IMPORTANT INSTRUCTIONS & OPERATING MANUAL
AURA42 | AURA50 | AURA60 | AURA72
Read and understand this entire owner's manual, including all safety
information, before plugging in or using this product. Failure to do so could result
WARNING
in fire, electric shock, or serious personal injury.
Keep this owner's manual for future reference. If you sell or give this product
CAUTION
away, make sure this manual accompanies this product.
NO VENTING REQUIRED
220-240V AC; 50 Hz; 1400-1600 Watts
Advertisement
Table of Contents
Related Manuals for Lumo AURA42
Summary of Contents for Lumo AURA42
- Page 1 IMPORTANT INSTRUCTIONS & OPERATING MANUAL AURA42 | AURA50 | AURA60 | AURA72 Read and understand this entire owner’s manual, including all safety information, before plugging in or using this product. Failure to do so could result WARNING in fire, electric shock, or serious personal injury.
-
Page 2: Important Instructions
IMPORTANT: It is important to read these instructions carefully before using the appliance for the first time. Keep the instructions safe so that you can refer to them later if necessary. 【IMPORTANT INSTRUCTIONS When using electrical appliances basic precautions should always be followed to reduce the risk of fire, electric shock and injury to persons, including the following: 1. -
Page 3: Unpacking And Testing Appliance
Make sure the width of the wood block on both sides which used to fix the fireplace is 3’’(76mm). Make sure that the revealed wood block width on both sides is about 1 1/2’’ (37.5mm) after finishing the plasterboard. Measure the depth D from the plasterboard surface to the wood block and write it down. M O DEL AURA42 AURA50 AURA60 AURA72 45.7 ’’... - Page 4 Before installing the in-wall fireplace, please read the following steps carefully. 1 - Wall mounted functional fireplace. Make the bulged screw tube onto the wall (Keep the screws with 5mm expose (See Step 2) Remove the two silver colored screws at both sides of the fireplace (See Step 1) Step 1 Step 2 Fix the fireplace onto the wall (See Step 3)
- Page 5 This carton includes GLASS! ALWAYS use extreme caution when handing glass. Failure to do so could result in personal injury or property damage. Warning ALWAYS unplug this fireplace heater before assembly or cleaning, or before relocating. Failure to do so could result in electric shock, fire, or personal injury. Warning 2 - Recessed functional fireplace Installation.
- Page 6 Plug the power cord into a 220-240 Volt 13 Amp outlet. Make sure the outlet is in good condition and that the plug is not loose. NEVER exceed the maximum amperage for the circuit. DO NOT plug other appliances into the same circuit. 【...
-
Page 7: Safety Instructions
【 Safety instructions 】 Only use the appliance in accordance with the instructions in this manual! It cannot be used for any other purpose. Never operate the appliance when the appliance itself or the main cable show any signs of damage. In order to avoid overheating, do not cover the heater. -
Page 8: Control Panel / Remote Control Operation
【 Instruction for Remote Controller and Switch Panel 】 Control Panel / Remote Control Operation (Control panel POWER switch must be ON to use remote control.) The touch display panel is shown by LED's on the front bottom right of the appliance. The LED's will appear on the bottom of the fireplace control panel. -
Page 9: Remote Control Battery Information
When the heater is first turned on, a slight odor may be present. This is normal and should not NOTICE occur again unless the heater is not used for a long period of time. To improve operation, aim the remote control at the front of the fireplace. DO NOT press the NOTICE buttons too quickly. - Page 10 5. Do not use this heater in the immediate surroundings of a bath, a shower or a swimming pool. 6. In order to avoid overheating, do not cover the heater. Model: AURA42 | AURA50 | AURA60 | AURA72 Power supply: 220-240V-50Hz...
