- Page 1 Installation Manual Ultraviolet Sterilizer For NU Aqua Product ID (SKU): HC-UVC1140GPD HC-UVC1140GPD-SYS...
- Page 2 Congratulations on Your New Ultraviolet Sterilizer Scan here Watch the complete for link to video installation guide at nuaquasystems.com/install...
-
Page 3: Table Of Contents
Recommended tools Page Installation components Page Quick connect guide Page Tube cutting guide Page Installation UV Filter (HC-UVC1140GPD) Page Complete UV System (HC-UVC1140GPD-SYS) Page Feed water adapter Page Leak stop valve Page Faucet Page Carbon Filter Page UV Filter Page Optional uv filter install... -
Page 4: Conditions
Use, install and monitor all of our products solely at your own risk. Always check all connections for leaks periodically. NU Aqua Systems is not responsible for any leaks or water damage. In case some states do not allow the exclusion or limitation of incidental or consequential damages, you may choose to return the system. -
Page 5: Introduction
Introduction Welcome to the NU Aqua family! We're excited for you to experience the benefits of our premium home water Ultraviolet Sterilizer. This guide will walk you through the installation process step-by-step, so you can have your new system up and running in no time. -
Page 6: Quick Connect Guide
Quick Connect Guide Plug Collet Locking Tubing/Fittings/ Clip Plug Removal If there is a retaining clip on the collet, remove it first. Push down on the collet to unlock the tubing, then gently pull the tube, fitting, or plug to remove Hold Down Pull Up... -
Page 7: Installation
Installation UV Filter Only (HC-UVC1140GPD) Wall Mounting Adhesive pad There are two mounting options for your UV filter. Mounting Plate Option one is a adhesive pad. This is the easiest option but will be less secure. Option two is a hard mount that is more secure and uses screws to attach to the inside of your cabinet. - Page 8 Installation System startup Connect the power supply to the port located WARNING: Check system for leaks on the bottom of the UV filter. every day for one week after Now to turn the system on connect the power installation. supply to a wall outlet. System functions The red light on the bottom of the system indicates that it is powered on.
-
Page 9: Complete Uv System (Hc-Uvc1140Gpd-Sys)
Installation Complete System (HC-UVC1140GPD-SYS) Feed Water Adapter 1. Locate vand turn o the cold water valve under your sink. Next turn on the cold water faucet to drain any remai- ning water in the line 2. Place a towel below your cold water valve to catch any remaining water in the line. -
Page 10: Leak Stop Valve
Installation Leak stop valve installation WARNING: NOTE: failure to install Leak Stop Valve will it may be best to insert the cartridge after void Warranty the initial startup is complete 1. Locate the lowest point within your cabinet or installa- tion location. - Page 11 Open and Closed Position Installation Faucet Installation Drilling Closed Open If your sink has a existing hole this can be used for your faucet. If you have to drill a new hole follow the steps below. Granite / Marble / Quartz sinks Keep the drill bit and hole wet during the drilling process 1.
-
Page 12: Carbon Filter
Installation Filter Installation 1. Mount the filter with the screws provi- ded in a location that is close to your leak detector. 2. Attach the tubing coming from the outlet of your leak detector to the inlet of the carbon filter. Attach the retaining clip to secure the tubing in place. -
Page 13: Optional Uv Filter Install
Installation UV Filter Connections 1. Cut a length of tubing that will connect between the outlet of the carbon filter and your UV filter. 2. Install this tubing into the outlet of the carbon filter and the inlet of the UV filter. Secure the tubing in place with retainer clips on both connections. -
Page 14: Filter Changes
Maintenance UV Filter The NU Aqua UV Filter is utilizes industrial grade LEDs instead of traditional style bulbs. This provi- des years of maintenance free use. Carbon Filter The carbon filter in your system requires replace- ment every 8-12 months or 5,000 gallons. -
Page 15: Warranty
NU Aqua Systems, unless NU Aqua Systems expressly approves such charges in writing. During the entire two (2) year warranty, NU Aqua Systems's obligation to repair or replace shall further be limited to repair or replacement with the styles, models, products, colors, etc. - Page 16 NU Aqua Systems, return of the product and a refund of the purchase price. Buyer assumes all risk whatsoever as to the result of the use of the product purchased, whether used singularly or in combination with any other products or substances.
