- Page 1 NETWORK CAMERA Installation Manual...
- Page 2 Installation Manual of Network Camera This manual may contain several technical incorrect places or printing errors, and the content is subject to change without notice. The updates will be added to the new version of this manual. We will readily improve or update the products or procedures described in the manual.
- Page 3 Installation Manual of Network Camera Safety Instruction These instructions are intended to ensure that the user can use the product correctly to avoid danger or property loss. The precaution measure is divided into ‘Warnings’ and ‘Cautions’: Warnings: Serious injury or death may be caused if any of these warnings are neglected. Cautions: Injury or equipment damage may be caused if any of these cautions are neglected.
- Page 4 Installation Manual of Network Camera Cautions: Make sure the power supply voltage is correct before using the camera. Do not drop the camera or subject it to physical shock. Do not touch sensor modules with fingers. If cleaning is necessary, use a clean cloth with a bit of ethanol and wipe it gently.
- Page 5 Installation Manual of Network Camera Table of Contents Chapter 1 Introduction .........................6 Applications ..........................6 Preparations ..........................6 Chapter 2 Dome Camera Installation ....................8 Camera Description ........................8 2.2 Installation ............................10...
- Page 6 Installation Manual of Network Camera Chapter 1 Introduction The network camera is a kind of embedded digital surveillance product that combines the features of both traditional analog camera and the encoder. With a built-in video server, the network camera is capable of providing real-time video stream compression, processing, video analysis and transmission simultaneously.
- Page 7 Installation Manual of Network Camera Make sure that the wall is strong enough to withstand three times the weight of the camera. For the camera that supports IR, you are required to pay attention to the following precautions to prevent IR reflection: ...
- Page 8 Installation Manual of Network Camera Chapter 2 Dome Camera Installation 2.1 Camera Description The overview of the network dome camera is shown below. Figure 2-1 Overview Table 2-1 Overview...
- Page 9 Installation Manual of Network Camera Description Bubble Black Liner Lens Mounting Base Reset Auxiliary Video Output Serial Port Micro SD Card Slot Network Cable Power Cable Audio/Alarm Interface Press RESET about 10s when the camera is powering on or rebooting to restore the default settings, including the user name, password, IP address, port No., etc.
- Page 10 Installation Manual of Network Camera 2.2 Installation Ceiling mounting Steps: 1. Loosen the three screws on the edge of the bubble with the screw driver. 2. Open the bubble and remove the inner black liner. Screw Hole Black Liner Bubble Figure 2-3 Remove the Bubble and Black Liner 3.
- Page 11 Installation Manual of Network Camera 5. If you want to route the cables inside the ceiling, drill a cable hole in the ceiling according to the drill template. Skip this step if you want to route the cables on the surface of the ceiling.
- Page 12 Installation Manual of Network Camera Conduit Installation on the Side If you want to route the cables from side of the camera, you need to follow the steps below to install a conduit for cable routing. Steps: 1. Rotate the water-proof plug counterclockwise to remove it from the camera. Water-proof Plug Cable Outlet Side...
- Page 13 Installation Manual of Network Camera Downward Figure 2-8 Side Outlet Direction Ceiling Mounting With Gang Box Steps: 1. Disassemble the camera. 2. Install the gang box in the ceiling. 3. Attach the mounting base to the gang box with two screws. Mounting Base Figure 2-9 In-ceiling Mount 4.
- Page 14 Installation Manual of Network Camera Figure 2-10 Secure Camera 9. Install the inner black liner back to the camera. 10. Align the bubble with the camera. 11. Tighten the screws to secure the bubble with the camera as shown below. Figure 2-11 Secure the Bubble ...
- Page 15 Installation Manual of Network Camera Mounting Adapter Mounting Base Figure 2-12 Secure Mounting Base 5. Route the cables through the hole in the center of the wall mount. 6. Align the camera with the mounting base. 7. Tighten the set screws to secure the camera with the mounting base. 8.
- Page 16 Installation Manual of Network Camera 12. Tighten the screws to secure the bubble with the camera. Figure 2-13 Secure Black Liner and Bubble Image and Focus Adjusting Steps: 1. View the camera image using the monitor. 2. Rotate the panning table to adjust the panning position of the camera. 3.
- Page 17 Installation Manual of Network Camera 4). Loosen the focus lever and move the lever between F (Far) and N (Near) to obtain the optimum focus. 5). Tighten the focus lever. Zoom/Focus Level Figure 2-15 Lens Adjustment...
