems. When used with hydronic systems, line voltage
switching Aquastat® Controllers normally provide for the
starting and stopping of the combustion sequences. With
forced air systems, both mechanical and electronic low
voltage thermostats control the starting and stopping of
the combustion process.
Some hydronic and forced air systems now require a
delayed valve-on and burner motor-off delay. The R7184
operates an oil valve that prevents the flow of oil when
the burner motor is running prior to combustion (delayed
valve-on) and when the burner motor is running after
combustion (burner motor-off delay).
The R7184 models are intended for use only on oil
burning appliances which do not require prepurge and
post-purge as a safety related function as defined in
UL296. The valve-on delay and burner motor-off delay in
this control are intended only to help establish draft and
reduce oil after-drip related problems.
EnviraCOM™ enabled R7184's can be used with
EnviraLink® monitoring systems and hand-held
diagnostics. Use only R7184P and U models for
networking with other EnviraCOM™ enabled devices.
FEATURES
Thermostat(s)
The oil primaries are compatible with both standard
thermostats and EnviraCOM™ communicating
thermostats.
INSTALLATION INSTRUCTIONS
Limited Recycle
This feature limits the number of recycle trials (for each
call for heat) to a maximum of three trials. If the flame is
lost three times and does not successfully satisfy a call
for heat, the R7184 locks out.
Pump Priming Cycle
To facilitate purging air from the oil lines and filters, the
R7184 can be placed in a purge routine by pressing and
releasing the reset button during the safety check,
delayed valve-on, ignition or carry-over periods. The
lockout timing will be extended to four minutes and the
ignition set in the intermittent mode for this cycle only.
The R7184 automatically reverts to its labeled interrupted
and safety switch timing states (as applicable). The pump
priming cycle can only be entered if there have been no
lockout occurrences since the last successful heat call.
To reset the device so that the pump priming cycle can
be entered, press and hold the reset button until the light
emitting diode (LED) flashes (approximately 30
seconds).
Data Port
Controls are designed to allow networking and upgrade
modules to be added in the field by simply plugging them
into the data port/network. (See Fig. 2.)
Disable Function
Pressing and holding the reset button will disable all
functions until the button is released. The R7184 will
restart at the beginning of the normal heat cycle on safety
check.
Limited Reset (Restricted Mode)
In order to limit the accumulation of unburned oil in the
combustion area, the control can only be reset three
times. The reset count returns to zero each time a call for
heat is successfully completed.
To reset from restricted mode: Press and hold the reset
button for 30 seconds. When the LED flashes once for
one second, the device has reset.
T-T Jumper
Select models have a pre-installed T-T jumper resistor.
To remove, use side-cutting pliers to cut the jumper. (See
Fig. 2.)
69-1459-06
