ELECTRIC FIREPLACE HEATER
OWNER'S MANUAL
Three Sided Electric Fires
WARNING
CAUTION
Read and understand this entire owner's manual including all safety
information, before plugging in or using this product. Failure to do so
could result in fire, electric shock, or serious personal injury.
Keep this owner's manual for future reference. If you sell or give this
product away, make sure this manual accompanies this product.
ULTRA 130
ULTRA 150
ULTRA 180
Advertisement
Table of Contents
Related Manuals for Lumo ULTRA 130
Summary of Contents for Lumo ULTRA 130
- Page 1 ELECTRIC FIREPLACE HEATER OWNER’S MANUAL ULTRA 130 Three Sided Electric Fires ULTRA 150 ULTRA 180 Read and understand this entire owner’s manual including all safety WARNING information, before plugging in or using this product. Failure to do so could result in fire, electric shock, or serious personal injury.
-
Page 2: Table Of Contents
Contents Parts and Hardware ............................. 4 Tools Required ............................4 Unpacking and Setup ..........................4 Unpacking Instructions ..........................4 BOX CONTENTS ..........................4 Wiring ............................... 5 Testing the Fireplace Prior to Installation ..................... 5 Prong Outlet Installation ........................5 Power Data ..............................5 Installation .............................. - Page 3 IMPORTANT SAFETY INFORMATION WARNING • THIS FIREPLACE IS HOT WHEN IN OPERATION AND CAN CAUSE SEVERE BURNS • Do not operate fireplace before reading and understanding operation instructions. Failure to operate fireplace according to operation instructions could cause fire or injury. •...
-
Page 4: Parts And Hardware
Parts and Hardware Tools Required • Phillips screwdriver • Stud finder • Level • Tape measure • Electric drill • Wood drill bit Unpacking and Setup Unpacking Instructions • Remove all parts and hardware from the carton and place them on a clean, soft, dry surface. Check the parts list to make sure no parts are missing. -
Page 5: Wiring
• Make sure this plug fits securely into the outlet. Faulty wall outlet connections or loose plugs can cause the outlet to overheat. If the outlet or face plate is hot, discontinue use immediately and have a qualified electrician inspect and/or replace the faulty outlet. Power Data Model ULTRA 130 ULTRA 150 ULTRA 180 Voltage 230Vac... -
Page 6: Installation
Installation WARNINGS • Due to high temperatures, keep the fireplace out of high traffic locations. • Keep combustible materials, such as furniture, pillows, bedding, papers, clothes, and curtains at least 1M away from the front of the fireplace. • Never install the fireplace where it may fall into a bathtub or other body of water. •... -
Page 7: Recessed Installation
1. Choose a location in the wall to install fireplace. 2. Make an opening in the wall based on metal firebox size. Drywall stops Drywall stops Fire Dimensions ULTRA 130 ULTRA 150 ULTRA 180 Model No. Fireplace Height Overall 521mm... -
Page 8: Recessed Installation Overview
Recessed Installation Overview The HM three-sided Electric Fireplace can be installed in five different recessed configurations: Three-Sided Installation: • Glass exposed on the left, front, and right sides • Fireplace is fully recessed into the wall with both sides open Two-Sided Installation: •... -
Page 9: Recessed Installation
Recessed Installation Three-Sided Installation: 1. Prepare the framed opening according to the Rough Opening Dimensions chart. Provide a 230Vac 13amp circuit for wire install at the top right of the framed opening. 2. Install Metal Bracket. 3. Install the fire unit in the framed opening with a minimum 1 ¼ drywall screws to secure the unit. 4. -
Page 10: Installing The Crystal Ember And Log-Set
Partial Recess Installation (Optional): Follow the directions included with the Partial Recess. Slide-in cabinet installation (Optional): Follow the directions included with the Slide-in Cabinet. Installing the Crystal Ember and Log-set Once the fireplace is installed in the wall, place crystal media stones and artificial logs in the fireplace. Installing the Crystal Embers 1. -
Page 11: Operating Fireplace
Operating Fireplace Once the fireplace has been plugged into a grounded outlet, the fireplace is now ready for operation. Ensure that the house circuit breakers for the power supply are turned on. Power Plug the power cable into a 230v 7.5 amp grounded outlet. Make sure the outlet is in good condition and that the plug is not loose. -
Page 12: Method Of Operation
Method of Operation Control Panel Functions BUTTON ACTION & INDICATION FUNCTION ON: Enables control panel functions and 1. Press once. Indicator light turns on. Power turns remote control. Turns on flame effect. on. All functions enabled. OFF: Disables control panel functions and 2. -
Page 13: Method Of Operation
Method of Operation Wireless Remote Control Functions Turn ON/OFF the fireplace Power button Global or single group color adjustable,short press the up and down keys to select among 8 Color ring colors, long press the up and down keys to select among 64 colors Used for adjusting functions such as time, week, temperature, etc. -
Page 14: Care And Maintenance
• This remote control uses 2 AAA batteries • To improve operation of the remote control, aim the remote control at the front of the fireplace. DO NOT PRESS the buttons too quickly. Give the unit time to respond to each command. -
Page 15: Wi-Fi Controls
Wi-Fi Controls This fireplace is also capable of being controlled over Wi-Fi using an Apple or Android mobile device. Scan the QR code for an instructional walk through video on how to download and setup the app needed to control your Electric fireplace. Alternatively, you can follow the steps below. -
Page 16: Wi-Fi Controls
Wi-Fi Controls Next you will be prompted to connect to your existing home wireless network. Select the appropriate 2.4Ghz network and log in. Note - Only 2.4GHz wireless networks are compatible, 5GHz wireless networks cannot be used. If not available, contact your wireless service provider for further information on setting up a 2.4GHz wireless network. -
Page 17: Wi-Fi Controls
Wi-Fi Controls With the fireplace now successfully Creating a Heat paired it can be controlled in the same Program manner as the remote controls (see page 15). Added capabilities like Sleep Timer and Heat Program are only possible when using the app. -
Page 18: Wi-Fi Controls
Wi-Fi Controls Next, in the pop-up window select the The Heat Program is now set to turn the desired program settings: fireplace and heater on at 1:00PM every Switch - Turn fireplace on or off Wednesday to maintain a temperature of 20˚C until 6:00PM. -
Page 19: Warranty
Warranty Our electric fireplaces are to be free of defects in material and workmanship for one year from the date of purchase. This warranty only covers manufacturing faults. This warranty does not cover damages, accidents, lack of maintenance, abuse or neglect. The warranty does not cover paint scratches, cosmetic blemishes, dents, corrosion or other normal wear and tear associated with the fireplace.
