- Page 1 Dell Rugged Extreme 14-7404 Setup And Features Information Regulatory Model: P45G Regulatory Type:P45G001 RFID Model: DWRFID1302...
- Page 2 CAUTION: A CAUTION indicates either potential damage to hardware or loss of data and tells you how to avoid the problem. WARNING: A WARNING indicates a potential for property damage, personal injury, or death. © 2013 Dell Inc. All Rights Reserved. Trademarks used in this text: Dell , the Dell logo, Dell Boomi...
- Page 3 ......................12 Closing The Press-Latch doors ......................12 Opening The Slide-Latch doors ......................12 Closing The Slide-Latch doors 4 Smart Cards......................13 5 Specifications......................15 6 Information para NOM (únicamente para México)........21 7 Finding More Information and Resources............23 8 Contacting Dell....................... 25...
- Page 5 Front and Back View Figure 1. Front view Display latch Microphone Privacy shutter Camera (optional) Camera status light Speaker Outdoor readable display/touchscreen Power button (optional) Memory-card reader USB 2.0 Connector USB 3.0 Connector Optical drive Secure-card reader Hard disk PC/Express Card Reader Finger Print Reader Status Lights Power Connector...
- Page 6 WARNING: Do not block, push objects into, or allow dust to accumulate in the air vents. Do not store your Dell computer in a low-airflow environment, such as a closed briefcase, while it is running. Restricting the airflow can damage the computer or cause a fire. The computer turns on the fan when the computer gets hot.
- Page 7 Quick Setup WARNING: Before you begin any of the procedures in this section, read the safety information that shipped with your computer. For additional best practices information, see www.dell.com/ regulatory_compliance WARNING: The AC adapter works with electrical outlets worldwide. However, power connectors and power strips vary among countries.
- Page 8 Connect IEEE 1394 devices, such as a 1394 hard drive (optional). Figure 6. 1394 Connector Open the computer display and press the power button to turn on the computer. Figure 7. Power Button NOTE: It is recommended that you turn on and shut down your computer at least once before you install any cards or connect the computer to a docking device or other external device, such as a printer.
- Page 9 Removing and Installing Components This section provides detailed information on how to remove or install the components from your computer.
- Page 10 WARNING: Using an incompatible battery may increase the risk of fire or explosion. Replace the battery only with a compatible battery purchased from Dell. The battery is designed to work with your Dell computer. Do not use a battery from other computers with your computer.
- Page 11 Removing the Hard Drive Perform the following steps: a) To open the hard drive latch door, push the lock button to the right first and then in a downward direction. b) Open the hard drive latch door by pushing the latch towards the rear of the computer. Perform the following steps to remove the hard drive : a) Slide the hard drive release latch to the left.
- Page 12 Opening The Press-Latch doors There are three press-latch doors. Two on the back and one on the right side panel. Follow the steps below to open the press-latch doors : a) Push the slide-lock to the left (the latch is locked when slid to the right). b) The door can now be opened by pressing down on the latch and pulling the door in a direction away from the computer.
- Page 13 Smart Cards There are two main types of Smart or Common Access Cards (CAC): Enclosed Smart Cards — These cards have a contact area with many gold plated connection pads. When inserted into a card reader, the information from the chip can be read and written The Smart Card can be fully inserted, allowing the protective hinged door to be closed.
- Page 15 Specifications NOTE: Offerings may vary by region. For more information regarding the configuration of your computer, click Start (Start icon) → Help and Support, and then select the option to view information about your computer. Table 1. System Information Feature Specification Chipset Intel Mobile Express Series 6 chipset...
- Page 16 Feature Specification Stereo conversion 24-bit (analog-to-digital and digital-to-analog) Interface: Internal high definition audio External microphone-in/stereo headphones/external speakers connector Speakers Internal speaker amplifier 1W (RMS) Volume controls Volume Up/Volume Down buttons CAUTION: Adjustment of volume control, as well as the equalizer in the operating system and/or equalizer software, to other settings than the center position may increase the earphones and/or headphones output and cause hearing damage or loss.
- Page 17 Feature Specification Docking port Subscriber Identity Module (SIM) port Table 8. Display Feature Specification Type white Light Emitting Diode (WLED) display Size 14.0 inches Dimensions: Height 190.00 mm (7.48 inches) Width 323.5 mm (12.59 inches) Diagonal 375.2 mm (14.77 inches) Active area (X/Y) 309.4 mm x 173.95 mm Maximum resolution...
- Page 18 Feature Specification Y-axis 51 mm (2.00 inches) Table 11. Battery Feature Specification Type 6–cell or 9–cell “smart” lithium ion Dimensions: Height 21 mm (0.82 inches) Width 166.9 mm (6.57 inches) Depth 80 mm (3.14 inches) Weight 6–cell : 365.5 g (0.80 lbs) ; 9–cell : 520 g (1.14 lbs) Voltage 14.8 VDC Temperature range:...
- Page 19 Table 13. Auto-air Adapter Type 90 W Input voltage 11 VDC to 16 VDC Input current (maximum) 9.0 A Output power 90 W Output current 4.86 A(continuous) Rated output voltage 19.5 +/– 1.0 VDC Temperature range: Operating 0 °C to 35 °C (32 °F to 95°F) Table 14.
- Page 21 Information para NOM (únicamente para México) The following information is provided on the device described in this document in compliance with the requirements of the official Mexican standards (NOM). Voltaje de alimentación 100 VAC – 240 VAC Frecuencia 50 Hz – 60 Hz Consumo eléctrico 1,7 A/2,5 A Voltaje de salida...
- Page 23 • Safety best practices • Regulatory certification • Ergonomics See www.dell.com for additional information on: • Warranty • Terms and Conditions (U.S. only) • End User License Agreement Additional information on your product is available at www.dell.com/support/manuals...
- Page 25 Dell product catalog. Dell provides several online and telephone-based support and service options. Availability varies by country and product, and some services may not be available in your area. To contact Dell for sales, technical support, or customer service issues: Visit dell.com/support...
