Lumo LQFT 750 Owner's Manual

Insert lcd fireplace heater
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
LCD FIREPLACE HEATER
OWNER'S MANUAL
Insert LCD FIREPLACE
WARNING
CAUTION
Read and understand this entire owner's manual including all safety
information, before plugging in or using this product. Failure to do so
could result in fire, electric shock, or serious personal injury.
Keep this owner's manual for future reference. If you sell or give this
product away, make sure this manual accompanies this product.
LQFT 750

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LQFT 750 and is the answer not in the manual?

Questions and answers

Related Manuals for Lumo LQFT 750

Summary of Contents for Lumo LQFT 750

  • Page 1 LCD FIREPLACE HEATER OWNER’S MANUAL Insert LCD FIREPLACE LQFT 750 Read and understand this entire owner’s manual including all safety information, before plugging in or using this product. Failure to do so WARNING could result in fire, electric shock, or serious personal injury.

  • Page 2: Table Of Contents

    Contents Parts and Hardware ............................. 4 Tools Required ............................4 Unpacking and Setup ..........................4 Unpacking Instructions ..........................4 BOX CONTENTS ..........................4 Wiring ............................... 5 Testing the Fireplace Prior to Installation ..................... 5 Prong Outlet Installation ........................5 Power Data ..............................5 Installation ..............................
  • Page 3 IMPORTANT SAFETY INFORMATION WARNING • THIS FIREPLACE IS HOT WHEN IN OPERATION AND CAN CAUSE SEVERE BURNS • Do not operate fireplace before reading and understanding operation instructions. Failure to operate fireplace according to operation instructions could cause fire or injury. •...

  • Page 4: Parts And Hardware

    Parts and Hardware Tools Required • Phillips screwdriver • Stud finder • Level • Tape measure • Electric drill • Wood drill bit Unpacking and Setup Unpacking Instructions • Remove all parts and hardware from the carton and place them on a clean, soft, dry surface. Check the parts list to make sure no parts are missing.

  • Page 5: Wiring

    • Make sure this plug fits securely into the outlet. Faulty wall outlet connections or loose plugs can cause the outlet to overheat. If the outlet or face plate is hot, discontinue use immediately and have a qualified electrician inspect and/or replace the faulty outlet. Power Data Model LQFT 750 Voltage 220V Watts 1500W Amps 7.5AMP...

  • Page 6: Installation

    Installation WARNINGS • Due to high temperatures, keep the fireplace out of high traffic locations. • Keep combustible materials, such as furniture, pillows, bedding, papers, clothes, and curtains at least 1M away from the front of the fireplace. • Never install the fireplace where it may fall into a bathtub or other body of water. •...

  • Page 7: Recessed Installation

    ONLY! Instructions: 1. Choose a location in the wall to install fireplace. 2. Make an opening in the wall based on metal firebox size. Fire Dimensions Model LQFT 750 Fireplace Height Overall 503mm Fireplace Height Recess 495mm Fireplace Width Overall...

  • Page 8: Recessed Installation

    Recessed Installation:...

  • Page 9: Installing The Crystal Ember And Log-Set

    Installing the Crystal Ember and Log-set Once the fireplace is installed in the wall, place crystal media stones and artificial logs in the fireplace. Installing the Crystal Embers 1. Carefully place crystal embers on plastic strip. Apply an even layer from side to side. Randomly place the crystals on top of the crystals to add an extra dimension to the ember bed.

  • Page 10: Operating Fireplace

    Operating Fireplace Once the fireplace has been plugged into a grounded outlet, the fireplace is now ready for operation. Ensure that the house circuit breakers for the power supply are turned on. Power Plug the power cable into a 230v 7.5 amp grounded outlet. Make sure the outlet is in good condition and that the plug is not loose.

  • Page 11: Method Of Operation

    Method of Operation Control Panel Functions BUTTON ACTION & INDICATION FUNCTION ON: Enables control panel functions and 1. Press once. Indicator light turns on. Power turns remote control. Turns on flame effect. on. All functions enabled. OFF: Disables control panel functions and 2.

  • Page 12: Method Of Operation

    Method of Operation Wireless Remote Control Functions Turn ON/OFF the fireplace Power button Global or single group color adjustable,short press the up and down keys to select among 8 Color ring colors, long press the up and down keys to select among 64 colors Used for adjusting functions such as time, week, temperature, etc.

  • Page 13: Care And Maintenance

    • This remote control uses 2 AAA batteries • To improve operation of the remote control, aim the remote control at the front of the fireplace. DO NOT PRESS the buttons too quickly. Give the unit time to respond to each command.

  • Page 14: Wi-Fi Controls

    Wi-Fi Controls This fireplace is also capable of being controlled over Wi-Fi using an Apple or Android mobile device. Scan the QR code for an instructional walk through video on how to download and setup the app needed to control your Electric fireplace. Alternatively, you can follow the steps below.

  • Page 15: Wi-Fi Controls

    Wi-Fi Controls Next you will be prompted to connect to your existing home wireless network. Select the appropriate 2.4Ghz network and log in. Note - Only 2.4GHz wireless networks are compatible, 5GHz wireless networks cannot be used. If not available, contact your wireless service provider for further information on setting up a 2.4GHz wireless network.

  • Page 16: Wi-Fi Controls

    Wi-Fi Controls With the fireplace now successfully Creating a Heat paired it can be controlled in the same Program manner as the remote controls (see page 15). Added capabilities like Sleep Timer and Heat Program are only possible when using the app.

  • Page 17: Wi-Fi Controls

    Wi-Fi Controls Next, in the pop-up window select the The Heat Program is now set to turn the fireplace and heater on at 1:00PM every desired program settings: Switch - Turn fireplace on or off Wednesday to maintain a temperature of 20˚C until 6:00PM.

  • Page 18: Warranty

    Warranty Our electric fireplaces are to be free of defects in material and workmanship for one year from the date of purchase. This warranty only covers manufacturing faults. This warranty does not cover damages, accidents, lack of maintenance, abuse or neglect. The warranty does not cover paint scratches, cosmetic blemishes, dents, corrosion or other normal wear and tear associated with the fireplace.
