Installation, Start-up, Operating, and
Service and Maintenance Instructions
Catalog No: 53PG-8J2
All manuals and user guides at all-guides.com
-Series A
The Payne PG8M/PG8J 80% AFUE Gas Furnaces feature 4-
way multipoise design and through-the-furnace downflow
venting. The PG8M/PG8J furnaces are approved for use with
natural or propane gas and the PG8J is also approved for use in
Low Nox Air Quality Management Districts.
STANDARD FEATURES
Four-position furnace: upflow, horizontal right, horizontal
•
left, downflow
Electronic control center
•
Adjustable heating air temperature rise
LED diagnostics and self test feature
Hot surface ignition (HSI)
•
Twinning in Upflow, Downflow and Horizontal
•
LIMITED WARRANTY
• 20-year warranty on "Super S™" heat exchanger
• 5-year parts warranty on all other components
Form No. IM-PG8J-03
PG8M/PG8J
12-02
