ENGLISH
IL51859524
Smart Wi-Fi Security Motion WiZ instructions
®
C. (2) #6-32 x 3/4 in. and (2) #8-32 x 3/4 in.
Junction box screws (use the size
that fits your junction box)
1. Philips Screwdriver
2. Safety Goggles
3. Silicone Sealant
4. Wire Strippers / Cutter
5. Circuit Tester
6. Adjustable Wrench
7. Work Gloves
8. Ladder
9. Power Drill
When using product, basic precautions should always be followed, including the following:
1. Heed all warnings, including below warnings AND those included on product.
2. HALO Outdoor Security luminaires (fixtures) are designed to meet the latest NEC requirements and are certified in full compliance
with UL. Before attempting installation of any lighting luminaire check your local electrical code. This code sets the wiring standards
for your locality and should be carefully studied before starting.
3. Read and follow these instructions.
4. For outdoor use only.
5. cULus LISTED for wet location.
6. Disassembling your fixture will void the warranty
7. Your fixture is prewired and preassembled for easy installation.
8. Do not make or alter any open holes in an enclosure of wiring or electrical components during kit installation.
9. Smart technology and downloads required to operate the fixtures.
10. To prevent wiring damage or abrasion, do not expose wiring to edges of sheet metal or other sharp objects.
11. Connect fixture to a 120Vac, 60 Hz power source. Any other connection voids the warranty.
12. Fixture should be installed by persons with experience in household wiring or by a qualified electrician. The electrical system, and
the method of electrically connecting the fixture to it, must be in accordance with the National Electrical Code and local building
codes.
13. WARNING - Risk of fire or electric shock.
14. Fixture operating temperature of -30°C to 40°C.
PACKAGING CONTENTS
A. Polycarbonate
housing light fixture
ITEMS REQUIRED (Purchase separately)
1 2 3
IMPORTANT SAFETY INSTRUCTIONS
B. Mounting Bracket with ground screw
D. (2) Fixture Mounting Screws
(M4*20mm) with Washers
4 5 6
INS #
ESF2ARGBWMBL-WiZ
ESF2ARGBWMW-WiZ
E. (2) Wire Nuts
7 8 9
