- Page 1 A C O U S T I C S S4N | i4N Professional Sound Reinforcement Loudspeaker System Operation Instructions © German Audio Engineering GmbH*An der Strusbek 1*22926 Ahrensburg – User Manual DAL S4N / i4N v1.0...
-
Page 2: System Description
For 70/100V Line operation with a third party amp and control system a variant with transformer (i4N-100) is available. S4N/i4N Acessories U-Mounting Yoke (suspending) U-Mounting Yoke (standing) Microphone Stand Adapter M5 – 3/8inch Truss C-Clamp small © German Audio Engineering GmbH*An der Strusbek 1*22926 Ahrensburg – User Manual DAL S4N / i4N v1.0... - Page 3 This symbol in connection with the signal word "Warning" indicates commands to observe product-relevant operating conditions. © German Audio Engineering GmbH*An der Strusbek 1*22926 Ahrensburg – User Manual DAL S4N / i4N v1.0...
-
Page 4: Intended Use And Application
150Hz Butterworth 2 Order 3,72KHz BW0,3 – Q4,8 -3dB 5,00KHz BW5,0 – Q 2,6 +5dB High Shelving 7.00KHZ BW 10,0 – Q3,0 -7dB © German Audio Engineering GmbH*An der Strusbek 1*22926 Ahrensburg – User Manual DAL S4N / i4N v1.0... -
Page 5: Safety Instructions
DAL will not be liable for any damage caused in this way and will not accept any warranty or liability for consequential damage. © German Audio Engineering GmbH*An der Strusbek 1*22926 Ahrensburg – User Manual DAL S4N / i4N v1.0... -
Page 6: Technical Overview
The illustration of the serial number sticker is shown on the left. The S/N Serial Number designation is followed by the serial number of the speaker system. © German Audio Engineering GmbH*An der Strusbek 1*22926 Ahrensburg – User Manual DAL S4N / i4N v1.0... -
Page 7: Technical Specifications
SWR equipment variant. Both variants are manufactured at the factory only. Peak SPL Level with DAL DS-4L © German Audio Engineering GmbH*An der Strusbek 1*22926 Ahrensburg – User Manual DAL S4N / i4N v1.0... - Page 8 Use approved stands and approved mounting accessories that are designed for the weight load. Additionally secure the ground stacked or flown speaker system before commissioning to prevent personal injury and property damage. © German Audio Engineering GmbH*An der Strusbek 1*22926 Ahrensburg – User Manual DAL S4N / i4N v1.0...
-
Page 9: Test And Maintenance
S4N - internal wiring schematic Fixing and mounting points should be inspected frequently. i4N - internal wiring schematic © German Audio Engineering GmbH*An der Strusbek 1*22926 Ahrensburg – User Manual DAL S4N / i4N v1.0... -
Page 10: Note On Disposal
Applied national standards and technical specifications: DIN 18800, DIN 1055, DGUV regulation 17, BGI 810-13 Hamburg, 01.06.2018 © German Audio Engineering GmbH*An der Strusbek 1*22926 Ahrensburg – User Manual DAL S4N / i4N v1.0...
