NU Aqua Platinum Series Installation Manual

Reverse osmosis system
Hide thumbs Also See for Platinum Series:

Advertisement

Quick Links

Installation Manual
Platinum Series
For NU Aqua Product ID (SKU):
WU-100GPD-NP
WU-100GPD-NP-ALK
WU-100GPD-NP-UV
WU-100GPD-NP-UV-ALk
WU-100GPD-WP
WU-100GPD-WP-ALK
WU-100GPD-WP-UV
WU-100GPD-WP-UV-ALk

Advertisement

loading
Need help?

Need help?

Do you have a question about the Platinum Series and is the answer not in the manual?

Questions and answers

Summary of Contents for NU Aqua Platinum Series

  • Page 1 Installation Manual Platinum Series For NU Aqua Product ID (SKU): WU-100GPD-NP WU-100GPD-NP-ALK WU-100GPD-NP-UV WU-100GPD-NP-UV-ALk WU-100GPD-WP WU-100GPD-WP-ALK WU-100GPD-WP-UV WU-100GPD-WP-UV-ALk...
  • Page 2 Congratulations on Your New Reverse Osmosis System Scan here Watch the complete for link to video installation guide at nuaquasystems.com/install...
  • Page 3 Table of contents Introduction Conditions Page Introduction Page Preparation Inspection Page Recommended tools Page System requirements Page Installation components Page Quick connect guide Page Tube cutting guide Page Installation Feed water adapter Page Leak stop valve Page Drain saddle Page Faucet installation Page Tank installation...
  • Page 4 INCOMING WATER Incoming water pressure must be between 45 PSI and 80 PSI for NU Aqua no pump reverse osmosis systems. Incoming water pressure must be between 45 PSI and 80 PSI for NU Aqua no pump reverse osmosis systems.
  • Page 5 Introduction Thank you for your purchase of the NU Aqua Platinum Series Reverse Osmosis Drinking water system. We're excited for you to experience the benefits of a premium home water filter system and hope that you are as well. This guide is intended to make your installation pain free and can be followed step by step with our installation video.
  • Page 6 Inspection After unpacking your new RO system and all the components, we recommend that you thoroughly inspect all fittings and tubing to ensure nothing has come loose during shipping. If any part appears cracked or broken from shipping, do not proceed with installation and contact us directly. Email: support@nuaquasystems.com Phone: 1(888) 621-0460 Recommended Tools...
  • Page 7 Quick Connect Guide Plug Collet Locking Tubing/Fittings/ Clip Plug Removal If there is a retaining clip on the collet of the fitting it must be removed first. Push and hold the collet down to unlock the tubing and gently pull the tube/fitting/plug to remove it.
  • Page 8 Installation Feed Water Adapter 1. Locate and turn o the cold water valve under your sink. Next turn on the cold water faucet to drain any remai- ning water in the line 2. Place a towel below your cold water valve to catch any remaining water in the line.
  • Page 9 Installation Leak stop valve installation WARNING: NOTE: failure to install Leak Stop Valve will it may be best to insert the cartridge after void Warranty the initial startup is complete 1. Locate the lowest point within your cabinet or installation location.
  • Page 10 Installation Drain Saddle Mount Drain WARNING! Saddle at either Never mount location there! 1. Locate a section on your drain plumbing using the 5. Slide a small screwdriver through the quick image above and mark the location with a pen. If the connect fitting on the drain saddle half and through drain saddle is to be installed on a horizontal section the hole drilled in your drain pipe.
  • Page 11 Open and Closed Position Installation Faucet Installation Drilling Closed Open If your sink has a existing hole this can be used for your faucet. If you have to drill a new hole follow the steps below. Granite / Marble / Quartz sinks Keep the drill bit and hole wet during the drilling process 1.
  • Page 12 Installation Tank Ball Valve Do not release pressure from storage tank unless needed. NOTE: Tanks come pressurized between 7-10psi when empty. 1. Apply 8-10 clockwise wraps of teflon tape to the threads on the top of your storage tank. 2. Install your tank ball valve on the tank threads and tighten by hand.
  • Page 13 Installation Filter Housing Install 1. Remove the plastic wrapper from each filter and reinsert them back into their housing. When inserting the stage 2 carbon GAC filter make sure the white washer is facing up. 2. While keeping the filters standing vertically in the housing, attach them to the system by threading it onto the cap.
  • Page 14 Installation 6 Stage System Assembly For Product ID (SKU): WU-100GPD-NP-ALK, WU-100GPD-WP-ALK Alkaline Filter Installation 1. Insert one quick connect elbow into the quick connect fitting on each end of the alkaline filter. 2. Attach the filter housing clips to the post filter. 3..
  • Page 15 System Connections 5 Stage Connections Product ID (SKU): WU-100GPD-NP, WU-100GPD-WP Connect red tubing to the feed water adapter to the inlet of the leak detector. Connect red tubing from the outlet of the leak detector to the water inlet of the first stage. Connect yellow tubing from the T fitting on the post filter to the tank ball valve.
  • Page 16 System Connections 6 Stage Alkaline Connections For Product ID (SKU): WU-100GPD-NP-ALK Connect red tubing to the feed water adapter to the inlet of the leak detector. Connect red tubing from the outlet of the leak detector to the water inlet of the first stage. Connect yellow tubing from the T fitting on the post filter to the tank ball valve.
  • Page 17 System Connections 6 Stage UV Connections For Product ID (SKU): WU-100GPD-NP-UV Connect red tubing to the feed water adapter to the inlet of the leak detector. Connect red tubing from the outlet of the leak detector to the water inlet of the first stage. Connect yellow tubing from the T fitting on the post filter to the tank ball valve.
  • Page 18 System Connections 7 Stage Connections For Product ID (SKU): WU-100GPD-NP-UV-ALK Connect red tubing to the feed water adapter to the inlet of the leak detector. Connect red tubing from the outlet of the leak detector to the water inlet of the first stage. Connect yellow tubing from the T fitting on the post filter to the tank ball valve.
  • Page 19 System Connections 5 Stage Pump Connections For Product ID (SKU): WU-100GPD-WP Connect red tubing to the feed water adapter to the inlet of the leak detector. Connect red tubing from the outlet of the leak detector to the water inlet of the first stage. Connect yellow tubing from the T fitting on the post filter to the tank ball valve.
  • Page 20 System Connections 6 Stage Alkaline Pump Connections For Product ID (SKU): WU-100GPD-WP-ALK Connect red tubing to the feed water adapter to the inlet of the leak detector. Connect red tubing from the outlet of the leak detector to the water inlet of the first stage. Connect yellow tubing from the T fitting on the post filter to the tank ball valve.
  • Page 21 System Connections 6 Stage UV Pump Connections For Product ID (SKU): WU-100GPD-WP-UV Connect red tubing to the feed water adapter to the inlet of the leak detector. Connect red tubing from the outlet of the leak detector to the water inlet of the first stage. Connect yellow tubing from the T fitting on the post filter to the tank ball valve.
  • Page 22 System Connections 7 Stage Pump Connections For Product ID (SKU): WU-100GPD-WP-UV-ALK Connect red tubing to the feed water adapter to the inlet of the leak detector. Connect red tubing from the outlet of the leak detector to the water inlet of the first stage. Connect yellow tubing from the T fitting on the post filter to the tank ball valve.
  • Page 23 Refrigerator/ Ice Maker kit available here: System Connections (Optional) Refrigerator Kit Instructions Scan Me! If you’re currently installing your system and have not gone through the startup process proceed to step 4. Turn o your cold water valve that is connected to your reverse osmosis sytem and close the tank ball valve. Open the faucet from the reverse osmosis system and allow the system to drain until the water flow stops.
  • Page 24 System Startup WARNING: Before sending any water through your system fully check every connection on the system. Remove any retaining clips and push the tubing into the quick connect to ensure its fully inserted. Reinstall each retaining clip. NOTE: DO NOT DRINK ANY WATER UNTIL COMPLETING THE FLUSHING PROCESS BELOW. Turn the valve on your tank to the o position.
  • Page 25 Scan Me! WANT YOUR FILTERS DELIVERED AUTOMATICALLY? Filter Changes JOIN THE FILTER CLUB AND GET YOUR FILTERS AT A DISCOUNT. NOTE: It is not necessary to disconnect the automatic shut o valve during a filter change. If you do disconnect it refer to system diagrams on page 28-35. Prefilers Stage 1-3 1.
  • Page 26 Sanitizing Your System To keep your system in the best operating conditions it’s recommended that you sanitize your system once every 12 months. We recommend using Sani Systems liquid sanitizer. NOTE: Make sure you’ve already turned o your system. If not follow step #1 from Prefilters on page 22. 1.
  • Page 27 Troubleshooting Problem Causes Solution Milky colored water • Air in the system • Air in the system is normal with initial Air bubbles in water installation and startup. This will clear up within 1 to 2 weeks. Loud or noisy system •...
  • Page 28 System Diagrams 5 Stage For Product ID (SKU): WU-100GPD-NP WU-RCLIP WU-FWA-02 WU-14LSV WU-FH10-CLEAR-SL WU-FH10-WHITE-SL WU-FHRING-SL WU-S-1M WU-GAC-1M WU-CB-5M 10. WU-14X14-ELB 11. WU-AHN-0202 12. WU-CL-204-T 13. WU-CHK-VLV-PF 14. WU-FL-300 15. WU-14DS 16. WU-14PF 17. WU-MHP-1812-PF 18. WU-MHP-OR-SL 19. WU-100GPD-MB 20. WU-14-ASOV 21.
  • Page 29 System Diagrams 5 Stage with Pump For Product ID (SKU): WU-100GPD-WP 1. WU-RCLIP 2. WU-FWA-02 3. WU-14LSV 4. WU-FH10-CLEAR-SL 5. WU-FH10-WHITE-SL 6. WU-FHRING-SL 7. WU-S-1M 8. WU-GAC-1M 9. WU-CB-5M 10. WU-WP-T 11. WU-14X14-ELB 12. WU-WP-BRKT 13. WU-PUMP 14. WU-PUMP-LPS 15. WU-PUMP-HPS 16.
  • Page 30 System Diagrams 6 Stage Alkaline For Product ID (SKU): WU-RCLIP WU-100GPD-NP-ALK 2. WU-FWA-02 3. WU-14LSV 4. WU-FH10-CLEAR-SL 5. WU-FH10-WHITE-SL 6. WU-FHRING-SL 7. WU-S-1M 8. WU-GAC-1M 9. WU-CB-5M 10. WU-14X14-ELB 11. WU-AHN-0202 12. WU-CL-204-T 13. WU-CHK-VLV-PF 14. WU-FL-300 15. WU-14DS 16. WU-14PF 17.
  • Page 31 System Diagrams 6 Stage with Pump For Product ID (SKU): WU-100GPD-WP-ALK 1. WU-RCLIP 2. WU-FWA-02 3. WU-14LSV 4. WU-FH10-CLEAR-SL 5. WU-FH10-WHITE-SL 6. WU-FHRING-SL 7. WU-S-1M 8. WU-GAC-1M 9. WU-CB-5M 10. WU-WP-T 11. WU-14X14-ELB 12. WU-WP-BRKT 13. WU-PUMP 14. WU-PUMP-LPS 15. WU-PUMP-HPS 16.
  • Page 32 System Diagrams 6 Stage Ultraviolet For Product ID (SKU): WU-100GPD-NP-UV WU-RCLIP 2. WU-FWA-02 3. WU-14LSV WU-FH10-CLEAR-SL 5. WU-FH10-WHITE-SL 6. WU-FHRING-SL 7. WU-S-1M 8. WU-GAC-1M 9. WU-CB-5M 10. WU-14X14-ELB 11. WU-AHN-0202 12. WU-CL-204-T 13. WU-CHK-VLV-PF 14. WU-FL-300 15. WU-14DS 16. WU-14PF 17.
  • Page 33 System Diagrams System Diagrams 6 Stage Ultraviolet with Pump 6 Stage Ultraviolet with Pump For Product ID (SKU): WU-100GPD-WP-UV For Product ID (SKU): WU-100GPD-WP-UV WU-RCLIP WU-RCLIP 2. WU-FWA-02 2. WU-FWA-02 3. WU-14LSV 3. WU-14LSV 4. WU-FH10-CLEAR-SL 4. WU-FH10-CLEAR-SL 5. WU-FH10-WHITE-SL 5.
  • Page 34 System Diagrams 7 Stage For Product ID (SKU): WU-100GPD-NP-UV-ALK WU-RCLIP 2. WU-FWA-02 3. WU-14LSV 4. WU-FH10-CLEAR-SL 5. WU-FH10-WHITE-SL 6. WU-FHRING-SL 7. WU-S-1M 8. WU-GAC-1M 9. WU-CB-5M 10. WU-14X14-ELB 11. WU-AHN-0202 12. WU-CL-204-T 13. WU-CHK-VLV-PF 14. WU-FL-300 15. WU-14DS 16. WU-14PF 17.
  • Page 35 System Diagrams 7 Stage with Pump For Product ID (SKU): WU-100GPD-WP-UV-ALK WU-RCLIP 2. WU-FWA-02 3. WU-14LSV 4. WU-FH10-CLEAR-SL 5. WU-FH10-WHITE-SL 6. WU-FHRING-SL 7. WU-S-1M 8. WU-GAC-1M 9. WU-CB-5M 10. WU-WP-T 11. WU-14X14-ELB 12. WU-WP-BRKT 13. WU-PUMP 14. WU-PUMP-LPS 15. WU-PUMP-HPS 16.
  • Page 36 Service Record Date of Purchase Installed By Date of Install DATE 1 ST STAGE 2 ST STAGE 3 ST STAGE 5 ST STAGE ALKALINE SEDIMENT CARBON CARBON MEMBRANE CARBON POST FILTER BULB BLOCK FILTER NOTES:...
  • Page 37 Service Record DATE 1 ST STAGE 2 ST STAGE 3 ST STAGE 5 ST STAGE ALKALINE SEDIMENT CARBON CARBON MEMBRANE CARBON POST FILTER BULB BLOCK FILTER NOTES:...
  • Page 38 Within that three (3) year period from the original purchase, NU Aqua Systems will, at its option, repair or replace the Product without charge, or refund the cost of the Product, if the Product fails or does not perform as warranted solely due to a manufacturing defect within the warranty period, subject to the limitations and exclusions set forth in this Limited Product Warranty.
  • Page 39 No claim by the buyer/owner of any kind, including claims for indemnification, shall be greater in amount than the purchase price of the products in respect to which damages are claimed. In no event shall NU Aqua Systems be liable to buyer/owner in tort, contract or otherwise, for any special, indirect, incidental, consequential, reliance, statutory, special, punitive or exemplary damages, including, but not limited to, lost profits, loss of use, loss of time, inconvenience, damage to goodwill or reputation, or...
