- Page 1 NETWORK CAMERA Installation Manual...
- Page 2 Installation Manual of Network Camera Thank you for purchasing our product. If there are any questions, or requests, please do not hesitate to contact us. This manual may contain several technical incorrect places or printing errors, and the content is subject to change without notice. The updates will be added to the new version of this manual.
- Page 3 Installation Manual of Network Camera Safety Instruction These instructions are intended to ensure that the user can use the product correctly to avoid danger or property loss. The precaution measure is divided into ‘Warnings’ and ‘Cautions’: Warnings: Serious injury or death may be caused if any of these warnings are neglected. Cautions: Injury or equipment damage may be caused if any of these cautions are neglected.
- Page 4 Installation Manual of Network Camera Cautions: Make sure the power supply voltage is correct before using the camera. Do not drop the camera or subject it to physical shock. Do not touch sensor modules with fingers. If cleaning is necessary, use a clean cloth with a bit of ethanol and wipe it gently.
-
Page 5: Table Of Contents
Installation Manual of Network Camera Table of Contents Chapter 1 Introduction .........................6 Applications ..........................6 Preparations ..........................6 Chapter 2 Bullet Camera Installation ....................8 Type X Bullet Camera ....................... 147 2.1.1 Camera Description ....................147 2.1.2 Installation ........................149... -
Page 6: Chapter 1 Introduction
Installation Manual of Network Camera Chapter 1 Introduction The network camera is a kind of embedded digital surveillance product that combines the features of both traditional analog camera and the encoder. With a built-in video server, the network camera is capable of providing real-time video stream compression, processing, video analysis and transmission simultaneously. - Page 7 Installation Manual of Network Camera Make sure that the wall is strong enough to withstand three times the weight of the camera. For the camera that supports IR, you are required to pay attention to the following precautions to prevent IR reflection: ...
-
Page 8: Chapter 2 Bullet Camera Installation
Installation Manual of Network Camera Chapter 2 Bullet Camera Installation 2.1 Type I Bullet Camera 2.1.1 Camera Description The overview of the network bullet camera is shown below. Figure 2-1 Overview (1) Figure 2-2 Overview (2) Table 2-1 Description... -
Page 9: Installation
Installation Manual of Network Camera Description Sun Shield Camera Body Bracket Tray Bracket Hinge Bracket Bearing Mounting Base Seal Ring Junction Box Network Cable Interface Power Cable Interface Alarm Interface IN, G: Alarm In 1A,1B: Alarm Out RS-485 Communication Interface Audio Input Audio Output SD Card Slot... - Page 10 Installation Manual of Network Camera Drill Template 1 1:Screw Hole for Mounting Base 1 Figure 2-3 Drill Template 2. Fix the junction box to the ceiling with the supplied screws. Please insert the expansion screws first if the camera is mounted to the cement ceiling. And you can use the self-tapping screws directly if camera is mounted to the wooden ceiling.
- Page 11 Installation Manual of Network Camera 4. Align the screw holes on the mounting base to those on the junction box, and tighten the camera with screws. Figure 2-5 Install Camera 5. Tighten the lock screw on the camera to complete installation. Figure 2-6 Tighten the Lock Screw ...
- Page 12 Installation Manual of Network Camera Drill Template 1 1:Screw Hole for Mounting Base 1 Figure 2-7 Drill Template 2. Fix the junction box to the wall with the supplied screws. Please insert the expansion screws first if the camera is mounted to the cement wall. And you can use the self-tapping screws directly if camera is mounted to the wooden wall.
- Page 13 Installation Manual of Network Camera Figure 2-9 Install Camera 5. Tighten the lock screw on the camera to complete installation. Figure 2-10 Tighten the Lock Screw 3-axis Adjustment This series of camera supports 3-axis adjustment, and you can follow the steps below to adjust the camera to the desired surveillance angle.
- Page 14 Installation Manual of Network Camera Steps: 1. Loosen No.1 lock screw to adjust the pan angle [±180°]. -180°~+180° Figure 2-11 Adjust Pan Angle 2. Loosen No.2 lock screw to adjust the tilt angle [±180°]. -180°~+180° Figure 2-12 Adjust Tilt Angle...
- Page 15 Installation Manual of Network Camera 3. Loosen No.3 lock screw, and rotate the camera body [0°~105°] to adjust the camera to the desired angle of view. Figure 2-13 Adjust the Rotation Angle 4. Tighten the screws after the adjustment is completed.
