Motec Logger Handbook

MoTeC Logger Handbook for the GT4
1. WHERE TO SUPPORT OR TO PURCHASE FROM
Your MoTeC Logger system should be ordered from your racing series supporting dealer. The Pirelli
Porsche Cup series sanctioned by Competent Motorsports races throughout the West coast. The PCA GT4
series races throughout the East coast. For support or to purchase a system, please contact either:
West Coast Series
Christopher Brown
CB-Racing
PO Box 6656
Huntington Beach, CA 92615
cb@cb-racing.com
2. Mounting Display
There are 3 possible locations for mounting your logger; above center console, in the passenger foot well or
in front of the instrument cluster. The prefered location is above the center console. The upper left corner to
allow for the mounting spacer to mount, and the upper center to allow for the wiring harness to pass through.
The pictures below show the two locations with yellow arrows.
The actual mount is comprised
of a long 5mm bolt, aluminum
spacer and bent aluminum
bracket. The bolt threads into an
existing hole behind the carbon
plate in the top left corner.
East Coast PCA Series
Joe Hullett
Digital Competition Systems
9303 Brentfield Road
Huntersville, NC 28078
overboost1@roadrunner.com
mounting plate:
1" x 2.75" and 1/8" thick
Two 5mm holes spaced 0.6" from
each end
mounting screw: 5mm x 70mm (2
3/4")
spacer: length = 50mm (2")
Page 1 of 6
