- Page 1 Installation Manual 600GPD Tankless RO System For NU Aqua Product ID (SKU): KF-600GPD-2FTL...
- Page 2 Congratulations on Your New Reverse Osmosis System Scan here Watch the complete for link to video installation guide at nuaquasystems.com/install...
-
Page 3: Table Of Contents
Table of contents Introduction Conditions Page Introduction Page System Requirements Page Preparation Inspection Page Recommended tools Page Installation components Page Quick connect guide Page Tube cutting guide Page Installation Feed water adapter Page Leak stop valve Page Drain saddle Page Faucet installation Page System installation... -
Page 4: Conditions
Use, install and monitor all of our products solely at your own risk. Always check all connections for leaks periodically. NU Aqua Systems is not responsible for any leaks or water damage. In case some states do not allow the exclusion or limitation of incidental or consequential damages, you may choose to return the system. -
Page 5: Introduction
Introduction Thank you for your purchase of the NU Aqua reverse ssmosis drinking water system. We're excited for you to experience the benefits of a premium home water filter system and hope that you are as well. This guide is intended to make your installation pain free and can be followed step by step with our installation video. -
Page 6: Inspection
Inspection After unpacking your new RO system and all the components, we recommend that you thoroughly inspect all fittings and tubing to ensure nothing has come loose during shipping. If any part appears cracked or broken from shipping, do not proceed with installation and contact us directly. Email: support@nuaquasystems.com Phone: 1(888) 621-0460 Recommended Tools... -
Page 7: Quick Connect Guide
Quick Connect Guide Plug Collet Locking Tubing/Fittings/ Clip Plug Removal If there is a retaining clip on the collet of the fitting it must be removed first. Push and hold the collet down to unlock the tubing and gently pull the tube/fitting/plug to remove it. -
Page 8: Installation
Installation Feed Water Adapter 1. Locate and turn o the cold water valve under your sink. Next turn on the cold water faucet to drain any remai- ning water in the line 2. Place a towel below your cold water valve to catch any remaining water in the line. -
Page 9: Leak Stop Valve
Installation Leak Stop Valve Installation WARNING: NOTE: Failure to install Leak Stop Valve will It may be best to insert the cartridge after void Warranty the initial startup is complete 1. Locate the lowest point within your cabinet or installation location. -
Page 10: Drain Saddle
Installation Drain Saddle Mount Drain WARNING! Saddle at either Never mount location there! 1. Locate a section on your drain plumbing using the 5. Slide a small screwdriver through the quick image above and mark the location with a pen. If the connect fitting on the drain saddle half and through drain saddle is to be installed on a horizontal section the hole drilled in your drain pipe. -
Page 11: Faucet Installation Page
Installation Faucet Installation Drilling If your sink has an existing hole this can be used for your faucet. If you have to drill a new hole follow the steps below. Granite / Marble / Quartz sinks Keep the drill bit and hole wet during the drilling process 1. -
Page 12: System Installation
System Installation NOTICE: If your system comes with the alkaline or UV filter you may skip this page For alkaline system proceeed to page 13 Filter Installation For UV system proceeed to page 14 1. Place your system under your sink in a For alkaline and UV system proceeed to page 16 location thats easily accessible. -
Page 13: Alkaline System Installation
Alkaline System Installation WALL Mounting Secure the filter bracket to the wall of your kitchen cabinet using the two provided screws. Before connecting the filter check that the o-ring is properly seated in place. SCREW Insert the filter into the bracket and twist clockwise to secure it in place. -
Page 14: Uv System Installation
UV System Installation Mounting There are two mounting options for your UV filter. Option one is a adhesive pad. This is the easiest option but will be less secure. Option two is a hard mount that is more secure and uses screws to attach to the inside of your cabinet. - Page 15 UV System Connections 1. Connect the 3/8” tubing coming from the leak detector into the INPUT connection on the back of the reverse osmosis system. Secure the tubing in place with a retaining clip. 2. Connect the 1/4” tubing coming from the drain saddle into the DRAIN connection on the back of the reverse osmosis system.
-
Page 16: Alkaline & Uv System Installation
UV & Alkaline System Installation Alkaline Filter Mounting Wall Secure the filter bracket to the wall of your kitchen cabinet using the two provided screws. Before connecting the filter check that the o-ring is properly seated in place. Screw Insert the filter into the bracket and twist clockwise to secure it in place. - Page 17 Alkaline & UV System Connections 1. Connect the 3/8” tubing coming from the leak detector into the INPUT connection on the back of the reverse osmosis system. Secure the tubing in place with a retaining clip. 2. Connect 1/4” tubing coming from the drain saddle into the DRAIN connection on the back of the reverse osmosis system.
-
Page 18: System Startup
System Startup Do not start system without checking each connection is fully inserted into the quick connect fitting NOTE: DO NOT DRINK ANY WATER UNTIL COMPLETING THE FLUSHING PROCESS BELOW. 1. Physically check each connection is fully inserted into it’s fitting and has a retaining clip installed. 2. -
Page 19: Filter Changes
Scan Me! Filter Changes WANT YOUR FILTERS DELIVERED AUTOMATICALLY? JOIN THE FILTER CLUB AND GET YOUR FILTERS AT A DISCOUNT. 1. Close your feed water adapter to stop the flow of water to your system. 2. Unplug the system power supply from your wall outlet. If you have a UV filter disconnect the power supply from your wall outlet. -
Page 20: Troubleshooting
Troubleshooting Problem Causes Solution Milky colored water • Air in the system is normal with initial • Air in the system Air bubbles in water installation and startup. This will clear up within 1 to 2 weeks. • Check for clog in drain line and clear. Water taste or an •... -
Page 21: Warranty
NU Aqua Systems, unless NU Aqua Systems expressly approves such charges in writing. During the entire one (1) year warranty, NU Aqua Systems's obligation to repair or replace shall further be limited to repair or replacement with the styles, models, products, colors, etc. - Page 22 NU Aqua Systems, return of the product and a refund of the purchase price. Buyer assumes all risk whatsoever as to the result of the use of the product purchased, whether used singularly or in combination with any other products or substances.
